P 9.4.5.2 T15 Pulse Output Max. Freq
Set the maximum frequency for terminal 15, corresponding to the output variable selected in parameter 9.4.5.1 T15 Pulse Output
Variable.
Default value:
5000
Parameter
562
number:
Data type:
uint32
Bus Control (Menu Index 9.4.6)
7.9.2.6
P 9.4.6.1 Digital & Relay Bus Control
This parameter controls the state of the digital outputs and relays that are controlled by bus. A logical 1 indicates that the output is high
or active. A logical 0 indicates that the output is low or inactive.
Default value:
0
Parameter
590
number:
Data type:
uint32
Table 67: Bit Description
Bit
Bit 0
Bit 1-3
Bit 4
Bit 6-23
Bit 24
Bit 26-31
P 9.4.6.2 T15 Pulse Out Bus Control
Set the output frequency transferred to the output terminal 15 when the terminal is configured as [45] Bus Control in P 9.4.5.1 T15 Pulse
Output Variable.
Default value:
0
Parameter
593
number:
Data type:
uint16
P 9.4.6.3 T15 Pulse Out Timeout Preset
Set the output frequency transferred to the output terminal 15 when the terminal is configured as [48] Bus Control, Timeout in P 9.4.5.1
T15 Pulse Output Variable and a timeout is detected.
Danfoss A/S © 2024.03
Parameter type:
Unit:
Access type:
Parameter type:
Unit:
Access type:
Bit name
Digital Output Terminal 15
Reserved
Relay 1 Output Terminal
Reserved
Reserved
Reserved
Parameter type:
Unit:
Access type:
AB413939445838en-000301 / 130R1254 |
Range (4–32000)
Hz
Read/Write
Range (0–4294967295)
–
Read
Range (0.00–100.00)
%
Read
