VACON® 100 FLOW
Application Guide
Table 82: Soft Fill Settings
Index Parameter
P3.13.8.1 Soft Fill Function
P3.13.8.2 Soft Fill Frequency
P3.13.8.3 Soft Fill Level
P3.13.8.4 Soft Fill Timeout
P3.13.8.5 D Soft Fill Fault
Table 83: Input Pressure Supervision Parameters
Index Parameter
P3.13.9.1 Enable Supervision
P3.13.9.2 Supervision Signal
P3.13.9.3 Supervision Unit
Selection
118 | Danfoss A/S © 2023.08
Min Max Unit
0 2
0.00 P3.3.1.2 Hz
-99999.9 9 99999.9 9 Varies
0 30000 s
0 3
Min Max Unit
0 1
0 23
0 9 Varies
Default ID Description
0 1094 0 = Disabled
1 = Enabled, Level
2 = Enabled, Timeout
0 1055
0.0000 1095
0 1096 0 = No timeout, no fault triggering
2 748 0 = No action
1 = Alarm
2 = Fault (Stop according to stop mode)
3 = Fault (Stop by coasting)
De- ID Description
fault
0 1685 0 = Disabled
1 = Enabled
0 1686 0 = Analog input 1
1 = Analog input 2
2 = Analog input 3
3 = Analog input 4
4 = Analog input 5
5 = Analog input 6
6 = ProcessDataIn1 (0–100%)
7 = ProcessDataIn2 (0–100%)
8 = ProcessDataIn3 (0–100%)
9 = ProcessDataIn4 (0–100%)
10 = ProcessDataIn5 (0–100%)
11 = ProcessDataIn6 (0–100%)
12 = ProcessDataIn7 (0–100%)
13 = ProcessDataIn8 (0–100%)
14 = Block Out.1
15 = Block Out.2
16 = Block Out.3
17 = Block Out.4
18 = Block Out.5
19 = Block Out.6
20 = Block Out.7
21 = Block Out.8
22 = Block Out.9
23 = Block Out.10
3 1687 1 = %
2 = mbar
AB298035655957en-000201 / DPD01083
Parameters Menu
