VACON® 100 FLOW
Application Guide
Parameter Descriptions
Use this parameter to enable Flux Braking. It is possible to use flux braking as an alternative to DC-braking. Flux braking increases
the braking capacity in conditions where extra brake resistors are not necessary.
When braking is necessary, the system decreases the frequency and increases the flux in the motor. It increases the capacity of the
motor to brake. The motor speed is controlled during braking.
N O T I C E
Use the braking only intermittently. Flux braking converts energy into heat and can damage the motor.
11.6.5.2 (ID 519) Flux Braking Current
Location in the menu: P3.4.5.2
Use this parameter to set the current level for the flux braking.
11.7 I/O Configuration
11.7.1 Programming of Digital and Analog Inputs
11.7.1.1 General Information on the Programming
The programming of inputs of the AC drive is flexible. It is possible to use freely the available inputs of the standard and optional I/O
for different functions.
It is possible to expand the available capacity of I/O with option boards. It is possible to install the option boards in the slots C, D,
and E. For more data on the installation of option boards, see the Installation Guide.
