Application Guide | iC2-Micro Frequency Converters
Table 68: Data for Dead-zone Funtion Key Parameters
Parameter
P 9.5.2.1 T33 Mode
P 9.5.2.2 T33 High Voltage
P 9.5.2.3 T33 Low Voltage
P 9.5.2.6 T33 High Ref./Feedb. Value
P 9.5.2.7 T33 Low Ref./Feedb. Value
P 9.5.2.9 T33 Voltage Dead Zone Scale
Table 69: Data for Relevant Parameters
Parameter
P 5.5.3.1 Reference Range
P 5.5.3.3 Reference Maximum
P 5.5.3.7 Reference 1 Source
P 5.5.3.8 Reference 2 Source
P 5.5.3.9 Reference 3 Source
P 5.8.1 Rotation Direction
Input Terminal 34 (Menu Index 9.5.3)
7.9.3.3
P 9.5.3.1 T34 Mode
Select if terminal 34 is used for current or voltage input.
Default value:
1 [Voltage Mode]
Parameter
629
number:
Data type:
enum
The following are the selections for the parameter.
Selection number
0
1
P 9.5.3.2 T34 High Voltage
Enter the voltage (V) that corresponds to the high reference value, as set in P 9.5.3.6 T34 High Ref./Feedb. Value.
Default value:
10.00
Danfoss A/S © 2024.03
Data
[1] Voltage Mode
10.00 V
2.00 V
50.000
-50.000
0.5 V
Data
[1] -Max~+Max
50.00
[1] Analog Input 33
[0] No function
[0] No function
[2] Both Directions
Parameter type:
Unit:
Access type:
Selection name
Current Mode
Voltage Mode
Parameter type:
Parameter number
619
611
610
615
614
617
Parameter number
300
303
315
316
317
410
Selection
–
Read/Write
Range (0.00–10.00)
AB413939445838en-000301 / 130R1254 |
