11.2.6 (ID 2373) Autoscale
Location in the menu: P2.2.7
Use this parameter to set autoscaling on or off. If autoscaling is enabled, the signal is automatically scaled between the minimum
and maximum values.

11.3 Motor Settings

11.3.1 Motor Nameplate Parameters

11.3.1.1 (ID 110) Motor Nominal Voltage
Location in the menu: P3.1.1.1
Find the value U on the nameplate of the motor. Find out whether the motor connection is Delta or Star.
n
11.3.1.2 (ID 111) Motor Nominal Frequency
Location in the menu: P3.1.1.2
Find the value f on the nameplate of the motor.
n
When this parameter changes, parameters P3.1.4.2 Field Weakening Point Frequency and P3.1.4.3 Voltage at Field Weakening Point
start automatically. The 2 parameters have different values for each motor type. See
11.3.1.3 (ID 112) Motor Nominal Speed
Location in the menu: P3.1.1.3
Find the value n on the nameplate of the motor.
n
11.3.1.4 (ID 113) Motor Nominal Current
Location in the menu: P3.1.1.4
Find the value I on the nameplate of the motor.
n
11.3.1.5 (ID 120) Motor Cos Phi
Location in the menu: P3.1.1.5
Find the value on the nameplate of the motor.
11.3.1.6 (ID 116) Motor Nominal Power
Location in the menu: P3.1.1.6
Find the value P on the nameplate of the motor.
n

11.3.2 Motor Control Parameters

11.3.2.1 (ID 650) Motor Type
Location in the menu: P3.1.2.2
Use this parameter to set the type of motor in the process.
Selection number Selection name
0 Induction motor (IM)
1 Permanent Magnet Motor (PM)
2 Reluctance Motor
When the value of parameter P3.1.2.2 Motor Type is changed, the values of parameters P3.1.4.2 Field Weakening Point Frequency
and P3.1.4.3 Voltage at Field Weakening Point change automatically. See the following table. The 2 parameters have different values
for each motor type.
