Application Guide | iC2-Micro Frequency Converters
Table 2: Operation Buttons and Potentiometer (continued)
Name
Function
Stop/Reset
Stops the drive in local mode.
Resets the drive to clear a fault.
Potentiometer
Changes the reference value when the reference value is selected as potentiometer.
Table 3: Status Indicator Lights
Name
Function
MON
On: The main display is showing the drive status.
PGM
On: The drive is in programming status.
TOR
On: The drive is in torque mode.
Off: The drive is in speed mode.
LOC
On: The drive is in local mode.
Off: The drive is in remote mode.
REV
On: The drive is in reverse direction.
Off: The drive is in forward direction.
ST2
Refer to
Table 4: Operating Indicator Lights
Name
Function
WARN
Steadily lit when a warning occurs.
READY
Steadily lit when the drive is ready.
FAULT
Flashes when a fault occurs.
Table 5: Run Indicator Light
Name
Function
RUN
On: The drive is in normal operation.
Off: The drive has stopped.
Flash: In the motor-stopping process; or the drive received a RUN command, but no frequency output.
Table 6: Multiple Setups Indicator Light
ST2
(1)
Active setup
(2)
Programming setup
1) Select active setup in parameter P 6.6.1 Active Setup.
2) Select programming setup in parameter P 6.6.2 Active Setup.
22
| Danfoss A/S © 2024.03
Table
6.
Off
Setup 1
Setup 1
On
Flash
Setup 2
Setup 1
Setup 2
Setup 2
Flash quickly
Setup 2
Setup 1
AB413939445838en-000301 / 130R1254
