SSANGYONG Y200
3. After releasing nut (4 ea) of body of tail gate hinge,
remove tail gate from the body (proceed to remove
after removing head-lining).
Notice: In order for tail gate not to deflect, staff
technician should support tail gate.
YAD9C980
4. Install reverse order of removal.
Notice: High pressing nitrogen gas and oil is filled
in the gas lifter, as gas lifter is removed, to prevent
damage of (body of technician) and explosion,
make hole (diameter 3 mm) into gas lifter for
removal gas.
YAD9C990

TAIL GATE FLIP UP SYSTEM

Removal and Installation
1. Remove the upper garnish.
2. Separate wiring (2 ea) in the connector of heating
line of rear glass and wiring (1 ea) of stop lamp
(section of left spoiler).
YAD9C0A0
3. Using service tool, after opening up clip (4 ea) at
end of both gas lifter, remove gas lifter (right/left).
YAD9C0B0
BODY EXTERIOR 9C-33
