1.2 Card Interface
There is a card interface on right side of display unit. It can use compact flash (CF) card and USB memory.
1.2.1 Memory Card (Front IC Card) Interface
It can insert compact flash (CF) card.
It can input/output Machining program data.
It can edit machining program (text file) that is stored in memory card. Also, it can load machining program that is stored
in memory card.
1.2.2 USB Memory
It can insert USB memory.
It can input/output Machining program data.
It can edit machining program (text file) that is stored in USB memory, but it can not load machining program that is
stored in USB memory.
Operation item
Input/Output
Load
Edit
out Search of ladder.
○ : Can operate
1.2.3 Caution
(1) Do not take out CF card/USB memory when loading data.
(2) Take time (about more than 10 seconds)when inserting/removing it after power stared.
(3) To prevent trouble, do not remove or turn the power off when accessing to CF card/USB memory.
(4) Do not connect other than USB memory.
(5) Genuine CF card is recommended. There is a CF card only for Mitsubishi CNC. To buy this CF card, please contact
Mitsubiswhi Electric dealer. Using open market CF card/USB memory is not guaranteed, please check operation
sufficiently.
USB Memory
○
×
○
×
× : Can not operate
E70 Series Instruction Manual
CF Card
○
○
○
○
1.2 Card Interface
I - 5
