CRC Check Field
6.1.7.4.7
Telegrams include an error-checking field, operating based on a cyclic redundancy check (CRC) method. The CRC field checks the
contents of the entire telegram. It is applied regardless of any parity check method used for the individual characters of the telegram.
The transmitting device calculates the CRC value and appends the CRC as the last field in the telegram. The receiving device recalculates
a CRC during receipt of the telegram and compares the calculated value to the actual value received in the CRC field. 2 unequal values
result in bus timeout. The error-checking field contains a 16-bit binary value implemented as 2 8-bit bytes. After the implementation,
the low-order byte of the field is appended first, followed by the high-order byte. The CRC high-order byte is the last byte sent in the
telegram.
Coil Register Addressing
6.1.7.4.8
Introduction
In Modbus, all data is organized in coils and holding registers. Coils hold a single bit, whereas holding registers hold a 2 byte word (that is
16 bits). All data addresses in Modbus telegrams are referenced to 0. The 1st occurrence of a data item is addressed as item number 0. For
example: The coil known as coil 1 in a programmable controller is addressed as coil 0000 in the data address field of a Modbus telegram.
Coil 127 decimal is addressed as coil 007Ehex (126 decimal).
Holding register 40001 is addressed as register 0000 in the data address field of the telegram. The function code field already specifies
a holding register operation. Therefore, the 4XXXX reference is implicit. Holding register 40108 is addressed as register 006Bhex (107
decimal).
Coil Register
Table 35: Coil Register
Coil number Description
1–16 Drive control word.
17–32 Drive speed or setpoint reference range 0x0– 0xFFFF (-200% ... ~200%).
33–48 Drive status word.
49–64 Open-loop mode: Drive output frequency.
Closed-loop mode: Drive feedback signal.
65 Parameter write control (master to follower).
0 = Parameter changes are written to the RAM of the drive.
1 = Parameter changes are written to the RAM and EEPROM of the drive.
66–65536 Reserved.
Drive Control Word (FC Profile)
Table 36: Drive Control Word (FC Profile)
Coil
01
02
03
Danfoss A/S © 2024.03
0
Preset reference lsb
Preset reference msb
DC brake
Signal direction
Master to follower
Master to follower
Follower to master
Follower to master
Master to follower
–
1
No DC brake
AB413939445838en-000301 / 130R1254 |
