VACON® 100 FLOW
Application Guide

5.6 Temperature Inputs

Table 16: Monitoring the Temperature Inputs
Index Monitoring value
V2.5.1 Temperature input 1
(1)
V2.5.2 Temperature input 2
(1)
V2.5.3 Temperature input 3
(1)
V2.5.4 Temperature input 4
(1)
V2.5.5 Temperature input 5
(1)
V2.5.6 Temperature input 6
(1)
This parameter group is visible with an option board for temperature measurement (OPTBH).
1

5.7 Extras and Advanced

Table 17: Monitoring of the Advanced Values
Index Monitoring value
V2.6.1 Drive Status Word
V2.6.2 Ready status
V2.6.3 Application Status Word1
Danfoss A/S © 2023.08
Unit
°C
°C
°C
°C
°C
°C
Unit Scale ID
1 43
1 78
1 89
Scale ID Description
0.1 50
0.1 51
0.1 52
0.1 69
0.1 70
0.1 71
Description
B1 = Ready
B2 = Run
B3 = Fault
B6 = Run Enable
B7 = Alarm Active
B10 = DC current in stop
B11 = DC brake active
B12 = Run Request
B13 = Motor Regulator Active
B15 = Brake Chopper Active
B0 = Run Enable high
B1 = No fault active
B2 = Charge switch closed
B3 = DC voltage OK
B4 = Power unit OK
B5 = Power unit is not blocking start
B6 = System software is not blocking start
B0 = Interlock 1
B1 = Interlock 2
B2 = Ramp 2 active
B3 = Reserved
B4 = I/O A control active
B5 = I/O B control active
B6 = Fieldbus Control Active
B7 = Local control active
B8 = PC control active
B9 = Preset frequencies active
B10 = Flushing active
B11 = Fire Mode active
AB298035655957en-000201 / DPD01083 | 79
Monitor Menu
