Danfoss iC2 Application Manual page 214

Application Guide | iC2-Micro Frequency Converters
Selection number Selection name
74 SL Time-out 7
83 Lost Load
States (Menu Index 8.4.6)
7.8.2.7
P 8.4.6.1 Event
Select the boolean input (TRUE or FALSE) to define the Smart Logic Controller event. This is an array parameter containing SLC events 0–
19.
Default value:
0
Parameter
1351
number:
Data type:
enum
Selection number Selection name
0 FALSE
1 TRUE
2 Running
3 In range
4 On reference
7 Out of current range
8 Below I low
9 Above I high
16 Thermal warning
17 Mains out of range
18 Reversing
19 Warning
20 Alarm (trip)
21 Alarm (trip lock)
22 Comparator 0
23 Comparator 1
24 Comparator 2
25 Comparator 3
26 Logic rule 0
27 Logic rule 1
28 Logic rule 2
214
| Danfoss A/S © 2024.03
Selection description
Use result of timer 7 in logic rule.
Lost load is performed.
Parameter type:
Unit:
Access type:
Selection description
Enters False in logic rule.
Enters True in logic rule.
See P 9.4.3.1 Function Relay [5] for description.
See P 9.4.3.1 Function Relay [7] for description.
See P 9.4.3.1 Function Relay [8] for description.
See P 9.4.3.1 Function Relay [12] for description.
See P 9.4.3.1 Function Relay [13] for description.
See P 9.4.3.1 Function Relay [14] for description.
See P 9.4.3.1 Function Relay [21] for description.
Mains voltage is outside the specified voltage range.
See P 9.4.3.1 Function Relay [25] for description.
A warning is active.
A trip alarm is active.
A trip lock alarm is active.
Use result of comparator 0 in logic rule.
Use result of comparator 1 in logic rule.
Use result of comparator 2 in logic rule.
Use result of comparator 3 in logic rule.
Use result of logic rule 0 in logic rule.
Use result of logic rule 1 in logic rule.
Use result of logic rule 2 in logic rule.
Selection
–
Read/Write
AB413939445838en-000301 / 130R1254
