Description
7 = At speed
8 = Thermistor fault
9 = Motor regulator active
10 = Start signal active
11 = Keypad control active
12 = I/O B control activated
13 = Limit supervision 1
14 = Limit supervision 2
15 = Fire Mode active
16 = Flushing activated
17 = Preset freq. active
18 = Quick stop activated
19 = PID in Sleep mode
20 = PID soft fill active
21 = PID feedback supervision (limits)
22 = Ext. PID supervision (limits)
23 = Input press. alarm/fault
24 = Frost prot. alarm/fault
25 = Time channel 1
26 = Time channel 2
27 = Time channel 3
28 = FB ControlWord B13
29 = FB ControlWord B14
30 = FB ControlWord B15
31 = FB Process- Data1.B0
32 = FB Process- Data1.B1
33 = FB Process- Data1.B2
34 = Maintenance alarm
35 = Maintenance fault
37 = Block 2 Out
38 = Block 3 Out
39 = Block 4 Out
40 = Block 5 Out
41 = Block 6 Out
42 = Block 7 Out
43 = Block 8 Out
44 = Block 9 Out
45 = Block 10 Out
46 = Jockey pump control
47 = Priming pump control
48 = Auto-cleaning active
49 = Multi-pump K1 control
50 = Multi-pump K2 control
51 = Multi-pump K3 control
52 = Multi-pump K4 control
53 = Multi-pump K5 control
54 = Multi-pump K6 control
55 = Multi-pump K7 control
56 = Multi-pump K8 control
69 = Selected parameter set
