Configuration Setup Examples

5
Introduction & Prerequisite
5.1
The section covers the basic configuration steps of a drive. Use the following topics as reference during the drive configuration/
commissioning process:
For control panel related information, see
l
For information on using MyDrive® Insight, see
l
Detailed information about the parameters is described in Chapter Parameter Descriptions.
l
A typical wiring schematic for iC2-Micro Frequency Converters is shown.
L1/L
L2
Power
L3/N
input
A=Analog, D=Digital
12 (+24 V OUT)
13 (D IN)
14 (D IN)
15 (D IN/OUT)
17 (D IN)
18 (D IN)
20 (COM I/O)
Analog output
31 (A OUT)
0/4-20 mA
32 (+10 V OUT)
+ 10 V DC
0-10 V DC
33 (A IN)
0/4-20 mA
0-10 V DC
34 (A IN)
0/4-20 mA
35 (COM I/O)
Figure 35: Wiring Diagram
48
| Danfoss A/S © 2024.03
3.2.4.1 Overview of Control Panel Basic
3.3.1 Overview of MyDrive®
1)
PE
Switch mode
power supply
24 V DC
4)
P9.4.1.1
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
Configuration.
Insight.
2)
UDC+/BR+
10 V DC
Relay 1
5)
S640
ON = Terminated
OFF = Open
5 V
S640
RS485
(N RS485) 69
interface
(P RS485) 68
(COM RS485) 61
RS485 communication
RJ45 port
U
V
W
PE
Motor
UDC-
Brake
resistor
BR-
3)
03
250 V AC, 2 A
02
01
0 V
RS485
