Index Parameter
1.11 Motor Nominal Speed
1.12 Motor Nominal Cur-
rent
1.13 Motor Cos Phi (Power
Factor)
1.14 Energy Optimization
1.15 Identification
1.16 Start Function
1.17 Stop Function
1.18 Automatic Reset
1.19 Response to External
Fault
1.20 Response to AI Low
Fault
1.21 Remote Control Place
1.22 I/O Control Reference
A Selection
36 | Danfoss A/S © 2023.08
Min Max Unit Default
24 19200 RPM Varies
IH * 0.1 IH * 2 A Varies
0.30 1.00 Varies
0 1 0
0 2 0
0 1 0
0 1 0
0 1 0
0 3 2
0 5 0
0 1 0
1 20 6
ID Description
112 Find this value n on the nameplate of the mo-
n
tor.
113 Find this value I on the nameplate of the mo-
n
tor.
120 Find this value on the nameplate of the motor.
666
0 = Disabled
1 = Enabled
631
0 = No action
1 = At standstill
2 = With rotation
505
0 = Ramping
1 = Flying Start
506
0 = Coasting
1 = Ramping
731
0 = Disabled
1 = Enabled
701
0 = No action
1 = Alarm
2 = Fault (Stop according to stop mode)
3 = Fault (Stop by coasting)
700
0 = No action
1 = Alarm
2 = Alarm+preset fault frequency (P3.9.1.13)
3 = Alarm + previous frequency
4 = Fault (Stop according to stop mode)
5 = Fault (Stop by coasting)
172
0 = I/O control
1 = Fieldbus control
117
1 = Preset Frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID reference
8 = Motor potentiometer
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
