VACON® 100 FLOW
Application Guide
Submenu level 1
Ethernet
Ethernet
Ethernet
Ethernet
For details, see VACON 100 Modbus User Manual.
1
For details, see VACON 100 BACnet Installation Manual.
2
For details, see VACON 100 EtherNet IP Installation Manual.
3
For details, see VACON 100 Profinet IO Installation Manual.
4

8.8 Fieldbus General

Enabling Ethernet Fieldbus Protocol
Needed internal Ethernet based fieldbus protocols can be enabled with parameters "Ethernet Fieldbus 1", 5.9.1.4 (ID 2622) and
"Ethernet Fieldbus 2", 5.9.1.5 (ID 2623). The parameters are included since VACON
V022 firmware.
Both parameters contain the same list with "PROFINET I/O, EtherNet/IP, BACnet/IP and Modbus TCP" protocols. PROFINET I/O and
EtherNet/IP are visible only if included in drive configuration. By default Modbus TCP is enabled, but if not used, it is recommended
to turn it off.
If the same fieldbus is selected to both parameters, the fieldbus protocol is still activated only once. Protocol specific menu tree
becomes visible only after enabling it from these parameters. When using VACON
Ethernet" menu tree must be reloaded after enabling the protocols.
When restoring parameters from older firmware version, drive checks on start-up which protocols were enabled in old firmware and
sets up these new parameters accordingly. After having restored parameters, restart the drive. If more than two Ethernet fieldbuses
were activated in old firmware, new firmware allows it. In this case, these two new parameters show "None", but when the values
are changed, all Ethernet fieldbuses are stopped, and only the enabled ones are started.
Table 119: Fieldbus Common Settings
Index Parameter
P5.9.1.4 Ethernet Field-
bus 1
P5.9.1.5 Ethernet Field-
bus 2
P5.9.1.6 IP Port Filter
P5.9.1.7 Drive PC Tool
Depends on fieldbuses included in drive configuration
1
Table 120: Fieldbus General
Index Parameter
P5.13.1 Controlling Fieldbus
V5.13.2 Controlling Fieldbus
Danfoss A/S © 2023.08
Submenu level 2
Modbus TCP
(1)
BACnet IP
(2)
EtherNet/IP
(3)
PROFINET I/O
(4)
Min Max Unit
None BACnet/
IP
(1)
None BACnet/
IP
(1)
0 65535
Configu- Disabled
ration
Min
Submenu level 3
MAC address
100 INDUSTRIAL V030 and VACON
®
Live, to see protocol specific menus, the "5.9
®
Default ID Description
None 2622 2 Ethernet-based internal fieldbuses can be
enabled at a time. Select fieldbus from the list.
Modbus 2623
TCP
0 2641 Use this parameter to block IP ports/protocols.
Configu- 2642 Use this parameter to block VACON
ration
over Ethernet, for example, VACON
Max Unit Default
I/O and Hardware Menu
Submenu level 4
100 FLOW
®
®
®
ID Description
2539
2610
AB298035655957en-000201 / DPD01083 | 145
PC Tools
Live.
