VACON® 100 FLOW
Application Guide
Index Parameter Min
P5.7.3 Menu Index
P5.7.4 Contrast 30
(1)
P5.7.5 Backlight 0
Time
Only available with the graphical keypad.
1

8.7 Fieldbus

In the I/O and Hardware menu, there are the parameters that are related to fieldbus boards. Find the instructions on how to use
these parameters in the related fieldbus manual.
Table 118: Fieldbus Menu Structure
Submenu level 1
RS-485
RS-485
RS-485
Danfoss A/S © 2023.08
Max Unit De- ID
fault
2499
70 % 50 830
60 min 5 818
Submenu level 2
Common settings
Modbus RTU
N2
Description
4 = Multimonitor
Set a page to be the menu index. (The selection 1 in P5.7.2.)
Set the contrast of the display.
Set the time after which the backlight of the display turns off. If the
value is set to 0, the backlight is always on.
Submenu level 3
Protocol
Parameters
Monitoring
Parameters
I/O and Hardware Menu
Submenu level 4
Modbus RTU
N2
BACnet MSTP
Slave address
Baud rate
Parity type
Stop bits
Communication timeout
Operate mode
Fieldbus protocol status
Communication status
Illegal functions
Illegal data addresses
Illegal data values
Slave device busy
Memory parity error
Slave device failure
Last fault response
Control Word
Status Word
Slave address
AB298035655957en-000201 / DPD01083 | 143
