Application Guide | iC2-Micro Frequency Converters
Quick Access Navigation
3.2.4.3.2
Quick Access consists of the following 3 functions to set up the iC2-Micro Frequency Converters easily in a step-by-step prescribed
manner.
q1 - Motor Data Setting: Enables to first select motor type, followed by motor data entry based on motor nameplate.
l
After completing the motor data settings, it is recommended to execute Automatic Motor Adaptation (AMA), if P 5.4.3 Motor
Control Principle is set as [1] VVC+.
See AMA procedure in 5.4.5 Automatic Motor Adaptation
q2 - Application Selection: Enables to select typical application configurations. The application selections are pre-configured
l
parameter settings. 5 preset common applications are supported in iC2-Micro frequency converter, which are
Speed control mode
¢
Process control mode
¢
Multi-speed control mode
¢
3-wire control mode
¢
Torque control mode
¢
For more information, see
To optimize application configuration, configure essential changes to the parameter based on the required application selection
q3 - Motor Control Setting: Enables setting of the motor control data which influence motor operation performance, such as ramp-
l
up time and down time, reference limit, and so on.
The following figure shows the setting procedure when using Quick Access to start the motor.
Danfoss A/S © 2024.03
5.5.1 Application Selection Overview.
NOTICE
(AMA).
NOTICE
