Index Parameter
P3.6.6 Fieldbus Data Out 6 Selection
P3.6.7 Fieldbus Data Out 7 Selection
P3.6.8 Fieldbus Data Out 8 Selection
P3.6.9 Fieldbus Data Out 9 Selection
P3.6.10 Fieldbus Data Out 10 Selection
P3.6.11 Fieldbus Data Out 11 Selection
P3.6.12 Fieldbus Data Out 12 Selection
P3.6.13 Fieldbus Data Out 13 Selection
P3.6.14 Fieldbus Data Out 14 Selection
P3.6.15 Fieldbus Data Out 15 Selection
P3.6.16 Fieldbus Data Out 16 Selection
P3.6.17 FB Sign of Actual
Table 54: The Default Values for Process Data Out in Fieldbus
Data
Process Data Out 1
Process Data Out 2
Process Data Out 3
Process Data Out 4
Process Data Out 5
Process Data Out 6
Process Data Out 7
Process Data Out 8
Example
The value 2500 for output frequency equals 25.00 Hz, because the scale is 0.01. All the monitoring values in the Monitor menu
(chapter 5.1 Uses of the Monitor
Danfoss A/S © 2023.08
Min
0
0
0
0
0
0
0
0
0
0
0
0
Default Value
Output frequency
Motor speed
Motor current
Motor torque
Motor power
Motor voltage
DC link voltage
Last active fault code
Menu) are given the scale value.
Max Unit Default
35000 6
35000 7
35000 37
35000 0
35000 0
35000 0
35000 0
35000 0
35000 0
35000 0
35000 0
2 0
AB298035655957en-000201 / DPD01083 | 103
Parameters Menu
ID Description
857
858
859
890
891
892
893
894
895
896
897
888 0 = Positive
1 = Actual direction
2 = Follow reference
Scale
0.01 Hz
1 RPM
0.1 A
0.1%
0.1%
0.1 V
1 V
1
