Group 3.12: Timer Functions - Danfoss VACON 100 FLOW Series Application Manual

VACON® 100 FLOW
Application Guide
Index Parameter
P3.11.5 FUNCT Button Configuration
P3.11.6 Set ParamLock
P3.11.7 ParamLock Key
The default value in the US is 1.
1

6.12 Group 3.12: Timer Functions

Table 67: Interval 1
Index Parameter
P3.12.1.1 ON Time
P3.12.1.2 OFF Time
P3.12.1.3 Days
P3.12.1.4 Assign to Channel
Table 68: Interval 2
Index Parameter
P3.12.2.1 ON Time
P3.12.2.2 OFF Time
P3.12.2.3 Days
P3.12.2.4 Assign to Channel
110 | Danfoss A/S © 2023.08
Min Max
0 15
0 9999
0 9999
Min Max Unit
00:00:00 23:59:59 hh:mm:ss
00:00:00 23:59:59 hh:mm:ss
Min Max
00:00:00 23:59:59
00:00:00 23:59:59
Unit Default ID
15 1195
0 1807
0 1808
Default ID
00:00:00 1464
00:00:00 1465
1466
1468
Unit Default
hh:mm:ss 00:00:00
hh:mm:ss 00:00:00
AB298035655957en-000201 / DPD01083
Parameters Menu
Description
B0 = Local/Remote
B1 = Control Page
B2 = Change Direction
B3 = Quick Edit
Description
B0 = Sunday
B1 = Monday
B2 = Tuesday
B3 = Wednesday
B4 = Thursday
B5 = Friday
B6 = Saturday
B0 = Time channel 1
B1 = Time channel 2
B2 = Time channel 3
ID Description
1469 See Interval 1.
1470 See Interval 1.
1471 See Interval 1.
1473 See Interval 1.
