1 Introduction

1.1 Purpose of this Application Guide

This Application Guide provides information for configuring the system, controlling the AC drive, accessing parameters, program-
ming, and troubleshooting of the AC drive. It is intended for use by qualified personnel. Read and follow the instructions to use the
drive safely and professionally. Pay particular attention to the safety instructions and general warnings that are provided in this
manual and other documentation delivered with the drive.

1.2 Manual and Software Version

This manual is regularly reviewed and updated. All suggestions for improvement are welcome.
The original language of this manual is English.
Table 1: Manual and Software Version
Edition
DPD01083I

1.3 Additional Resources

Other resources are available to understand advanced AC drive functions and operation.
• VACON 100 Wall-mounted Drives Operating Guide
®
• VACON 100 Enclosed Drives Installation Manual
®
• VACON 100 IP00 Drive Modules Installation Manual
®
• VACON 100 X Installation Manual
®
• Instructions for operation with option boards and other optional equipment.
Supplementary publications and manuals are available from Danfoss.
For US and Canadian markets:
NOTE! Download the English and French product guides with applicable safety, warning and caution information from
www.danfoss.com/en/service-and-support/.
REMARQUE Vous pouvez télécharger les versions anglaise et française des guides produit contenant l'ensemble des informations
de sécurité, avertissements et mises en garde applicables sur le site https://www.danfoss.com/en/service-and-support/.

1.4 Parameter Table Reading Guide

This manual includes a large quantity of parameter tables. These instructions tell you how to read the tables.
A B
Index Parameter
Illustration 1: Parameter Table Reading Guide
A The location of the parameter in the menu, that is,
the parameter number.
B The name of the parameter.
C The minimum value of the parameter.
D The maximum value of the parameter.
Danfoss A/S © 2023.08
Software version
FW0159V028
C D E F
Min Max Unit
G H
Default ID Description
E The unit of the value of the parameter. The unit
shows if it is available.
F The value that was set in the factory.
G The ID number of the parameter.
H A short description of the values of the parameter
and/or its function.
AB298035655957en-000201 / DPD01083 | 11
