Danfoss iC2 Application Manual page 88

Application Guide | iC2-Micro Frequency Converters
Table 36: Drive Control Word (FC Profile) (continued)
Coil
04
05
06
07
08
09
10
11
12
13
14
15
16
Drive Status Word (FC Profile)
Table 37: Drive Status Word (FC Profile)
Coil
33
34
35
36
37
38
39
40
41
42
43
44
45
46
88
| Danfoss A/S © 2024.03
0
Coast stop
Quick stop
Freeze frequency
Ramp stop
No reset
No jog
Ramp 1
Data not valid
Relay 1 off
Reserved
Set up LSB
Reserved
No reversing
0
Control not ready
Drive not ready
Coast stop
No alarm
Not used
Not used
Not used
No warning
Not at reference
Local mode
Out of frequency range
Stopped
Not used
No voltage warning
1
No coast stop
No quick stop
No freeze frequency
Start
Reset
Jog
Ramp 2
Data valid
Relay 1 on
Reversing
1
Control ready
Drive ready
Safety closed
Alarm
Not used
Not used
Not used
Warning
At reference
Remote mode
In frequency range
Running
Not used
Voltage warning
AB413939445838en-000301 / 130R1254
