VACON® 100 FLOW
Application Guide
Selection
Selection name
number
55
Multi-pump K7 control
56
Multi-pump K8 control
69
Selected parameter set
72
AHF Capacitor Disconnection
73
AHF Capacitor Disconnection
Inverted
74
Run Indication
75
Motor Switch Open
11.7.6.2 (ID 11002) RO1 ON Delay
Location in the menu: P3.5.3.2.2
Use this parameter to set the ON delay for the relay output.
11.7.6.3 (ID 11003) RO1 OFF Delay
Location in the menu: P3.5.3.2.3
Use this parameter to set the OFF delay for the relay output.
11.7.7 Analog Outputs
11.7.7.1 (ID 10050) AO1 Function
Location in the menu: P3.5.4.1.1
Use this parameter to select a function or a signal that is connected to the analog output. The contents of the analog output signal 1
are specified in this parameter. The scaling of the analog output signal depends on the signal.
Selection
Selection name
number
0
Test 0% (Not used)
1
TEST 100%
2
Output frequency
3
Frequency reference
4
Motor speed
5
Output current
6
Motor torque
7
Motor power
8
Motor voltage
9
DC link voltage
10
PID Setpoint
212 | Danfoss A/S © 2023.08
Description
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
Shows the active parameter set:
OPEN = Parameter set 1 active
CLOSED = Parameter set 2 active
The Motor Switch function has detected that the switch between the drive and
the motor is open.
Description
The analog output is set to 0% or 20% so that it agrees with parameter P3.5.4.1.3.
The analog output is set to 100% of the signal (10 V/20 mA).
The actual output frequency from 0 to Maximum frequency reference.
The actual frequency reference from 0 to Maximum frequency reference.
The actual motor speed from 0 to Motor nominal speed.
The output current of the drive from 0 to Motor nominal current.
The actual motor torque from 0 to motor nominal torque (100%).
The actual motor power from 0 to Motor nominal power (100%).
The actual motor voltage from 0 to Motor nominal voltage.
The actual DC link voltage 0...1000 V.
The actual setpoint value of the PID Controller (0...100%).
Parameter Descriptions
AB298035655957en-000201 / DPD01083
