Danfoss iC2 Application Manual page 277

Application Guide | iC2-Micro Frequency Converters
Group index Group name
4.2.2 Nameplate Data
4.2.3 Asyn. Induction Motor
4.2.4 Permanent Magnet Motor
4.4 Motor Control
4.4.1 General Settings
4.4.2 AC-Brake
Danfoss A/S © 2024.03
Parameter Parameter name
index
4.2.1.1 Motor Type
4.2.1.2 Number of Poles
4.2.1.3 AMA Mode
4.2.1.4 Motor Cable Length
4.2.1.5 Motor Cable Length Feet
4.2.2.1 Nominal Power
4.2.2.2 Nominal Voltage
4.2.2.3 Nominal Current
4.2.2.4 Nominal Frequency
4.2.2.5 Nominal Speed
4.2.3.1 Stator Resistance Rs
4.2.3.2 Rotor Resistance Rr
4.2.3.4 Stator Leakage Inductance Lls
4.2.3.6 Magnetizing Inductance Lm
4.2.3.7 Motor Cont. Rated Torque
4.2.4.1 Back EMF
4.2.4.3 d-axis Inductance Ld
4.2.4.4 d-axis Inductance LdSat
4.2.4.6 Ld Current Point
4.2.4.7 q-axis Inductance Lq
4.2.4.8 q-axis Inductance LqSat
4.2.4.10 Lq Current Point
4.4.1.2 AEO Minimum Magnetization
4.4.1.3 Torque Characteristic
4.4.1.4 Clockwise Direction
4.4.1.5 Motor Control Bandwidth
4.4.2.1 Enable AC-Brake
Parameter
number
110
139
129
142
143
120
122
124
123
125
130
131
133
135
126
140
137
144
148
138
145
149
1441
103
106
108
210
AB413939445838en-000301 / 130R1254 |
Type
enum
uint8
enum
uint8
uint16
uint16
uint16
uint32
uint16
uint16
uint32
uint32
uint32
uint32
uint32
uint16
int32
int32
int16
int32
int32
uint16
uint8
enum
enum
enum
enum
277
