VACON® 100 FLOW
Application Guide
Index Monitoring value
V2.6.4 Application Status Word2
V2.6.5 DIN Status Word 1
V2.6.6 DIN Status Word 2
V2.6.7 Motor current 1 decimal
V2.6.8 Frequency reference source
V2.6.9 Last active fault code
V2.6.10 Last active fault ID
80 | Danfoss A/S © 2023.08
Unit Scale ID
1 90
1 56
1 57
0.1 45
1 1495
1 37
1 95
Description
B12 = Motor Preheat active
B13 = Quick stop active
B14 = Drive stopped from keypad
B0 = Acc/Dec prohibited
B1 = Motor switch open
B2 = PID running
B3 = PID sleep
B4 = PID soft fil
B5 = Autocleaning active
B6 = Jockey pump
B7 = Priming pump
B8 = Anti-blocking
B9 = Input pressure alarm
B10 = Frost protection alarm
B11 = Overpressure alarm
B14 = Supervision 1
B15 = Supervision 2
0 = PC
1 = Preset Freqs
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Controller
8 = Motor Potentiom.
10 = Flushing
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
100 = Not defined
101 = Alarm,PresetFreq
102 = Auto-cleaning
AB298035655957en-000201 / DPD01083
Monitor Menu
