Setting up the Drive using Quick Access via Control Panel

5.3
The following steps shows the quick access setup.
1.
Power up the drive.
2.
Press Home/Menu button on the control panel for accessing the menu structure.
3. Select QACC, and enter q1 Motor Data to first select motor type using P 4.2.1.1 Motor Type.
4.
Set the value of motor data parameters, in sequence, based on the selected motor type.
5.
Execute Automatic Motor Adaptation (AMA), if needed. See
6. Select application type in q2 Application Selection and wiring I/O terminals accordingly. For more information, see
Application Selection
7.
Enter q3 Motor Control to configure reference limitations, output limitations, and ramp time.
8.
Press REM/LOC, to set the drive in remote operation.
9.
To start the drive by I/O terminals.

Motor Configuration

5.4

Motor Configuration Overview

5.4.1
The setup examples in this chapter describe motor configuration.
The parameters specified in motor configuration, cannot be adjusted when the motor is running.
The configuration setup contains, menu index, parameter name, recommended parameter setting, and parameter number. The
parameter number is a unique identification reference for the parameter. For detailed description on a parameter, refer Chapter
Parameter Descriptions.

Asynchronous Motor Setup

5.4.2
1.
For asynchronous motor setup, set the following parameters:
50
| Danfoss A/S © 2024.03
Parameter name
Reference 3 Source
Coasting Select
Quick Stop Select
Start Select
Reversing Select
T13 Digital Input
T14 Digital Input
T15 Digital Input
T17 Digital Input
Overview.
Example setting
[11] Local Bus Reference
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[8] Start
[10] Reversing
[1] Reset
[14] Jog
5.4.5 Automatic Motor Adaptation
NOTICE
Parameter number
317
850
851
853
854
510
511
512
513
(AMA).
5.5.1
