VACON® 100 FLOW
Application Guide
Index Parameter
P3.5.1.21 Preset Frequency Selection 0
P3.5.1.22 Preset Frequency Selection 1
P3.5.1.23 Preset Frequency Selection 2
P3.5.1.24 Motor Potentiometer UP
P3.5.1.25 Motor Potentiometer DOWN
P3.5.1.26 Quick Stop Activation
P3.5.1.27 Timer 1
P3.5.1.28 Timer 2
P3.5.1.29 Timer 3
P3.5.1.30 PID Setpoint Boost
P3.5.1.31 PID Select Setpoint
P3.5.1.32 External PID Start Signal
P3.5.1.33 External PID Select Setpoint
P3.5.1.34 Reset Maintenance Counter 1
P3.5.1.36 Flushing Reference Activation
P3.5.1.38 Fire Mode Activation OPEN
P3.5.1.39 Fire Mode Activation CLOSE
P3.5.1.40 Fire Mode Reverse
P3.5.1.41 Auto-cleaning Activation
P3.5.1.42 Pump 1 Interlock
P3.5.1.43 Pump 2 Interlock
96 | Danfoss A/S © 2023.08
Min Max Unit Default
DigIN SlotA.4
Varies
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
Varies
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
ID Description
(1)
419
420
(1)
421
418 OPEN = Not active
CLOSED = Active
417 OPEN = Not active
CLOSED = Active
1213 OPEN = Activated
447
448
449
1046 OPEN = No boost
CLOSED = Boost
(1)
1047 OPEN = Setpoint 1
CLOSED = Setpoint 2
1049 OPEN = PID2 in stop mode
CLOSED = PID2 regulating
1048 OPEN = Setpoint 1
CLOSED = Setpoint 2
490 CLOSED = Reset
(1)
530
1596 OPEN = Fire mode active
CLOSED = No action
1619 OPEN = No action
CLOSED = Fire Mode active
1618 OPEN = Forward
CLOSED = Reverse
1715
(1)
426 OPEN = Not active
CLOSED = Active
()
427 OPEN = Not active
CLOSED = Active
AB298035655957en-000201 / DPD01083
Parameters Menu
