Danfoss iC2 Application Manual page 202

Application Guide | iC2-Micro Frequency Converters
Default value:
39
Parameter
1301
number:
Data type:
enum
The following are the selections for the parameter.
Selection number Selection name
0 FALSE
1 TRUE
2 Running
3 In range
4 On reference
7 Out of current range
8 Below I low
9 Above I high
16 Thermal warning
17 Mains out of range
18 Reversing
19 Warning
20 Alarm (trip)
21 Alarm (trip lock)
22 Comparator 0
23 Comparator 1
24 Comparator 2
25 Comparator 3
26 Logic rule 0
27 Logic rule 1
28 Logic rule 2
29 Logic rule 3
33 Digital input T13
34 Digital input T14
35 Digital input T15
36 Digital input T17
202
| Danfoss A/S © 2024.03
Parameter type:
Unit:
Access type:
Selection description
Enters False in logic rule.
Enters True in logic rule.
See P 9.4.3.1 Function Relay [5] for description.
See P 9.4.3.1 Function Relay [7] for description.
See P 9.4.3.1 Function Relay [8] for description.
See P 9.4.3.1 Function Relay [12] for description.
See P 9.4.3.1 Function Relay [13] for description.
See P 9.4.3.1 Function Relay [14] for description.
See P 9.4.3.1 Function Relay [21] for description.
Mains voltage is outside the specified voltage range.
See P 9.4.3.1 Function Relay [25] for description.
A warning is active.
A trip alarm is active.
A trip lock alarm is active.
Use result of comparator 0 in logic rule.
Use result of comparator 1 in logic rule.
Use result of comparator 2 in logic rule.
Use result of comparator 3 in logic rule.
Use result of logic rule 0 in logic rule.
Use result of logic rule 1 in logic rule.
Use result of logic rule 2 in logic rule.
Use result of logic rule 3 in logic rule.
Use value of DI1 in logic rule.
Use value of DI2 in logic rule.
Use value of DIO in logic rule.
Use value of DI3 in logic rule.
Selection
–
Read/Write
AB413939445838en-000301 / 130R1254
