VACON® 100 FLOW
Application Guide
10.11.7 (ID 880) FB Data IN 5
Location in the menu: V2.12.7
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.8 (ID 881) FB Data IN 6
Location in the menu: V2.12.8
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.9 (ID 882) FB Data IN 7
Location in the menu: V2.12.9
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.10 (ID 883) FB Data IN 8
Location in the menu: V2.12.10
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.11 (ID 864) FB Status Word
Location in the menu: V2.12.11
This monitoring value shows the status of the fieldbus status word that the application uses in bypass mode. Depending on the
fieldbus type or profile, the data can be modified before it is sent to the fieldbus.
Bit Value = 0 (FALSE)
Bit 0 Not ready to operate
Bit 1 Not running
Bit 2
Behavior depends on P3.6.17.
Bit 3 No fault
Bit 4 No alarm
Bit 5 Requested speed not reached
Bit 6 Actual speed of the drive not zero
Bit 7 Motor not magnetized (flux not ready)
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
10.11.12 (ID 865) FB Speed Actual
Location in the menu: V2.12.12
This monitoring value shows the actual speed of the drive as a percentage of minimum frequency and maximum frequency. The
value 0% indicates the minimum frequency and the value 100% indicates the maximum frequency. This monitoring value is contin-
uously updated depending on the momentary min and max frequencies and the output frequency.
Danfoss A/S © 2023.08
Monitoring Value Descriptions
Value = 1 (TRUE)
Ready to operate
Running
Behavior depends on P3.6.17.
Fault is active
Alarm is active
Running at requested speed
Actual speed of the drive is zero
Motor magnetized (flux ready)
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
AB298035655957en-000201 / DPD01083 | 161
