VACON® 100 FLOW
Application Guide
Selection num- Selection name
ber
0 Protection disabled
1 Protection enabled in RUN status
2 Protection enabled in RUN and STOP status
11.11.6.2 (ID 700) Analog Input Low Fault
Location in the menu: P3.9.8.2
Use this parameter to select the response of the drive to an 'AI Low' fault. If the analog input signal becomes less than 50% of the
minimum signal for 500 ms, an AI Low fault occurs.
If AI Low Protection is enabled with parameter P3.9.8.1, this parameter gives a response for the fault code 50 (Fault ID 1050).
The AI low protection function monitors the signal level of the analog inputs 1–6. If the analog input signal becomes less than 50%
of the minimum signal for 500 ms, an AI Low fault, or alarm shows.
It is possible to use the value Alarm + previous frequency only when using analog input 1 or analog input 2 as frequency refer-
ence.
Selection number Selection name
0 No Action
1 Alarm
2 Alarm, preset frequency
3 Alarm, previous frequency
4 Fault
5 Fault, coasting
11.12 Automatic Reset
11.12.1 (ID 731) Automatic Reset
Location in the menu: P3.10.1
Use this parameter to enable the Automatic reset function. To select the faults that are reset automatically, enter the value 0 or 1 to
parameters from P3.10.6 to P3.10.13.
The automatic reset function is available only for some fault types.
11.12.2 (ID 719) Restart Function
Location in the menu: P3.10.2
Use this parameter to select the start mode for the Automatic reset function.
11.12.3 (ID 717) Wait Time
Location in the menu: P3.10.3
Use this parameter to set the wait time before the first reset is done.
Danfoss A/S © 2023.08
Description
The protection is enabled only when the drive is in the RUN
status.
The protection is enabled in the 2 statuses, RUN, and STOP.
N O T I C E
Description
AI Low Protection is not used.
The frequency reference is set as in P3.9.1.13 Preset Alarm Frequency.
The last valid frequency is kept as frequency reference.
The drive stops as is set in P3.2.5 Stop Mode.
The drive stops by coasting.
N O T I C E
Parameter Descriptions
