Application Guide | iC2-Micro Frequency Converters
Selection number
0
1
P 5.5.1.6 Configurable Status Word STW
Use this parameter to configure status word bits. Bits 5 and 12–15 of the STW are configurable for various Drive status signals.
Default value:
1 [Profile Default]
Parameter
813
number:
Data type:
enum
The following are the selections for the parameter.
Selection number
0
1
10
11
12
13
15
21
30
40
54
59
P 5.5.1.7 Configurable Control Word CTW
Use this parameter to configure control word bits. The control word has 16 bits (0–15). Bits 10 and 12–15 are configurable.
Default value:
1 [Profile Default]
Parameter
814
number:
Data type:
enum
The following are the selections for the parameter.
150
| Danfoss A/S © 2024.03
Selection name
None
FC Port
Parameter type:
Unit:
Access type:
Selection name
No function
Profile default
T13 DI status
T14 DI status
T15 DI status
T17 DI status
T18 DI status
Thermal warning
Brake fault (IGBT)
Out of reference range
Running
On reference
Parameter type:
Unit:
Access type:
Selection
–
Read/Write
Selection
–
Read/Write
