Application Guide | iC2-Micro Frequency Converters
2.
To test motor operation, start the motor at low speed (100–200 RPM). If the motor does not turn, check installation, general
parameter configurations, and motor data.
3.
Perform parking operation by setting P 5.6.14 Sync. Motor Parking Current % and P 5.6.13 Sync. Motor Parking Time. The
factory setting values of the parameters can be adjusted and increased for applications with high inertia. Start the motor at
nominal speed. If the application does not run well, check the VVC+ PM settings. The following table shows recommendations
in different applications.
Table 13: Recommendations in Different Applications
Application
Low inertia applications ILoad/IMotor<5
Medium inertia applications 50>ILoad/IMotor>5
High inertia applications ILoad/IMotor>50
High load at low speed <30% (rated speed)
If the motor starts oscillating at a certain speed, increase P 4.4.4.7 Damping Gain. Increase the value in small steps. Starting
torque can be adjusted in P 4.4.4.14 Min. Current at Low Speed. 100% provides nominal torque as starting torque.

Speed Control Configuration with I/O Using Default

5.4.4
1.
Go to parameter group 5 and specify the following:
Parameter index
5.4.3
5.4.2
9.4.1.2
9.4.1.3
9.4.1.4
9.4.1.5
5.5.3.7
9.5.1.2
9.4.3.1
5.5.3.3
Danfoss A/S © 2024.03
Parameter name Recommended settings
Motor Control Principle Use default: [1] VVC+. In most situations,
selecting VVC+ provides optimum
performance without further adjustments.
Operation Mode Use default: [0] Speed Open Loop
T13 Digital Input Use default: [8] Start
T14 Digital Input Use default: [10] Reversing
T15 Digital Input Use default: [1] Reset
T17 Digital Input Use default: [14] Jog
Reference 1 Source [1] Analog Input 33
T31 Analog Output Use default: [100] Output Frequency
Function Relay Use default: [9] Fault
Reference Maximum Use default: 50
Settings
• Increase the value for P 4.4.4.10 Voltage filter time const.
by factor 5–10.
• Reduce the value for P 4.4.4.7 Damping Gain.
• Reduce the value (<100%) for P 4.4.4.14 Min. Current at
Low Speed.
Keep calculated values.
Increase the values for P 4.4.4.7 Damping Gain, P 4.4.4.9 Low
Speed Filter Time Const., and P 4.4.4.8 High Speed Filter Time
Const.
Increase the value for P 4.4.4.10 Voltage filter time const.
Increase the value for P 4.4.4.14 Min. Current at Low Speed
(>100% for longer time can overheat the motor).
AB413939445838en-000301 / 130R1254 |
Parameter number
101
100
510
511
512
513
315
691
540
303
53
