Danfoss iC2 Application Manual page 185

Application Guide | iC2-Micro Frequency Converters
Parameter
2248
number:
Data type:
uint16
P 5.12.7.10 Wake-Up Delay Time
Set the delay time for the motor to wait before waking up from sleep mode when the condition of waking up is met.
Default value:
0
Parameter
2249
number:
Data type:
uint16
Fieldbus Process Data (Menu Index 5.27)
7.6.12
P 5.27.1 PCD Write Selection
Use this parameter to select the parameters to be assigned to the PCD's telegrams. The number of available PCDs depends on the
telegram type. The values in the PCDs are then written to the selected parameters as data values.
Enter up to 16 different preset mapping 0–15 in this parameter, using array programming. If this parameter is active, addresses 2810–
2825 represent values of the 16 parameters. If this parameter is not active, addresses 2810 and 2811 are used as input-data-drive control
word and bus reference. Addresses 2812–2825 are reserved.
Default value:
0 [None]
Parameter
842
number:
Data type:
enum
The following are the selections for the parameter:
Selection number
0
1
2
3
4
5
6
7
8
9
10
Danfoss A/S © 2024.03
Unit:
Access type:
Parameter type:
Unit:
Access type:
Parameter type:
Unit:
Access type:
Selection name
None
Minimum Reference
Maximum Reference
Ramp 1 Ramp Up Time
Ramp 1 Ramp Down Time
Ramp 2 Ramp Up Time
Ramp 2 Ramp Down Time
Jog Ramp Time
Quick Stop Time
Motor Speed Low Limit [Hz]
Motor Speed High Limit [Hz]
AB413939445838en-000301 / 130R1254 |
s
Read/Write
Range (0–3600)
s
Read/Write
Selection
–
Read/Write
185
