VACON® 100 FLOW
Application Guide
A
Analog output signal
B
Analog output minimum scale
C
Analog output maximum scale
11.8 Fieldbus Data
11.8.1 (ID 852) FB DataOut 1 Selection
Location in the menu: P3.6.1
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.2 (ID 853) FB DataOut 2 Selection
Location in the menu: P3.6.2
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.3 (ID 854) FB DataOut 3 Selection
Location in the menu: P3.6.3
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.4 (ID 855) FB DataOut 4 Selection
Location in the menu: P3.6.4
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.5 (ID 856) FB DataOut 5 Selection
Location in the menu: P3.6.5
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.6 (ID 857) FB DataOut 6 Selection
Location in the menu: P3.6.6
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.7 (ID 858) FB DataOut 7 Selection
Location in the menu: P3.6.7
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
The data is scaled to an unsigned 16-bit format according to the format on the control panel. For example, value 25.5 on the display
equals 255.
11.8.8 (ID 859) FB DataOut 8 Selection
Location in the menu: P3.6.8
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
Danfoss A/S © 2023.08
D
Maximum frequency reference
E
Output frequency
AB298035655957en-000201 / DPD01083 | 215
Parameter Descriptions
