VACON® 100 FLOW
Application Guide
11.22.1.4 (ID 1713) Cleaning Current Delay
Location in the menu: P3.21.1.4
Use this parameter to set the time that the motor current must stay above the limit before the auto-cleaning starts.
Parameters P3.21.1.3 and P3.21.1.4 are used only when P3.21.1.1 = 2.
The cleaning sequence starts when the motor current goes above the current limit (P3.21.1.3) for longer than specified with
P3.21.1.4. The current limit is specified as a percentage of the motor nominal current.
11.22.1.5 (ID 1715) Cleaning Weekdays
Location in the menu: P3.21.1.5
Use this parameter to set the days of the week when the Auto-cleaning is executed. This parameter is used only when P3.21.1.1 = 3.
11.22.1.6 (ID 1700) Cleaning Time of Day
Location in the menu: P3.21.1.6
Use this parameter to set the time of the day when the Auto-cleaning is executed. This parameter is used only when P3.21.1.1 = 3.
A battery must be installed in the real-time clock.
11.22.1.7 (ID 1716) Cleaning Cycles
Location in the menu: P3.21.1.7
Use this parameter to set the number of forward or reverse cleaning cycles.
11.22.1.8 (ID 1717) Clean Forward Frequency
Location in the menu: P3.21.1.8
Use this parameter to set the frequency reference of the drive for the forward direction in the Auto-cleaning cycle.
Set the frequency and time of the cleaning cycle with the parameters P3.21.1.4, P3.21.1.5, P3.21.1.6, and P3.21.1.7.
11.22.1.9 (ID 1718) Clean Forward Time
Location in the menu: P3.21.1.9
Use this parameter to set the operation time for the forward direction frequency in the Autocleaning cycle. See parameter
(ID 1717) Clean Forward Frequency.
11.22.1.10 (ID 1719) Clean Reverse Frequency
Location in the menu: P3.21.1.10
Use this parameter to set the frequency reference of the drive for the reverse direction in the Auto-cleaning cycle. See parameter
11.22.1.8 (ID 1717) Clean Forward
11.22.1.11 (ID 1720) Clean Reverse Time
Location in the menu: P3.21.1.11
Use this parameter to set the operation time for the reverse direction frequency in the Autocleaning cycle. See parameter
(ID 1717) Clean Forward Frequency.
11.22.1.12 (ID 1721) Cleaning Acceleration Time
Location in the menu: P3.21.1.12
Use this parameter to set the motor acceleration time when the Auto-cleaning is active. It is possible to set acceleration and deceler-
ation ramps for the Auto-cleaning function with parameters P3.21.1.12 and P3.21.1.13.
11.22.1.13 (ID 1722) Cleaning Deceleration Time
Location in the menu: P3.21.1.13
Use this parameter to set the motor deceleration time when the Auto-cleaning is active. It is possible to set acceleration and decel-
eration ramps for the Auto-cleaning function with parameters P3.21.1.12 and P3.21.1.13.
Danfoss A/S © 2023.08
N O T I C E
Frequency.
Parameter Descriptions
AB298035655957en-000201 / DPD01083 | 275
11.22.1.8
11.22.1.8
