Page 13: Introduction
Switch by using the Web User Interface (Web UI). The Web UI is the secondary management interface to the DGS-3630 Series Switch, which will be generally be referred to simply as the “Switch” within this manual. This manual is written in a way that assumes that you already have the experience and knowledge of Ethernet and modern networking principles for Local Area Networks.
Page 14 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide CAUTION: A caution indicates a potential for property damage, personal injury, or death.
Page 15: Web-Based Switch Configuration
Alternatively, the Switch can also be managed, in-band, by using a Telnet connection to any of the LAN ports on the Switch. The command line interface provides complete access to all Switch management features. For more detailed information about the CLI, refer to the DGS-3630 Series CLI Reference Guide. SNMP-based Management The Switch can be managed with an SNMP-compatible Network Management System (NMS).
Page 16: Web User Interface (Web Ui)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 2-1 Displays entering the IP address in Internet Explorer After pressing the ENTER key, the following authentication window should appear, as shown below. Figure 2-2 Web UI Login Window When connecting to the Web UI of the Switch for the first time, leave the User Name and Password fields blank and click Login since there are no login user accounts created by default on the Switch.
Page 17 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide AREA 1 AREA 2 AREA 3 AREA 4 Figure 2-3 Main Web UI Window Area Number Description AREA 1 This area displays a graphical, near real-time image of the front panel of the Switch.
Page 18: System
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide System Device Information System Information Settings Peripheral Settings Port Configuration Loopback Test System Log Time and SNTP Time Range PTP (Precise Time Protocol) USB Console Settings Device Information In the Device Information section, the user can view a list of basic information regarding the Switch. It appears automatically when you log on to the Switch.
Page 19: Peripheral Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-2 System Information Settings Window The fields that can be configured in System Information Settings are described below: Parameter Description System Name Enter a system name for the Switch, if so desired. This name will identify it in the Switch network.
Page 20: Port Configuration
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-3 Peripheral Settings Window The fields that can be configured in Environment Trap Settings are described below: Parameter Description Fan Trap Select to enable or disable the fan trap state for waning fan event (fan failed or fan recover).
Page 21 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-4 Port Settings Window The fields that can be configured are described below: Parameter Description Unit Select the stacking unit ID of the Switch that will be configured here.
Page 22: Port Status
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Slave, and 10G. The Master setting will allow the port to advertise capabilities related to duplex, speed and physical layer type. The master setting will also determine the master and slave relationship between the two connected physical layers.
Page 23: Port Gbic
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-5 Port Status Window The fields that can be configured are described below: Parameter Description Unit Select the stacking unit ID of the Switch that will be displayed here.
Page 24: Error Disable Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click System > Port Configuration > Port Auto Negotiation, as shown below: Figure 3-7 Port Auto Negotiation Window The fields that can be configured are described below:...
Page 25: Jumbo Frame
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Asserted Specifies to enable or disable notifications for entering into the error disabled state. Cleared Specifies to enable or disable notifications for exiting from the error disabled state.
Page 26: Loopback Test
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Maximum Receive Frame Enter the maximum receive frame size value here. This value must be between Size 64 and 12288 bytes. By default, this value is 1536 bytes.
Page 27: System Log
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. System Log System Log Settings This window is used to display and configure the system log settings. To view the following window, click System > System Log > System Log Settings, as shown below:...
Page 28: System Log Discriminator Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description interfaces this value is from 1 to 4094. Click the Apply button to accept the changes made. The fields that can be configured for Buffer Log Settings are described below:...
Page 29: System Log Server Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-12 System Log Discriminator Settings Window The fields that can be configured are described below: Parameter Description Discriminator Name Enter the name of the discriminator profile here. This name can be up to 15 characters long.
Page 30 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Host IPv4 Address Enter the system log server IPv4 address here. Host IPv6 Address Enter the system log server IPv6 address here.
Page 31: System Log
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide System Log This window is used to view and clear the system log. To view the following window, click System > System Log > System Log, as shown below: Figure 3-14 System Log Window Click the Clear Log button to clear the system log entries displayed in the table.
Page 32: Time And Sntp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Time and SNTP Clock Settings This window is used to display and configure the time settings for the Switch. To view the following window, click System > Time and SNTP > Clock Settings, as shown below:...
Page 33 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-17 Time Zone Settings Window The fields that can be configured are described below: Parameter Description Summer Time State Select the summer time setting. Options to choose from are Disabled, Recurring Setting, and Date Setting.
Page 34: Sntp Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description To: Week of the Month Select week of the month that summer time will end. To: Day of the Week Select the day of the week that summer time will end.
Page 35: Time Range
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description SNTP State Select this option to enable or disable SNTP. Poll Interval Enter the synchronizing interval in seconds. The value is from 30 to 99999 seconds. The default interval is 720 seconds.
Page 36: Ptp (Precise Time Protocol)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Delete Periodic button to delete the periodic entry. Click the Delete button to delete the specified entry.
Page 37 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description delay of the link. The link, in this case, is connected to the port that is receiving the PTP event messages. Ports on peer-to-peer transparent clocks use the peer delay mechanism to calculate the propagation delay between PTP ports.
Page 38: Ptp Port Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide PTP Port Global Settings This window is used to display and configure the PTP interface settings. To view the following window, click System > PTP (Precise Time Protocol) > PTP Port Global Settings, as shown...
Page 39 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-22 PTP Boundary Port Settings Window The fields that can be configured are described below: Parameter Description Select the Switch unit that will be used for this configuration here.
Page 40: Ptp P2P Transparent Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description 1588 protocol, this value must be represented as the logarithm to the base of 2 of this time, measured in seconds. The range is from 1 to 2 seconds. Select the Half Second option to set 0.5 seconds as this value.
Page 41: Ptp Port Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-24 PTP Clock Information Window The fields that can be configured are described below: Parameter Description Select the Switch unit that will be used here. Unit PTP Port Information This window is used to view PTP port information.
Page 42: Ptp Foreign Master Records Port Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used here. PTP Foreign Master Records Port Information This window is used to view PTP Foreign Master Records port information.
Page 43: Srm
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The Switch Resource Management (SRM) feature provides a large number of resources that can be distributed and optimized as needed by applications. It provides resource configuration flexibility that allows users to allocate more resources for tables that require more entries and prevents wasting resources on unused functions.
Page 44 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 3-29 SRM Prefer Mode Window The fields that can be configured are described below: Parameter Description SRM Prefer Mode Select the SRM prefer mode that will be used in the display here. Options to choose from are LAN, IP, and L2VPN.
Page 45: Management
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Management Command Logging User Accounts Settings Password Encryption Password Recovery Login Method SNMP RMON Telnet/Web Session Timeout DHCP DHCP Auto Configuration DHCP Auto Image Settings IP Source Interface File System...
Page 46 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: By default, there are no user accounts created on the Switch. To view the following window, click Management > User Accounts Settings, as shown below: After selecting the User Management Settings tab, the following page will appear.
Page 47: Password Encryption
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Password Encryption This window is used to display and configure whether to save the encryption of the password in the configuration file. To view the following window, click Management > Password Encryption, as shown below:...
Page 48: Login Method
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Login Method This window is used to display and configure the login method for each management interface that is supported by the Switch. To view the following window, click Management > Login Method, as shown below:...
Page 49: Snmp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Login Local requires the user to enter a username and a password to access the specified application. Click the Apply button to accept the changes made.
Page 50: Snmp Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide to view read-only information or receive traps using SNMPv1 while assigning a higher level of security to another group, granting read/write privileges using SNMPv3. Using SNMPv3, users or groups can be allowed or be prevented from performing specific SNMP management functions.
Page 51: Snmp Linkchange Trap Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description SNMP UDP Port Enter the SNMP UDP port number. Trap Source Interface Enter the interface whose IP address will be used as the source address for sending the SNMP trap packet.
Page 52: Snmp View Table Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description From Port - To Port Select the appropriate port range used for the configuration here. Trap Sending Select this option to enable or disable the sending of the SNMP notification traps that are generated by the system.
Page 53: Snmp Community Table Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide SNMP Community Table Settings This window is used to create an SNMP community string to define the relationship between the SNMP manager and an agent. The community string acts like a password to permit access to the agent on the Switch. One or more of the following characteristics can be associated with the community string: •...
Page 54: Snmp Group Table Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide SNMP Group Table Settings An SNMP group created with this table maps SNMP users to the views created in the SNMP View Table Settings window. To view the following window, click Management > SNMP > SNMP Group Table Settings, as shown below:...
Page 55: Snmp Engine Id Local Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide SNMP Engine ID Local Settings The Engine ID is a unique identifier used for SNMPv3 implementations on the Switch. To view the following window, click Management > SNMP > SNMP Engine ID Local Settings, as shown below:...
Page 56: Snmp Host Table Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description SNMP Version Select the SNMP version. Options to choose from are v1, v2c, and v3. SNMP V3 Encryption When selecting v3 in the SNMP Version drop-down list, this option is available.
Page 57: Snmp Context Mapping Table Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-14 SNMP Host Table Settings Window The fields that can be configured are described below: Parameter Description Host IPv4 Address Enter the IPv4 address of the SNMP notification host.
Page 58: Rmon
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Management > SNMP > SNMP Context Mapping Table Settings, as shown below: Figure 4-15 SNMP Context Mapping Table Settings Window The fields that can be configured are described below:...
Page 59: Rmon Statistics Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide RMON Statistics Settings This window is used to display and configure the RMON statistics on the specified port. To view the following window, click Management > RMON > RMON Statistics Settings, as shown below:...
Page 60: Rmon Alarm Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-19 RMON History Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 61: Rmon Event Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-21 RMON Alarm Settings Window The fields that can be configured are described below: Parameter Description Index Enter the alarm index. The range is from 1 to 65535.
Page 62: Telnet/Web
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-22 RMON Event Settings Window The fields that can be configured are described below: Parameter Description Index Enter the index value of the alarm entry here. The range is from 1 to 65535.
Page 63: Session Timeout
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-24 Telnet/Web Window The fields that can be configured in Telnet Settings are described below: Parameter Description Telnet State Select to enable or disable the Telnet server feature here.
Page 64: Dhcp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-25 Session Timeout Window The fields that can be configured are described below: Parameter Description Web Session Timeout Enter the time in seconds of the web session timeout. Tick the Default check box to return to the default setting.
Page 65: Dhcp Class Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Service IPv6 DHCP State Select this option to enable or disable the IPv6 DHCP Relay service. Click the Apply button to accept the changes made. DHCP Class Settings This window is used to display and configure the DHCP class and the DHCP option matching pattern for the DHCP class.
Page 66: Dhcp Server
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description match the remaining bits of the option. Bitmask Enter the hex bit mask for masking of the pattern. The masked pattern bits will be matched. If not specified, all bits entered in the Hex field will be checked.
Page 67: Dhcp Server Pool Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description DHCP Ping Packet Enter the number of ping packets that the Switch will send out on the network containing the IP address to be allotted. If the ping request is not returned, the IP address is considered unique to the local network and then allotted to the requesting client.
Page 68 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-31 DHCP Server Pool Settings (Edit Class) Window The fields that can be configured are described below: Parameter Description Class Name Select an existing DHCP class name here that will be associated with this DHCP pool.
Page 69 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description entered. Click the Apply button to accept the changes made. Click the Delete button to remove the specified entry. Click the Back button to return to the previous window.
Page 70: Dhcp Server Manual Binding
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description system uses broadcasts. A Peer To Peer (p-node) system uses only point-to- point name queries to a name server (WINS). A Mixed (m-node) system broadcasts first, and then queries the name server. A Hybrid (h-node) system queries the name server first, and then broadcasts.
Page 71: Dhcp Server Dynamic Binding
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-35 DHCP Server Manual Binding Window The fields that can be configured are described below: Parameter Description Pool Name Enter the DHCP server pool name here. This name can be up to 32 characters long.
Page 72 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Clear button to clear the entries based on the information specified. DHCP Server IP Conflict This window is used to view and clear the DHCP conflict entries from the DHCP server database.
Page 73: Dhcpv6 Server
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-38 DHCP Server Statistic Window Click the Clear button to clear the statistics information displayed here. DHCPv6 Server DHCPv6 Server Pool Settings This window is used to display and configure the DHCPv6 server pool settings.
Page 74 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Configure button, the following page will appear.
Page 75 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description preferred lifetime. The range is from 60 to 4294967295 seconds. By default, this value is 2592000 seconds (30 days). Preferred Lifetime Enter the preferred lifetime value here. The range is from 60 to 4294967295 seconds.
Page 76: Dhcpv6 Server Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Management > DHCP > DHCPv6 Server > DHCPv6 Server Exclude Address, as shown below: Figure 4-42 DHCPv6 Server Exclude Address Window The fields that can be configured are described below:...
Page 77: Dhcp Relay
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Management > DHCP > DHCPv6 Server > DHCPv6 Server Interface Settings, as shown below: Figure 4-44 DHCPv6 Server Interface Settings Window The fields that can be configured are described below:...
Page 78 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-46 DHCP Relay Global Settings Window The fields that can be configured are described below: Parameter Description DHCP Relay Unicast State Select to globally enable or disable the DHCP relay unicast state here.
Page 79 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Source IP Address Enter the source subnet of client packets. Enter the network mask of the source subnet.
Page 80 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Class Name Select the DHCP class name. Click the Apply button to accept the changes made. Click the Edit button to edit more information. Click the Delete button to remove the specified entry.
Page 81 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-52 DHCP Relay Information Settings Window The fields that can be configured are described below: Parameter Description Information Trust All Select this option to enable or disable the DHCP relay agent to trust the IP DHCP relay information for all interfaces.
Page 82 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-53 DHCP Relay Information Option Format Settings Window The fields that can be configured in DHCP Relay Information Option Format Global are described below: Parameter Description Select the DHCP information remote ID sub-option. Options to choose from are Information Format Remote Default, User Define, and Vendor2.
Page 83 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. DHCP Relay Information Profile Settings This window is used to display and configure the DHCP relay information profile settings. To view the following window, click Management > DHCP > DHCP Relay > DHCP Relay Information Profile...
Page 84 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Profile Name Enter the Option 82 profile name here. The profile can be used to define the flexible, user-defined Option 82 entry. Format String After clicking the Edit button, enter the user-defined DHCP Option 82 format string here.
Page 85 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description string or a hexadecimal value.  svlan - Indicates the outer VLAN ID. This can be either an ASCII string or a hexadecimal value.  cvlan - Indicates the inner VLAN ID. This can be either an ASCII string or a hexadecimal value.
Page 86: Dhcpv6 Relay
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description State Select to enable or disable the DHCP Relay feature on the specified port(s). Click the Apply button to accept the changes made. DHCP Local Relay VLAN This window is used to display and configure local relay on a VLAN or a group of VLANs.
Page 87 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-57 DHCPv6 Relay Global Settings Window The fields that can be configured in DHCPv6 Relay Remote ID Settings are described below: Parameter Description IPv6 DHCP Relay Remote Select the IPv6 DHCP Relay remote ID format that will be used here. Options to ID Format choose from are Default, CID with User Define, User Define, and Expert UDF.
Page 88: Dhcpv6 Relay Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Keep - Specifies that the DHCPv6 request packets that already contain the relay agent interface ID option are left unchanged and directly relay to the DHCPv6 server.
Page 89 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-58 DHCPv6 Relay Interface Settings Window The fields that can be configured are described below: Parameter Description Interface VLAN Enter the interface VLAN ID used in the DHCPv6 relay here. The range is from 1 to 4094.
Page 90 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description The following rules need to be considered: • This string can be a hexadecimal value, an ASCII string, or any combination of hexadecimal values and ASCII characters. An ASCII string needs to be enclosed with quotation marks (“”) like “Ethernet”.
Page 91 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description string or a hexadecimal value. ○ : - Indicates the end of the formatted key sting. If a formatted key string is the last parameter of the command, its ending character (“:”) can be ignored.
Page 92 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description “keyword”+“:”: ○ % - Indicates that the string that follows this character is a formatted key string. ○ “$” or “0” - (Optional) Indicates a fill indicator. This option specifies how to fill the formatted key string to meet the length option.
Page 93 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description “\%” is “%” itself, not the start indicator of a formatted key string. Spaces not in the formatted key string will also be encapsulated. • Hexadecimal values can be any combination of formatted key strings and 0~9, A~F, a~f, and space characters.
Page 94 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide DHCPv6 Relay Port Settings This window is used to display and configure the DHCPv6 relay port settings. To view the following window, click Management > DHCP > DHCPv6 Relay > DHCPv6 Relay Port Settings, as...
Page 95: Dhcp Auto Configuration
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description State Select to enable or disable the DHCPv6 local relay feature on the specified VLAN(s) here. Click the Apply button to accept the changes made. NOTE: When the state of the DHCPv6 relay port is disabled, the port will not relay or locally relay received DHCPv6 packets.
Page 96: Dns
RFC 2132. When specifying the image file name, the DHCP Option 125 (RFC 3925) must be used. The Switch needs to check the enterprise-number1 field. If the value is not the D-Link vendor ID (171), the Switch will stop the process.
Page 97: Dns Name Server Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description IP DNS Lookup Static State Select to enable or disable the IP DNS lookup static state here. IP DNS Lookup Cache State Select to enable or disable the IP DNS lookup cache state here.
Page 98: Dns Host Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide DNS Host Settings This window is used to display and configure the static mapping entry for the host name and the IP address in the host table. To view the following window, click Management > DNS > DNS Host Settings, as shown below:...
Page 99 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-69 NTP Global Settings Window The fields that can be configured in NTP State are described below: Parameter Description NTP State Select to globally enable or disable the NTP feature here.
Page 100: Ntp Server Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NTP Server Settings This window is used to display and configure the NTP server settings. This is used to enable the Switch to synchronize time with an NTP server.
Page 101: Ntp Access Group Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-71 NTP Peer Settings Window The fields that can be configured are described below: Parameter Description IP Address Select and enter the IPv4 address of the NTP peer here.
Page 102: Ntp Key Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-72 NTP Access Group Settings Window The fields that can be configured are described below: Parameter Description Default Select this option to specify to use the default IPv4 (0.0.0.0/0.0.0.0) or IPv6 (::/::) address.
Page 103: Ntp Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-73 NTP Key Settings Window The fields that can be configured in NTP Control Key are described below: Parameter Description NTP Control Key Enter the NTP control key here. This is used to define the key ID for the NTP control messages.
Page 104: Ntp Associations
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Management > NTP > NTP Interface Settings, as shown below: Figure 4-74 NTP Interface Settings Window The fields that can be configured are described below:...
Page 105: Ntp Status
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-76 NTP Associations (Show Detail) Window NTP Status This window is used to view NTP status information. To view the following window, click Management > NTP > NTP Status, as shown below:...
Page 106 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-78 IP Source Interface Window The fields that can be configured in IP TFTP Source Interface are described below: Parameter Description Source Interface State Select to enable or disable the IP TFTP source interface state here.
Page 107: File System
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide File System This window is used to view, manage and configure the Switch file system. To view the following window, click Management > File System, as shown below: Figure 4-79 File System Window...
Page 108: Stacking
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: If the boot configuration file is damaged, the Switch will automatically revert back to the default configuration. NOTE: If the boot image file is damaged, the Switch will automatically use the backup image file in the next boot up.
Page 109 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Switches in the series can be physically stacked using optical fiber cables connected to SFP+ transceivers or Direct Attached Cables (DAC) with SFP+ connectors. Only the last 4 ports can be used for physical stacking.
Page 110 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The figure below illustrates how Switches can be stacked in a Duplex Ring formation using optical fiber cables connected to SFP+ transceivers or DAC with SFP+ connectors where the 2-port stacking configuration is used.
Page 111 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Primary Master - The Primary Master is the leader of the stack. It will maintain normal operations, monitor operations and the running topology of the Stack. This Switch will also assign Stack Unit IDs, synchronize configurations and transmit commands to remaining Switches in the Switch stack.
Page 112: Physical Stacking
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide databases, such as ARP, will also be cleared. Then the Backup Master will begin backing up the Primary Master when the database synchronization has been completed by the stack.
Page 113: Stacking Bandwidth
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Trap State Select this option to enable or disable stacking related SNMP traps. Click the Apply button to accept the changes made. The fields that can be configured in Stack ID are described below:...
Page 114: Virtual Stacking (Sim)
Click the Apply button to accept the changes made. Virtual Stacking (SIM) D-Link Single IP Management (SIM) is a concept that will stack Switches together over Ethernet instead of using stacking ports or modules. There are some advantages in implementing the Single IP Management feature: •...
Page 115 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The SIM group is a group of Switches that are managed as a single entity. The Switch may take on three different roles: 1. Commander Switch (CS) - This is a Switch that has been manually configured as the controlling device for a group, and takes on the following characteristics: ...
Page 116: Single Ip Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The topology map now includes new features for connections that are a member of a port trunking group. It will display the speed and number of Ethernet connections creating this port trunk group.
Page 117: Topology
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description for SIM. Group Name Enter a group name. This is optional. This name is used to segment Switches into different SIM groups. Click the Apply button to accept the changes made.
Page 118 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-87 Topology Window The fields that can be configured are described below: Parameter Description Device Name Display the Device Name of the Switches in the SIM group configured by the user.
Page 119 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-88 Topology View This window will display how the devices within the Single IP Management Group connect to other groups and devices. Possible icons on this window are as follows:...
Page 120 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-89 Device Information Utilizing the Tool Tip Setting the mouse cursor over a line between two devices will display the connection speed between the two devices, as shown below.
Page 121 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-91 Right-Clicking a Group Icon The following options may appear for the user to configure: • Collapse - To collapse the group that will be represented by a single icon.
Page 122 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Close button to close the property window. Commander Switch Icon Figure 4-93 Right-clicking a Commander Icon The following options may appear for the user to configure: • Collapse - To collapse the group that will be represented by a single icon.
Page 123 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide • Add to group - Add a candidate to a group. Clicking this option will reveal the following dialog box for the user to enter a password for authentication from the Candidate Switch before being added to the SIM group. Click OK to enter the password or Cancel to exit the dialog box.
Page 124: Firmware Upgrade
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-99 About Window Firmware Upgrade This window is used to view and upgrade firmware from the Commander Switch to the Member Switch. Member Switches will be listed in the table.
Page 125: Upload Log File
Click the Upload button to initiate the file transfer. D-Link Discovery Protocol This window is used to display and configure the D-Link Discovery Protocol (DDP) settings. To view the following window, click Management > D-Link Discovery Protocol, as shown below:...
Page 126: Smtp Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-103 D-Link Discovery Protocol Window The fields that can be configured in D-Link Discovery Protocol are described below: Parameter Description Select to globally enable or disable the DDP feature here.
Page 127 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-104 SMTP Settings Window The fields that can be configured in SMTP Global Settings are described below: Parameter Description SMTP IP Select the SMTP server IP address type here. Options to choose from are IPv4 and IPv6.
Page 128: Reboot Schedule Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description characters long. Click the Add button to add a new SMTP email recipient. The fields that can be configured in Send a Test Mail to All are described below:...
Page 129: Nlb Fdb Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Delete button to remove the specified reboot schedule. NLB FDB Settings This window is used to display and configure the Network Load Balancing (NLB) FDB settings. The Network Load Balancing (NLB) function is used to support the Microsoft server load balancing application where multiple servers can share the same IP address and MAC address.
Page 130: Sd Card Management
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide SD Card Management This section refers to the configuration associated with removable devices which includes USB driver storage. SD Card Backup Settings This window is used to display and configure the SD card backup settings. This is used to create or modify an SD card management backup schedule entry.
Page 131 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 4-108 SD Card Execute Settings Window The fields that can be configured in Execute Configuration are described below: Parameter Description File URL Enter the URL of the file here. If the current directory is not the directory of SD card file system, then the full file path must be entered.
Page 132: Layer 2 Features
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Layer 2 Features VLAN VLAN Tunnel ERPS (G.8032) Loopback Detection Link Aggregation Flex Links L2 Protocol Tunnel L2 Multicast Control LLDP Static FDB Unicast Static FDB This window is used to display and configure the static unicast forwarding settings on the Switch.
Page 133: Mac Address Table Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Multicast Static FDB This window is used to display and configure the multicast static FDB settings. To view the following window, click L2 Features > FDB > Static FDB > Multicast Static FDB, as shown below:...
Page 134 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description value is 300 seconds. Aging Destination Hit Select to enable or disable the aging destination hit function. Click the Apply button to accept the changes made. After selecting the MAC Address Port Learning Settings tab option, at the top of the page, the following page will be available.
Page 135: Mac Address Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description VID List Enter the VLAN ID(s) that will be used in this configuration or display here. A series of VLAN IDs can be entered separated by commas or a range of VLAN IDs can be entered separated by a hyphen.
Page 136: Mac Notification
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Clear All button to clear all dynamic MAC addresses. Click the Show All button to display all the MAC addresses recorded in the MAC address table.
Page 137: Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made for each individual section. After selecting the MAC Notification History tab, at the top of the page, the following page will be available.
Page 138: 802.1V Protocol Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Delete button to remove the specific entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. 802.1v Protocol VLAN Protocol VLAN Profile This window is used to display and configure 802.1v protocol VLAN profiles.
Page 139: Gvrp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-11 Protocol VLAN Profile Interface Window The fields that can be configured are described below: Parameter Description Select the stacking unit ID and the port number of the Switch that will be Port configured here.
Page 140: Gvrp Port
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide GVRP Port This window is used to display and configure the GVRP port settings. To view the following window, click L2 Features > VLAN > GVRP > GVRP Port, as shown below:...
Page 141 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-14 GVRP Advertise VLAN Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 142: Asymmetric Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description From Port - To Port Select the range of ports that will be used for this configuration here. Action Select the forbidden VLAN to port mapping action that will be taken here. Options to choose from are All, Add, and Remove.
Page 143: Mac Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-17 Asymmetric VLAN Window The fields that can be configured are described below: Parameter Description Asymmetric VLAN State Select to enable or disable the asymmetric VLAN feature here.
Page 144 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-19 VLAN Interface Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 145 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-21 VLAN Interface (Access) Window The fields that can be configured are described below: Parameter Description Select the VLAN mode option here. Options to choose from are Access, Hybrid, VLAN Mode Trunk, 802.1Q-Tunnel, Promiscuous, Host, Trunk Promiscuous, and Trunk...
Page 146 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Secondary. Acceptable Frame Select the acceptable frame behavior option here. Options to choose from are Tagged Only, Untagged Only, and Admit All. Ingress Checking Select to enable or disable the ingress checking function.
Page 147 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description After ticking the Native VLAN option the following parameter will be available. Enter the VLAN ID used for this configuration here. This value must be between 1 and 4094.
Page 148 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Back button to discard the changes made and return to the previous page. When Promiscuous was selected as the VLAN Mode, the following page will appear.
Page 149 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Clone Select this option to enable the clone feature. From Port - To Port Select the range of ports that will be used in the clone feature here.
Page 150: L2Vlan Interface Description
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-28 VLAN Interface (Trunk Secondary) Window The fields that can be configured are described below: Parameter Description VLAN Mode Select the VLAN mode option here. Options to choose from are Access, Hybrid, Trunk, 802.1Q-Tunnel, Promiscuous, Host, Trunk Promiscuous, and Trunk...
Page 151: Subnet Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-29 L2VLAN Interface Description Window The fields that can be configured are described below: Parameter Description L2VLAN Interface Enter the ID of the Layer 2 VLAN interface here.
Page 152: Super Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Length here. IPv6 Network Prefix / Prefix Select and enter the IPv6 address and prefix length value for the subnet VLAN Length here. Enter the VLAN ID for the subnet VLAN here.
Page 153: Auto Surveillance Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. The fields that can be configured in Find Super VLAN are described below: Parameter Description Super VID Enter the super VLAN ID that will be displayed here. The range is from 1 to 4094.
Page 154 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-33 Auto Surveillance Properties Window The fields that can be configured in Global Settings are described below: Parameter Description Surveillance VLAN Select to enable or disable the surveillance VLAN feature here.
Page 155 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. MAC Settings and Surveillance Device This window is used to display and configure surveillance devices and their MAC settings. To view the following window, click L2 Features > VLAN > Auto Surveillance VLAN > MAC Settings and...
Page 156: Voice Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-35 MAC Settings and Surveillance Device (Auto Surveillance VLAN Summary) Window The fields that can be configured are described below: Parameter Description Unit Select the stacking unit ID of the Switch that will be used in this display here.
Page 157 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Voice VLAN Port This window is used to display and configure the voice VLAN interface settings. To view the following window, click L2 Features > VLAN > Voice VLAN > Voice VLAN Port, as shown below:...
Page 158: Voice Vlan Oui
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Voice VLAN OUI This window is used to display and configure the voice VLAN OUI settings. Use this window to add a user-defined OUI for the voice VLAN. The OUI for the voice VLAN is used to identify the voice traffic by using the voice VLAN function.
Page 159: Private Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used in this display here. Voice VLAN LLDP-MED Device This window is used to view the voice VLAN LLDP-MED device table.
Page 160: Vlan Tunnel
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Type Select the type of private VLAN that will be created here. Options to choose from are Community, Isolated, and Primary. Click the Apply button to accept the changes made.
Page 161 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Only configure the 802.1Q tunneling Ethernet type on ports that are connected to the provider bridge network, which receives and transmits the service VLAN tagged frames. If the tunnel Ethernet type is configured, the specified value will be the Tag Protocol ID (TPID) in the outer VLAN tag of the transmitted frames of the port.
Page 162: Vlan Mapping
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-43 Dot1q Tunnel Settings (Dot1q Tunnel Port Settings) Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit ID that will be used here.
Page 163: Vlan Mapping Profile
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-44 VLAN Mapping Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit ID that will be used here. From Port - To Port Select the port range that will be used here.
Page 164 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-45 VLAN Mapping Profile Window The fields that can be configured are described below: Parameter Description Profile ID Enter the ID of the VLAN mapping profile here. A lower ID has a higher priority.
Page 165 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-46 VLAN Mapping Profile (Ethernet, Add Rule) Window The fields that can be configured are described below: Parameter Description Rule ID Enter the VLAN mapping rule ID here. If not specified, the rule ID begins from 10 and is incremented by 10 for every new rule.
Page 166 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-47 VLAN Mapping Profile (IP, Add Rule) Window The fields that can be configured are described below: Parameter Description Rule ID Enter the VLAN mapping rule ID here. If not specified, the rule ID begins from 10 and is incremented by 10 for every new rule.
Page 167 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-48 VLAN Mapping Profile (IPv6, Add Rule) Window The fields that can be configured are described below: Parameter Description Enter the VLAN mapping rule ID here. If not specified, the rule ID begins from 10 Rule ID and is incremented by 10 for every new rule.
Page 168 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-49 VLAN Mapping Profile (Ethernet-IP, Add Rule) Window The fields that can be configured are described below: Parameter Description Enter the VLAN mapping rule ID here. If not specified, the rule ID begins from 10 Rule ID and is incremented by 10 for every new rule.
Page 169: Stp
However, as IEEE 802.1D-2004 RSTP and IEEE 802.1Q-2005 MSTP have been recently introduced to D-Link managed Ethernet Switches, a brief introduction to the technology is provided below followed by a description of how to set up IEEE 802.1D-1998 STP, IEEE 802.1D-2004 RSTP, and IEEE 802.1Q-2005 MSTP.
Page 170 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide version compatible with IEEE 802.1D-1998. RSTP can operate with legacy equipment implementing IEEE 802.1D- 1998, however the advantages of using RSTP will be lost. This section introduces some new Spanning Tree concepts and illustrates the main differences between the two protocols.
Page 171: Stp Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide STP Global Settings This window is used to display and configure the global STP settings. To view the following window, click L2 Features > STP > STP Global Settings, as shown below:...
Page 172: Stp Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description this value is 32768. The lower the value, the higher the priority. Click the Apply button to accept the changes made. The fields that can be configured for STP Configuration are described below:...
Page 173 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-51 STP Port Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 174: Mst Configuration Identification
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description option is Disabled. BPDU Forward Select to enable or disable BPDU forwarding. If enabled, the received STP BPDU will be forwarded to all VLAN member ports in the untagged form. By default, this option is Disabled.
Page 175: Stp Instance
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured for MST Configuration Identification are described below: Parameter Description Configuration Name Enter the MST. This name uniquely identifies the MSTI (Multiple Spanning Tree Instance).
Page 176: Mstp Port Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Edit button to re-configure the specific entry. Click the Apply button to accept the changes made. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 177 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: Be aware that changing the ERPS version will lead to the restart of the running protocol. To view the following window, click L2 Features > ERPS (G.8032) > ERPS, as shown below:...
Page 178 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in Ethernet Ring G.8032 are described below: Parameter Description Ring Name Enter the Ethernet Ring Protection (ERP) instance name here. This name can be up to 32 characters long.
Page 179 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to discard the changes made and return to the previous window. Click the Apply button to accept the changes made. After click the Show Detail button, the following window will appear.
Page 180 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-59 ERPS (ERPS Brief, Edit Instance) Window The fields that can be configured are described below: Parameter Description Description Select the checkbox and enter the ERP instance description here. This description can be up to 64 characters long.
Page 181: Erps Profile
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description active this ERP instance. Sub Ring Instance Select the checkbox and enter the identifier of the ERP instance here. This is used to specify the sub-ring instance of a physical ring instance. The range is from 1 to 32.
Page 182: Loopback Detection
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-61 ERPS Profile (Edit) Window The fields that can be configured are described below: Parameter Description TCN Propagation Select the checkbox and then select the TCN propagation state. Options to choose from are Enable and Disabled.
Page 183 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-62 Loopback Detection Window The fields that can be configured in Loopback Detection Global Settings are described below: Parameter Description Select to enable or disable loopback detection. The default is Disabled.
Page 184: Link Aggregation
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Link Aggregation Understanding Port Trunk Groups Port trunk groups are used to combine a number of ports together to make a single high-bandwidth data pipeline. The Switch supports up to 32 port trunk groups with up to 12 ports in each group.
Page 185 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-64 Link Aggregation Window The fields that can be configured for Link Aggregation are described below: Parameter Description System Priority Enter the system priority value used here. This value must be between 1 and 65535.
Page 186: Flex Links
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-65 Link Aggregation (Channel Detail) Window The fields that can be configured are described below: Parameter Description Description Enter the description for the port channel here. This string can be up to 64 characters long.
Page 187: L2 Protocol Tunnel
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-66 L2 Flex Links Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit of the primary port here. Primary Port Select the primary port here.
Page 188 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description By default, this value is 0. The tunneling of the Layer 2 protocol packets will consume CPU processing power in encapsulating, decapsulating, and forwarding of the packet. Use this option to restrict the CPU processing bandwidth consumed by specifying a threshold on the number of all Layer 2 protocol packets that can be processed by the system.
Page 189: L2 Multicast Control
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description from are 01-00-0C-CC-CC-CC and 01-00-0C-CC-CC-CD. Threshold After selecting the Shutdown or Drop option in the Type field, the following parameter will be available. Enter the threshold value here. This value must be between 1 and 4096.
Page 190 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Enter a VLAN ID from 1 to 4094, and select to enable or disable IGMP snooping on the VLAN. Click the Apply button to accept the changes made.
Page 191 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-71 IGMP Snooping Settings (Modify, Edit) Window The fields that can be configured are described below: Parameter Description Minimum Version Select the minimum IGMP host version that is allowed on the VLAN. Options to choose from are 1, 2, and 3.
Page 192 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Rate Limit Enter the rate limit value here. The range is from 1 to 1000. Tick the No Limit option to apply no rate limit on this profile.
Page 193 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping Groups Settings, as shown below: Figure 5-73 IGMP Snooping Groups Settings Window...
Page 194 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IGMP Snooping Filter Settings This window is used to display and configure the IGMP snooping filter settings. To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping Filter...
Page 195 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. From Port - To Port Select the appropriate port range used for the configuration here.
Page 196 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Please Select button, the following page will appear. Figure 5-75 IGMP Snooping Filter Settings (Please Select) Window Select the ACL and click the OK button to use the selected access list.
Page 197 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Enter the VLAN ID used here. The range is from 1 to 4094. Configuration Select the port configuration. Options to choose from are Port, and Forbidden Port.
Page 198: Mld Snooping
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description when Port is selected in the Statistics drop-down list. From Port - To Port Select the appropriate port range used for the configuration here. This is available when Port is selected in the Statistics drop-down list.
Page 199: Mld Snooping Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide • Multicast Listener Report, Version 2 - Comparable to the Host Membership Report in IGMPv3, and labeled as 143 in the ICMP packet header, this message is sent by the listening port to the Switch stating that it is interested in receiving multicast data from a multicast address in response to the Multicast Listener Query message.
Page 200 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Show Detail button, the following window will appear. Figure 5-80 MLD Snooping Settings (Show Detail) Window The window displays the detail information about MLD snooping VLAN.
Page 201 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Minimum Version Select the minimum version of MLD hosts that is allowed on the VLAN. Options to choose from are 1 and 2. Fast Leave Select this option to enable or disable the MLD snooping Fast Leave function. If enabled, the membership is immediately removed when the system receives the MLD leave message.
Page 202 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-82 MLD Snooping Groups Settings Window The fields that can be configured in MLD Snooping Static Groups Settings are described below: Parameter Description Enter the VLAN ID of the multicast group here. The range is from 1 to 4094.
Page 203 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping Filter Settings, as shown below: Figure 5-83 MLD Snooping Filter Settings Window...
Page 204 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Limit Number Enter the limit number here. This is used to set the limitation on the number of MLD cache entries that can be created. The range is from 1 to 4096.
Page 205 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-84 MLD Snooping Filter Settings (Please Select) Window Select the ACL and click the OK button to use the selected access list. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 206 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Enter a VLAN ID between 1 and 4094. Configuration Select the port configuration. Options to choose from are Port, Forbidden Port, and Learn PIMv6. • Port - Select to have the configured ports as being connected to multicast- enabled routers.
Page 207: Multicast Vlan
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. This is available when Port is selected in the Statistics drop-down list. From Port - To Port Select the appropriate port range used for the configuration here.
Page 208 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-88 Multicast VLAN Settings Window The fields that can be configured in Multicast VLAN Global Settings are described below: Parameter Description Multicast VLAN IPv4 State Select to enable or disable the IPv4 IGMP control packet process in multicast VLANs.
Page 209 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in Member Port Settings are described below: Parameter Description Enter the multicast VLAN ID that will be used here. The range is 2 to 4094.
Page 210 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description From Select the “from” option here. Options to choose from are Receiver, Source, and Both. • Receiver - Specifies that the source IPv4/IPv6 address of the IGMP/MLD report/leave packet received on any multicast VLAN receiver port will be replaced.
Page 211 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-89 Multicast VLAN Group Settings Window The fields that can be configured in Group Profile Settings are described below: Parameter Description Profile Name Enter the group profile name for the multicast VLAN feature here. This name can be up to 32 characters long.
Page 212: Pim Snooping
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. The fields that can be configured in Group Profile Table are described below: Parameter Description Profile Name Enter the group profile name for the multicast VLAN feature here. This name can be up to 32 characters long.
Page 213 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. The fields that can be configured in VLAN Status Settings are described below: Parameter Description Enter the VLAN ID on which the PIM snooping feature will be used here. The range is from 1 to 4094.
Page 214: Multicast Filtering
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-92 PIM Snooping Mroute Table Window The fields that can be configured are described below: Parameter Description Select and enter the VLAN ID that will be used in this display here. The range is from 1 to 4094.
Page 215: Lldp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-94 Multicast Filtering Window The fields that can be configured are described below: Parameter Description Enter the VLAN ID list that will be used for this configuration here.
Page 216 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-95 LLDP Global Settings Window The fields that can be configured in LLDP Global Settings are described below: Parameter Description Select this option to enable or disable the LLDP feature...
Page 217: Lldp Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description each physical interface. The range is from 5 to 32768 seconds. Message TX Hold Multiplier Enter the multiplier on the LLDPDUs transmission interval that used to calculate the TTL value of an LLDPDU.
Page 218: Lldp Management Address List
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description are Default, IPv4 and IPv6. Action Select the action that will be taken here. Options to choose from are Remove and Add. Address Enter the IP address that will be sent.
Page 219: Lldp Dot1 Tlvs Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-98 LLDP Basic TLVs Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 220: Lldp Dot3 Tlvs Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. From Port - To Port Select the appropriate port range used for the configuration here.
Page 221: Lldp-Med Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Maximum Frame Size Select this option to enable or disable the Maximum Frame Size TLV to send. The Maximum Frame Size TLV indicates the maximum frame size capability of the implemented MAC and PHY.
Page 222: Lldp Statistics Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-102 LLDP-DCBX Port Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit ID that will be used here. From Port - To Port Select the Switch port range that will be used here.
Page 223: Lldp Local Port Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used here. Port Select the port number that will be used here.
Page 224: Lldp Neighbor Port Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-105 LLDP Local Port Information (Show Detail) Window To view more details about, for example, the MAC/PHY Configuration/Status, click the Show Detail hyperlink. Click the Back button to return to the previous window.
Page 225 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 5-107 LLDP Neighbor Port Information Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be displayed. Port Select the port number that will be displayed.
Page 226: Layer 3 Features
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Layer 3 Features Gratuitous ARP IPv6 Neighbor Interface UDP Helper IPv4 Static/Default Route IPv4 Static Route BFD IPv4 Route Table IPv6 Static/Default Route IPv6 Static Route BFD IPv6 Route Table...
Page 227: Arp Aging Time
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide ARP Aging Time This window is used to display and configure the ARP aging time settings. To view the following window, click L3 Features > ARP > ARP Aging Time, as shown below:...
Page 228: Proxy Arp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. Proxy ARP This window is used to display and configure the Proxy ARP settings. The Proxy ARP feature will allow the Switch to reply to ARP requests destined for another device by faking its identity (IP and MAC Address) as the original ARP responder.
Page 229: Gratuitous Arp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long. Interface VLAN Enter the interface VLAN ID used here. This value must be between 1 and 4094.
Page 230: Ipv6 Neighbor
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description gratuitous ARP packets. The gratuitous ARP packet is sent by a source IP address and is identical to the IP that the packet is querying. Click the Apply button to accept the changes made.
Page 231: Interface
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Interface IPv4 Interface This window is used to display and configure the IPv4 interface settings. To view the following window, click L3 Features > Interface > IPv4 Interface, as shown below:...
Page 232 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description State Select to enable or disable the IPv4 interface global state. IP VRF Forwarding Enter the VRF instance name that will be forwarded here.
Page 233: Ipv6 Interface
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description DHCP discover message. Lease Enter and optionally select the DHCP client lease time here. In the text box the lease time, in days, can be entered. The range is from 0 to 10000 days. Hours and Minutes can also be selected optionally.
Page 234 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-12 IPv6 Interface (Detail, IPv6 Interface Settings) Window The fields that can be configured are described below: Parameter Description IPv6 MTU Enter the IPv6 MTU value here. The range is from 1280 to 65534 bytes. By default, this value is 1500 bytes.
Page 235 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description 3600000 milliseconds, in multiples of 1000. If the specified time is 0, the router will use 1 second on the interface and advertise 0 (unspecified) in the Router Advertisement (RA) message.
Page 236: Loopback Interface
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After selecting the DHCPv6 Client tab option, at the top of the page, the following page will be available. Figure 6-15 IPv6 Interface (Detail, DHCPv6 Client) Window Click the Restart button to restart the DHCPv6 client service.
Page 237 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-16 Loopback Interface Window The fields that can be configured are described below: Parameter Description Interface Loopback Enter the loopback interface ID here. The range is from 1 to 8.
Page 238: Null Interface
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Delete button to delete the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 239: Ip Helper Address
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description IP Forward Protocol UDP Enter the destination port of the UDP service to be forwarded here. The range is Port from 1 to 65535.
Page 240: Ipv4 Static/Default Route
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv4 Static/Default Route This window is used to display and configure the IPv4 static and default route settings. The Switch supports static routing for IPv4 formatted addressing. Users can create up to 512 static route entries for IPv4. For IPv4 static routes, once a static route has been set, the Switch will send an ARP request packet to the next hop router that has been set by the user.
Page 241: Ipv4 Static Route Bfd
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Delete button to remove the specific entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. IPv4 Static Route BFD This window is used to display and configure the IPv4 static route Bidirectional Forwarding Detection (BFD) settings.
Page 242: Ipv6 Static/Default Route
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long. IP Address Select and enter the single IPv4 address here.
Page 243: Ipv6 Static Route Bfd
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description default administrative distance for a static route is 1. Backup State Select the backup state option here. Options to choose from are Primary, and Backup. When the Primary option is selected, the route is specified as the primary route to the destination.
Page 244: Route Preference
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-26 IPv6 Route Table Window The fields that can be configured are described below: Parameter Description IPv6 Address Select and enter the IPv6 address to display here. IPv6 Address/Prefix Length Select and enter the IPv6 address and prefix length to display here.
Page 245: Ecmp Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long. Click the Please Select button to select a pre-configured VRF instance that will be used here.
Page 246: Ipv6 General Prefix
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description CRC 32 Upper Select this option to use the upper bits of CRC-32 as the ECMP hashing algorithm. TCP/UDP Port Select this option to use TCP/UDP port number as ECMP hash key.
Page 247: Ip Tunnel Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IP Tunnel Settings This window is used to display and configure the IP tunnel settings. To view the following window, click L3 Features > IP Tunnel Settings, as shown below:...
Page 248: Urpf Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Tunnel Mode Select the tunnel mode here. Options to choose from are IPv6 IP, 6to4, ISATAP, GRE IP, and GRE IPv6. • IPv6 IP - Specifies that the interface is an IPv6 IP tunnel interface.
Page 249 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in URPF Global Settings are described below: Parameter Description URPF State Select to globally enable or disable the URPF state here. Click the Apply button to accept the changes made.
Page 250: Vrf
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide VRF Settings This window is used to display and configure the Virtual Routing and Forwarding (VRF) settings. To view the following window, click L3 Features > VRF > VRF Settings, as shown below:...
Page 251 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to return to the previous window. The fields that can be configured in VRF Max Routes Settings are described below: Parameter Description Max Routes Enter the maximum number of routes within the VRF here. The range is from 1 to 16384.
Page 252: Vrf Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-36 VRF Settings (Show Detail) Window Click the Back button to return to the previous window. After clicking the Show Detail link, the following page will appear. Figure 6-37 VRF Settings (Show Detail, Show Detail) Window Click the Back button to return to the previous window.
Page 253: Rip
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-38 VRF Interface Settings Window The fields that can be configured in VRF Interface Settings are described below: Parameter Description Interface VLAN Enter the ID of the VLAN interface here. The range is from 1 to 4094.
Page 254 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-39 RIP Settings Window The fields that can be configured in RIP Global Settings are described below: Parameter Description RIP State Select to globally enable or disable the Routing Information Protocol (RIP) feature here.
Page 255 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-40 RIP Settings (Edit) Window Click the Back button to return to the previous window. The fields that can be configured in Redistribution Configuration are described below: Parameter...
Page 256: Rip Distribute List
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description to RIP. The specifying of the metric allows the metric to be synced. Select the Default option to use the default metric value, which is 0. Version Select the global RIP version that will be used as the default version for all interfaces here.
Page 257: Rip Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to return to the previous window. RIP Interface Settings This window is used to display and configure the RIP interface settings. To view the following window, click L3 Features > RIP > RIP Interface Settings, as shown below:...
Page 258: Ripng
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-44 RIP Database Window The fields that can be configured are described below: Parameter Description Network Address Enter the subnet prefix and the prefix length of the network(s) to be displayed here.
Page 259 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in RIPng Global Settings are described below: Parameter Description Global State Select to globally enable or disable the RIPng feature here. Click the Apply button to accept the changes made.
Page 260: Ripng Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide RIPng Interface Settings This window is used to display and configure the RIPng interface settings. To view the following window, click L3 Features > RIPng > RIPng Interface Settings, as shown below:...
Page 261: Ospf
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description IPv6 Address/Prefix Length Enter the IPv6 address that will be used for these results here. Click the Find button to locate a specific entry based on the information entered.
Page 262 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Select the VRF entry and click the OK button to use the selected VRF entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 263 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-51 OSPFv2 Process Settings (Show Detail) Window The fields that can be configured are described below: Parameter Description Select to enable or disable the implementation of Area Border Router (ABR) Compatible RFC3509 behavior (as defined in RFC 3509) here.
Page 264 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-52 OSPFv2 Distribute List Window The fields that can be configured are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 265 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-54 OSPFv2 GR Helper Settings Window The fields that can be configured are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 266 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-56 OSPFv2 Passive Interface Settings Window The fields that can be configured are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 267 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-58 OSPFv2 Area Settings Window The fields that can be configured in OSPF Area Settings are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 268 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Select VRF button, the following page will appear. Figure 6-59 OSPFv2 Area Settings (Select VRF) Window Select the VRF entry and click the OK button to use the selected VRF entry.
Page 269 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-61 OSPFv2 Interface Settings Window The fields that can be configured in OSPF Interface Settings are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 270 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-62 OSPFv2 Interface Settings (Show Detail) Window The fields that can be configured are described below: Parameter Description Cost Enter the cost value here. The range is from 1 to 65535. The interface cost reflects the overhead for sending the packet across the interface.
Page 271 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description become the DR, the router with the higher router priority will be elected the DR. If the routers have the same priority, the router with the higher router ID takes precedence.
Page 272 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Select the VRF entry and click the OK button to use the selected VRF entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 273 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-65 OSPFv2 Redistribute Settings Window The fields that can be configured are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 274 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide OSPFv2 Virtual Link Settings This window is used to display and configure OSPFv2 virtual link settings. If a non-zero area is not physically connected to the zero area, it must be connected to the zero area via a virtual link. The virtual link is a point-to-point link.
Page 275 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in OSPF Virtual Link Table are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 276 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-70 OSPFv2 LSDB Table Window The fields that can be configured are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 277 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-72 OSPFv2 LSDB Table (Show Detail) Window Click the Back button to return to the previous window. OSPFv2 Neighbor Table This window is used to display information on OSPF neighbors.
Page 278 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Select VRF button, the following page will appear.
Page 279 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-76 OSPFv2 Host Route Settings Window The fields that can be configured in OSPFv2 Host Route Settings are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 280: Ospfv3
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide OSPFv3 OSPFv3 Process Settings This window is used to display and configure OSPFv3 process settings. To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Process Settings, as shown below:...
Page 281 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Default Metric Enter the default metric value for the OSPF process here. The range is from 1 to 16777214. By default, this value is 20. This value is used in conjunction with the OSPFv3 redistribution feature to enable the current routing protocol to use the same metric value for all redistributed routes.
Page 282 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Passive Interface Settings, as shown below: Figure 6-81 OSPFv3 Passive Interface Settings Window The fields that can be configured are described below:...
Page 283 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description feature is used only with ABRs. It is used to consolidate or summarize routes for an area. The result is that a single summary route is advertised to other areas by the ABR.
Page 284 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking a Normal area the Process ID link (1) in the table, the following page will appear. Figure 6-84 OSPFv3 Area Settings (Process ID, Normal) Window Click the OK button to close the window and return to the previous window.
Page 285 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Instance ID Enter the instance identifier here. The range is from 0 to 255. If not specified, the default is 0. Area ID Enter the identifier of the area here. It can be specified as an IPv4 address.
Page 286 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Hello Interval, the earlier topological changes will be detected, but more routing traffic will ensue. This value must be the same for all routers and access servers on a specific network.
Page 287 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-87 OSPFv3 Redistribute Settings Window The fields that can be configured are described below: Parameter Description Process ID Enter the ID for an IPv6 OSPF routing process here. It is locally assigned and should be unique for each IPv6 OSPF routing process on the router.
Page 288 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-88 OSPFv3 Virtual Link Settings Window The fields that can be configured in OSPFv3 Virtual Link are described below: Parameter Description Enter the ID for an IPv6 OSPF routing process here. It is locally assigned and Process ID should be unique for each IPv6 OSPF routing process on the router.
Page 289 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Process ID link (1), the following page will appear. Figure 6-89 OSPFv3 Virtual Link Settings (Process ID) Window Click the OK button to close the window and return to the previous window.
Page 290: Ospfv3 Neighbor Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Prefix - Specifies to display information on the intra-area-prefix LSAs. • Link - Specifies to display information about the link LSAs. • Inter-Area Prefix - Specifies to display information only about LSAs based on inter-area prefix LSAs.
Page 291 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-92 OSPFv3 Neighbor Table Window The fields that can be configured are described below: Parameter Description Process ID Enter the OSPFv3 process ID to find here. The range is from 1 to 65535.
Page 292: Ip Multicast Routing Protocol
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-94 OSPFv3 Border Router Table Window The fields that can be configured are described below: Parameter Description Process ID Enter the OSPFv3 process ID to search for here. The range is from 1 to 65535.
Page 293 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-96 IGMP Interface Settings (Edit) Window The fields that can be configured are described below: Parameter Description Version Select the IGMP version number here. The range is from 1 to 3. Select the Default option to use the default version which is 3.
Page 294: Igmp Static Group Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IGMP Static Group Settings This window is used to display and configure the IGMP static group settings. Use this window to create an IGMP static group in the case that the attached host does not support the IGMP protocol. Once configured, the group member entry is added to the IGMP cache.
Page 295 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Group Enter the IP multicast group address here. Click the Find button to locate a specific entry based on the information entered. Click the Clear button to clear the entries based on the information specified.
Page 296: Mld
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description ACL Name Enter the standard IP access list name that contains the multicast groups to be mapped. To permit a group, specify ‘any’ in source address field and specify the group address in destination address field of the access list entry.
Page 297 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Interface VLAN Enter the associated VLAN ID of the interface here. The range is from 1 to 4094.
Page 298 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description interface does not receive the report packet before the leave timer expires, then the interface’s membership will be removed from the group or channel that it is leaving.
Page 299 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-104 MLD SSM Mapping Settings Window The fields that can be configured in MLD SSM Mapping Settings are described below: Parameter Description SSM Mapping State Select to enable or disable the MLD SSM mapping feature here.
Page 300: Igmp Proxy
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Select the ACL and click the OK button to use the selected access list. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 301 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in IGMP Proxy Downstream Settings are described below: Parameter Description Interface VLAN Enter the VLAN interface ID here. The range is from 1 to 4094.
Page 302: Mld Proxy
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-108 IGMP Proxy Forwarding Table Window The fields that can be configured are described below: Parameter Description Group Address Enter the IPv4 group multicast address here. Click the Find button to locate a specific entry based on the information entered.
Page 303 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Global State Select to globally enable or disable the MLD proxy feature here. Click the Apply button to accept the changes made. The fields that can be configured in MLD Proxy Upstream Settings are described below:...
Page 304: Dvmrp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Group Address Enter the IPv6 group multicast address here. Click the Find button to locate a specific entry based on the information entered. Click the Show All button to display all the entries.
Page 305: Dvmrp Routing Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Show All button to display all the entries. Click the Edit button to modify the specified entry.
Page 306: Pim
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Source Network Enter the source IPv4 network address and mask length here. Click the Find button to locate a specific entry based on the information entered. Click the Show All button to display all the entries.
Page 307 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The third type of router created in the PIM-SM configuration is the Boot Strap Router (BSR). The goal of the Boot Strap Router is to collect and relay RP information to PIM-SM enabled routers on the LAN. Although the RP can be statically set, the BSR mechanism can also determine the RP.
Page 308 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide PIM-DM The Protocol Independent Multicast - Dense Mode (PIM-DM) protocol should be used in networks with a low delay (low latency) and high bandwidth, as PIM-DM is optimized to guarantee delivery of multicast packets and not to reduce overhead.
Page 309 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Edit button to modify the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Edit button, the following page will appear.
Page 310 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description segment. The configured query interval is also used as the value for hold time. By configuring a smaller period for the interval, the unresponsive neighbor can be discovered faster and thus the failover and recovery will become more efficient.
Page 311 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-118 PIM BSR Candidate Window The fields that can be configured are described below: Parameter Description Interface Name Enter the name of the interface here. Hash Mask Length Enter the hash mask length for RP selection here.
Page 312 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-119 PIM RP Address Window The fields that can be configured are described below: Parameter Description RP Address Enter the RP IPv4 address here. Group Access List Name Enter the standard access list that will be used here.
Page 313 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to use the selected access list. PIM RP Candidate This window is used to display and configure the PIM RP candidate settings. To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv4 > PIM RP...
Page 314 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Show List button, the following page will appear. Figure 6-122 PIM RP Candidate (Show List) Window The fields that can be configured are described below: Parameter...
Page 315 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide PIM Register Settings This window is used to display and configure the PIM register settings. To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv4 > PIM...
Page 316 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in Register Keepalive Time are described below: Parameter Description Register Keepalive Enter the register keep-alive time value here. The range from 1 to 65525 seconds.
Page 317 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description SPT Threshold Select the SPT threshold option here. Options to choose from are 0 and Infinity. • 0 - Specifies to establish the source tree right at the arrival of the first packet.
Page 318: Pim Neighbor Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description ACL Type Select the ACL type that will be used to display the type of existing access lists in the table here.
Page 319 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-130 PIM for IPv6 Interface Window The fields that can be configured are described below: Parameter Description Interface Name Enter the VLAN interface name here. Click the Find button to locate a specific entry based on the information entered.
Page 320 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Mode Select the IPv6 PIM mode used in this interface here. Options to choose from are None and Sparse Mode. PIM for IPv6 will be disabled in this interface when the None option was selected.
Page 321 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-132 PIM for IPv6 BSR Candidate Settings Window The fields that can be configured are described below: Parameter Description Interface Name Enter the VLAN interface name used here.
Page 322 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide PIM for IPv6 RP Address This window is used to display and configure the IPv6 PIM RP address settings. This feature only affects PIM-SM operation. Use this feature to statically define the RP address for multicast groups that are to operate in sparse mode.
Page 323 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-135 PIM for IPv6 RP Address (Show List) Window The fields that can be configured are described below: Parameter Description ACL Type Select the ACL type that will be used to display the type of existing access lists in the table here.
Page 324 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Interface Name Enter the interface name here whose IPv6 address will be advertised as the candidate RP (C-RP). Group Access List Name Enter the standard IPv6 access list that will be used here. Alternatively, click the Show List button to find and select any of the exiting access lists configured on this Switch to be used in this configuration.
Page 325 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-138 PIM for IPv6 RP Candidate (Edit) Window The additional fields that can be configured are described below: Parameter Description Interval Enter the RP candidate advertisement interval value here. The range is from 1 to 16383 seconds.
Page 326 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-140 PIM for IPv6 RP Table Window The fields that can be configured are described below: Parameter Description Enter the multicast group IPv6 address and prefix length here.
Page 327 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description register checksum methodology is PIM RFC-compliant, excluding the data portion in the Register message. Click the Apply button to accept the changes made. The fields that can be configured in Register Probe Time are described below:...
Page 328 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide PIM for IPv6 SSM Settings This window is used to display and configure the IPv6 PIM SSM settings. To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv6 > PIM for...
Page 329 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide PIM for IPv6 (S,G) Keepalive Time This window is used to display and configure the IPv6 PIM (S,G) keep-alive time settings. This feature is used to configure the keep-alive timer, which is the period during which the PIM router will maintain the (S, G) state in the absence of explicit (S, G) local membership or (S, G) join messages received to maintain it.
Page 330 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Show Detail button, the following page will appear.
Page 331 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Interface Name Enter the VLAN interface name used in this display here. Click the Find button to locate a specific entry based on the information entered.
Page 332 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description option to use the default value which is 30 seconds. SA Cache Expiry Time Enter the Source-Active (SA) cache expiry time value here. The range is from 65 to 65535 seconds.
Page 333 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Show Detail button to display more detailed information about the specified entry. Click the Delete button to delete the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 334 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description messages to a specified peer. By specifying this string, the router only forwards SA messages that match (S, G) pairs defined in the standard IP access list to a specified peer.
Page 335 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide MSDP SA Cache This window is used to view and clear the MSDP SA cache table. To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > MSDP > MSDP SA Cache,...
Page 336: Ipmc
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Find button to find and display an entry based on the information entered. MSDP Mesh Group Settings This window is used to display and configure the MSDP mesh group settings. Before adding an MSDP peer to the mesh group, an MSDP peer must be added first.
Page 337 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-157 IP Multicast Global Settings Window The fields that can be configured in IP Multicast Routing Global State are described below: Parameter Description Select to globally enable or disable the IP multicast routing feature here. When IP...
Page 338 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Please Select button, the following page will appear. Figure 6-158 IP Multicast Global Settings (Please Select) Window Select the ACL and click the OK button to use the selected access list.
Page 339 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Static Selecting this option specifies to display the multicast static routes. Multicast Protocol Select this option and then select the multicast protocol that will be used in this display here.
Page 340 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Group Address Enter the multicast group IP address here. Enter the multicast source IP address here. Source Address Click the Find button to locate a specific entry based on the information entered.
Page 341 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Control Packet CPU Filtering This window is used to display and configure the IPMC control packet CPU filtering settings. To view the following window, click L3 Features > IP Multicast Routing Protocol > IPMC > Control Packet CPU...
Page 342: Ipv6Mc
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv6MC IPv6 Multicast Global Settings This window is used to display and configure the global IPv6 multicast settings. To view the following window, click L3 Features > IP Multicast Routing Protocol > IPv6MC > IPv6 Multicast Global...
Page 343 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-165 IPv6 Static Multicast Route Settings Window The fields that can be configured are described below: Parameter Description IPv6 Address/Prefix Length Enter the IPv6 network address and prefix length of the multicast source here. A decimal value that indicates how many of the high-order contiguous bits of the address comprise the prefix (the network portion of the address).
Page 344 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description multicast routing table. Click the Find button to locate a specific entry based on the information entered. Click the Show All button to display all the entries.
Page 345: Bgp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide BGP Global Settings This window is used to display and configure the global Border Gateway Protocol (BGP) settings. To view the following window, click L3 Features > BGP > BGP Global Settings, as shown below:...
Page 346 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description 65535 seconds. Hold Time Enter the hold time value here. This specifies the length of time to timeout the keep-alive message. The software will declare a BGP peer dead after the on timeout.
Page 347: Bgp Aggregate Address Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in BGP Trap Settings are described below: Parameter Description Peer Established Trap State Select to enable or disable the BGP peer established trap state here.
Page 348: Bgp Network Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Please Select button, the following page will appear.
Page 349: Bgp Route Redistribution Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Edit button to re-configure the specific entry. Click the Delete button to remove the specific entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 350 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Source Protocol Select the source protocol here. Options to choose from are: • Connected - Specifies to redistribute connected routes to BGP. • Static - Specifies to redistribute static routes to BGP.
Page 351: Bgp Route Preference Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide BGP Route Preference Settings This window is used to display and configure the BGP route preference settings. To view the following window, click L3 Features > BGP > BGP Route Preference Settings, as shown below:...
Page 352 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click L3 Features > BGP > BGP Dampening Settings, as shown below: Figure 6-178 BGP Dampening Settings Window The fields that can be configured in BGP Dampening are described below:...
Page 353: Bgp Dampening Dampened Paths Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description minutes. Reuse Value Enter the re-use value here. As the penalty is decreased and falls below the re- use threshold, the route will be re-entered into the routing table as a normal route.
Page 354: Bgp Dampening Flap Statistics Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description configuration. • IPv4 VRF - Specifies to use a VRF instance in this configuration. Enter the name of the VRF instance in the space provided or click the Please Select button to select a pre-configured VRF instance that will be used here.
Page 355 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-182 BGP Dampening Flap Statistics Table Window The fields that can be configured are described below: Parameter Description Address Family Select the address family that will be used here. Options to choose from are: •...
Page 356: Bgp Reflector Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Select the VRF entry and click the OK button to use the selected VRF entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 357: Bgp Confederation Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description here. State Select to enable or disable the BGP reflector client state here. Click the Apply button to accept the changes made. BGP Confederation Settings This window is used to display and configure the BGP confederation settings.
Page 358: Bgp Community List Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-186 BGP AS Path Access List Settings Window The fields that can be configured are described below: Parameter Description List Name Enter the name of the AS path access list here. This name can be up to 16 characters long.
Page 359 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-187 BGP Community List Settings Window The fields that can be configured are described below: Parameter Description List Name Enter the name of the community list here. This name can be up to 16 characters long.
Page 360: Bgp Extended Community List Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Show All button to display all the available entries. Click the Delete button to remove the specific entry.
Page 361: Bgp Clear Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Regular Expression Enter the regular expression here. This string can be up to 80 characters long. Click the Apply button to accept the changes made. BGP Clear Settings This window is used to display and configure the BGP clear settings.
Page 362: Bgp Summary Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Peer Group Enter the name of the peer group of which the BGP peer session will be cleared here. This name can be up to 16 characters long.
Page 363: Bgp Routing Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Layer 2 VPN VPLS address family. Click the Find button to locate a specific entry based on the information selected/entered. After clicking the Please Select button, the following page will appear.
Page 364 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • VPNv4 VRF - Specifies to display BGP routing information related to the VRF instance in the VPNv4 address family. Enter the name of the VRF instance here. This name can be up to 12 characters long. Alternatively, click the Please Select button to select a pre-configured VRF instance that will be used here.
Page 365: Bgp Labels Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description ○ Community List - Enter the name of the BGP community list here. This name can be up to 16 characters long. ○ Exact Match - Select this option to display only routes that are an exact match.
Page 366: Bgp Neighbor
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Address Family Select the address family that will be used here. Options to choose from are: • VPNv4 All - Specifies to display all BGP label information related to the VPNv4 address family.
Page 367 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-196 Neighbor Window The fields that can be configured in Neighbor Settings are described below: Parameter Description Select and enter the IPv4 or IPv6 address of the neighboring router here.
Page 368: Peer Group
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Neighbor Address Select and enter the IPv4 or IPv6 address of the neighboring router here. Type Select the type of information to display here. Options to choose from are: •...
Page 369 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-198 Peer Group Window The fields that can be configured in Peer Group are described below: Parameter Description Group Name Enter the name of the BGP peer group here. This name can be up to 16 characters long.
Page 370 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Address Family Select the address family that will be used here. Options to choose from are: • IPv4 Unicast - Specifies to display the BGP peer group table related to the IPv4 unicast address family.
Page 371: Neighbor Activate
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Neighbor Activate This window is used to view, activate and deactivate BGP neighbors. To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor Activate, as shown below:...
Page 372: Neighbor Shutdown
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Select the VRF entry and click the OK button to use the selected VRF entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 373 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor Map Settings, as shown below: Figure 6-205 Neighbor Map Settings Window The fields that can be configured are described below:...
Page 374 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description long. Click the Apply button to accept the changes made. After clicking the Please Select button, the following page will appear. Figure 6-206 Neighbor Map Settings (Please Select) Window Select the VRF entry and click the OK button to use the selected VRF entry.
Page 375 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • IPv4 Multicast - Specifies to configure the BGP neighbor filter settings related to the IPv4 multicast address family. • L2VPN VPLS - Specifies to configure the BGP neighbor filter settings related to the Layer 2 VPN VPLS address family.
Page 376 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Neighbor Maximum Prefix Settings This window is used to display and configure the BGP neighbor maximum prefix settings. This is used to control the maximum number of prefixes that can be accepted from a BGP neighbor.
Page 377 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description threshold was exceeded. Click the Apply button to accept the changes made. After clicking the Please Select button, the following page will appear. Figure 6-210 Neighbor Maximum Prefix Settings (Please Select) Window Select the VRF entry and click the OK button to use the selected VRF entry.
Page 378 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Address Family Select the address family that will be used here. Options to choose from are: • IPv4 Unicast - Specifies to configure the BGP general settings related to the IPv4 unicast address family.
Page 379 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Capability Graceful Restart Select to enable or disable the graceful restart capability here. This is used to enable the feature to advertise the graceful restart capability to its neighbors.
Page 380: Bfd
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide BFD Settings This window is used to display and configure the Bidirectional Forwarding Detection (BFD) settings. To view the following window, click L3 Features > BFD > BFD Settings, as shown below:...
Page 381: Isis
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: Performance will vary depending on the configuration and traffic patterns. It is advised to perform lab testing before deploying BFD in a live environment. To view the following window, click L3 Features > BFD > BFD Neighbor Table, as shown below: Figure 6-214 BFD Neighbor Table Window Click the Show Detail button to view more detailed information about the specific entry.
Page 382 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Area Tag Enter the ISIS area tag here. This can be up to 16 characters long. Click the Apply button to accept the changes made.
Page 383 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Select the Authenticate SNP option to insert the password into sequence number PDUs (SNPs). • Validate - Specifies to insert the password into the SNPs and check the password in SNPs on receiving.
Page 384 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description LSPs from timing out. Reducing the refresh interval reduces the amount of time undetected link-state database corruption can persist at the cost of increased link utilization. Increasing the interval reduces the link utilization caused by the flooding of refreshed packets.
Page 385 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description SPF Interval Level-2 Enter the SPF interval level-2 value here. This is used to customize ISIS throttling of SPF calculations applied to level-2 areas only. The range is from 1 to 120 seconds.
Page 386: Isis Router Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide ISIS Router Settings This window is used to display and configure the ISIS router settings. To view the following window, click L3 Features > ISIS > ISIS Router Settings, as shown below:...
Page 387 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Distance Enter the distance value here. This is used to define the administrative distance of ISIS routes. The range is from 1 to 255 for IPv4 ISIS routes and 1 to 254 for IPv6 ISIS routes.
Page 388: Isis Interface Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Summary Prefix List button, the following page will appear. Figure 6-223 ISIS Router Settings (Summary Prefix List) Window The fields that can be configured are described below:...
Page 389 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Interface VLAN Enter the VLAN ID that will be used here. The range is from 1 to 4094. IPv4 Select this option to enable the ISIS routing protocol for IPv4 on the interface.
Page 390 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Mesh Group Enter the mesh group number here. This is used to optimize Link-State Packet (LSP) flooding on point-to-point networks. Select the Block option to specify that no LSP flooding will take place on this interface.
Page 391: Isis Redistribute Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description 0 to 127. Select the Default option to use the default value. Wide Metric Level-1 Enter the wider metric value that is assigned to the link and used to calculate the cost from other routers via the links in the network to other destinations for level-1 routing here.
Page 392: Isis Redistribute Isis Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Metric Type Select the metric type of the redistributed routes here. Options to choose from are: • None - The metric type is not specified. • Internal - The redistributed routes advertised with internal metrics.
Page 393: Isis Route Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Find button to locate a specific entry based on the information entered. Click the Delete button to remove the specific entry.
Page 394: Isis Topology
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Area Tag Enter the ISIS area tag that will be used in this display here. This can be up to 16 characters long.
Page 395: Isis Hostname
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • IPv4 - Specifies to display the ISIS IPv4 routing table information. • IPv6 - Specifies to display the ISIS IPv6 routing table information. Area Tag Enter the ISIS area tag that will be used in this display here. This can be up to 16 characters long.
Page 396: Ip Route Filter
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-234 ISIS Neighbors (Show Detail) Window Click the Back button to return to the previous window. IP Route Filter IP Prefix List This window is used to display and configure the IP route filter prefix list settings.
Page 397: Route Map
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description IPv6 Network Address Enter the IPv6 address and prefix length here. Enter the minimum prefix length of the route that can be matched here. The range is from 1 to 32 for IPv4 and 1 to 128 for IPv6.
Page 398 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Delete button to delete the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Edit button in the Match Clauses column, the following page will appear.
Page 399 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description IPv6 Next Hop ACL Select and enter the standard IPv6 access list name here. This option is used to define a clause to match the route’s next hop based on the standard IPv6 access list.
Page 400 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-238 Route Map (Set Clauses, Edit) Window The fields that can be configured are described below: Parameter Description Action Select Add to add a new entry based in the information entered.
Page 401 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Community String - Select and enter the community string here. It can be a user-specified number represented by AA:NN, where AA (AS number) is the upper part of the word and NN (community number, user-specified) is the lower part of the word.
Page 402: Policy Route
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Back button to return to the previous window. Policy Route This window is used to display and configure the policy route settings.
Page 403 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-241 VRRP Settings Window The fields that can be configured in VRRP Settings are described below: Parameter Description SNMP Server Traps VRRP Select to enable or disable the SNMP server traps feature for the new VRRP New master master.
Page 404: Vrrpv3 Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Edit button, the following page will appear.
Page 405 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 6-243 VRRPv3 Settings Window The fields that can be configured are described below: Parameter Description VLAN Enter the ID of the VLAN interface that will be used here. The range is from 1 to 4094.
Page 406 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Virtual IP Address Enter the virtual IPv4/IPv6 address here. This parameter will be either IPv4 or IPv6 depending on the Address Family selection made in the previous step. All routers in the same VRRP group must be configured with the same virtual router ID and virtual address.
Page 407: Quality Of Service (Qos)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Quality of Service (QoS) Basic Settings Advanced Settings QoS PFC WRED iSCSI Basic Settings Port Default CoS This window is used to display and configure the port default CoS settings.
Page 408 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-2 Port Scheduler Method Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 409: Queue Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Queue Settings This window is used to display and configure the queue settings. To view the following window, click QoS > Basic Settings > Queue Settings, as shown below:...
Page 410: Port Rate Limiting
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-4 CoS to Queue Mapping Window The fields that can be configured are described below: Parameter Description Queue ID Select the queue ID that will be mapped to the corresponding CoS value. Options to choose from are 0 to 7.
Page 411: Queue Rate Limiting
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description the space provided. This value must be between 8 and 10000000 kbps. Also, enter the Burst Size value in the space provided. This value must be between 0 and 128000 kilobytes.
Page 412: Advanced Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description even if the bandwidth is available. When configuring the minimal bandwidth, the aggregate of the configured minimum bandwidth must be less than 75 percent of the interface bandwidth to make sure the configured minimal bandwidth can be guaranteed.
Page 413: Port Trust State And Mutation Binding
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Delete button to remove the specific entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 414: Cos Color Mapping
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-9 DSCP CoS Mapping Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 415: Dscp Color Mapping
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-10 CoS Color Mapping Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 416: Class Map
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-11 DSCP Color Mapping Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 417: Aggregate Policer
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Match button to configure the specific entry. Click the Delete button to remove the specific entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 418 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click QoS > Advanced Settings > Aggregate Policer, as shown below: Figure 7-14 Aggregate Policer (Single Rate Setting) Window The fields that can be configured are described below:...
Page 419 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • When selecting the Set-DSCP-1P option, enter the IP DSCP and 1P transmit values in the spaces provided. Select the violate action here. The violate action specifies the action to take on Violate Action packets that violate the normal and maximum burst sizes for singe rate policing.
Page 420 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description bucket for the two-rate metering. Confirm Burst Enter the confirm burst value here. This value must be between 0 and 16384 Kbytes. The confirm burst value specifies the burst size for the first token bucket in kbps.
Page 421: Policy Map
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • When selecting the Transmit option, packets will be transmitted unaltered. • When selecting the Set-DSCP-1P option, enter the IP DSCP and 1P transmit values in the spaces provided.
Page 422 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Set Action button to configure the set action settings for the specified entry. Click the Policer button to configure the policer settings for the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 423 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-18 Policy Map (Policer) Window The fields that can be configured are described below: Parameter Description None Select this option to specify that no policer settings will be configured for this entry.
Page 424: Policy Binding
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Transmit - Specifies that the exceed action is to transmit the packet unmodified. • Set-DSCP-1P - Specifies that the exceed action is to modify the DSCP and 802.1p values and then to transmit the packet with the new DSCP and...
Page 425: Qos Pfc
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. From Port - To Port Select the range of ports that will be used for this configuration here.
Page 426: Network Qos Policy Map
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Match Select the IEEE 802.1Q Class of Service (CoS) value to be matched here. The range is from 0 to 7. When a packet is received, the packet will be given an internal CoS. This internal CoS is used to select the transmit queue based on the CoS to queue map.
Page 427: Network Qos Policy Binding
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Edit button, the following page will appear. Figure 7-23 Network QoS Policy Map (Edit) Window The fields that can be configured are described below: Parameter Description Pause Select to enable or disable the pause feature here.
Page 428: Pfc Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit ID that will be used here. From Port - To Port Select the Switch port range that will be used here. Direction Select the Input direction here.
Page 429: Wred
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit ID that will be used here. From Port - To Port Select the Switch port range that will be used here. Select the All option to specify that all ports will be used here.
Page 430 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-26 WRED Profile Window The fields that can be configured are described below: Parameter Description Enter the WRED profile ID here. The range is from 1 to 128.
Page 431: Wred Queue
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide WRED Queue This window is used to display and configure the WRED queue settings. WRED drops packets, based on the average queue size exceeding a specific threshold, to indicate congestion. Explicit Congestion Notification (ECN) is an extension to WRED in that ECN marks packets instead of dropping them when the average queue size exceeds a specific threshold value.
Page 432: Iscsi
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-28 WRED Drop Counter Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit ID that will be used here. From Port - To Port Select the Switch port range that will be used here.
Page 433 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 7-29 iSCSI Settings Window The fields that can be configured are described below: Parameter Description Select to globally enable or disable the iSCSI awareness feature here. iSCSI State iSCSI CoS Select the iSCSI CoS that will be configured here.
Page 434: Iscsi Sessions
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide iSCSI Sessions This window is used to view the iSCSI active session table. To view the following window, click QoS > iSCSI > iSCSI Sessions, as shown below: Figure 7-30 iSCSI Sessions Window...
Page 435: Access Control List (Acl)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Access Control List (ACL) ACL Configuration Wizard ACL Access List ACL Interface Access Group ACL VLAN Access Map ACL VLAN Filter CPU ACL ACL Configuration Wizard This window is used to guide the user to create a new ACL access list or configure an existing ACL access list.
Page 436: Step 2 - Select Packet Type
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Create Select this option to create a new ACL access list using the configuration wizard. ACL Name Enter the new ACL name here. This name can be up to 32 characters long.
Page 437 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 8-4 ACL Configuration Wizard (Create, Packet Type, MAC) Window The fields that can be configured are described below: Parameter Description Sequence No. Enter the ACL rule number here. This value must be between 1 and 65535.
Page 438 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Ethernet Type Enter the Ethernet type hexadecimal value here. This value must be between 0x600 and 0xFFFF. When any Ethernet type profile is selected in the Specify Ethernet Type drop-down list, the appropriate hexadecimal value will automatically be entered.
Page 439 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv4 After clicking the IPv4 radio button and the Next button, the following window will appear. Figure 8-5 ACL Configuration Wizard (Create, Packet Type, IPv4) Window The fields that can be configured are described below:...
Page 440 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IP. • When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule.
Page 441 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description mask will be used. Enter the destination port mask value in the space provided. The range is from 0x0 to 0xFFFF. This parameter is only available in the protocol type TCP and UDP.
Page 442 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv6 After clicking the IPv6 radio button and the Next button, the following window will appear. Figure 8-6 ACL Configuration Wizard (Create, Packet Type, IPv6) Window The fields that can be configured are described below:...
Page 443 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IPv6. • When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule.
Page 444: Step 4 - Apply Port
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description This parameter is only available in the protocol type TCP and UDP. Specify ICMP Message Select the ICMP message type used here. Type This parameter is only available in the protocol type ICMP.
Page 445: Acl Access List
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. From Port - To Port Select the appropriate port range used for the configuration here.
Page 446 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Delete button, next to the ACL rule, to remove the specific ACL rule. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 447: Standard Ip Acl
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Standard IP ACL, Extended IP ACL, Standard IPv6 ACL, Extended IPv6 ACL, Extended MAC ACL, and Extended Expert ACL. Enter the ID for the ACL here. • For a Standard IP ACL, the range from 1 to 1999.
Page 448: Extended Ip Acl
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description bit value 0 will be checked. Destination Select and enter the destination information here. Options to choose from are Any, Host, IP, and Wildcard. • When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule.
Page 449 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description this value is not specified, the system will automatically generate an ACL rule number for this entry. Action Select the action that this rule will take here. Options to choose from are Permit, Deny, and Deny CPU.
Page 450 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • When selecting the = option, the specific selected port number will be used. • When selecting the > option, all ports greater than the selected port, will be used.
Page 451: Standard Ipv6 Acl
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Back button to discard the changes made and return to the previous page. Standard IPv6 ACL After selecting a Standard IPv6 ACL and clicking the Add Rule button, the following page will appear.
Page 452: Extended Ipv6 Acl
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to discard the changes made and return to the previous page. Extended IPv6 ACL After selecting an Extended IPv6 ACL and clicking the Add Rule button, the following page will appear.
Page 453 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • When the Host option is selected, enter the source host IPv6 address here. • When the IPv6 option is selected, the Prefix Length option will also be available.
Page 454: Extended Mac Acl
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Specify ICMP Message Select the ICMP message type used here. Type This parameter is only available in the protocol type ICMP. ICMP Message Type When the ICMP Message Type is not selected, enter the ICMP Message Type numerical value used here.
Page 455 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 8-15 Extended MAC ACL (Add Rule) Window The fields that can be configured are described below: Parameter Description Sequence No. Enter the sequence number of this ACL rule here. The range is from 1 to 65535. If this value is not specified, the system will automatically generate an ACL rule number for this entry.
Page 456: Extended Expert Acl
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description appropriate hexadecimal value will automatically be entered. Ethernet Type Mask Enter the Ethernet type mask hexadecimal value here. This value must be between 0x0 and 0xFFFF. When the Ethernet type profile is selected, above, the appropriate hexadecimal value will automatically be entered.
Page 457 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 8-16 Extended Expert ACL (Add Rule) Window The fields that can be configured are described below: Parameter Description Sequence No. Enter the sequence number of this ACL rule here. The range is from 1 to 65535. If this value is not specified, the system will automatically generate an ACL rule number for this entry.
Page 458 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked. Destination Select and enter the destination IP information here. Options to choose from are Any, Host, and IP.
Page 459 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description used. • When selecting the < option, all ports smaller than the selected port, will be used. • When selecting the ≠ option, all ports, excluding the selected port, will be used.
Page 460: Acl Interface Access Group
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description is from 1 to 4094. • Mask - Enter the inner VLAN ID mask value here. The range is from 0x0 to 0xFFF. VLAN Range Select and enter the VLAN range that will be associated with this ACL rule here.
Page 461: Acl Vlan Access Map
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. After clicking the Please Select button, the following window will appear: Figure 8-18 ACL Interface Access Group (Please Select) Window Select the radio button next to the entry to use that ACL in the configuration.
Page 462 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Clear Counter button to the clear the counter information for the specified access map. Click the Find button to locate a specific entry based on the information entered.
Page 463: Acl Vlan Filter
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide ACL VLAN Filter This window is used to display and configure the ACL VLAN filter settings. To view the following window, click ACL > ACL VLAN Filter, as shown below:...
Page 464 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Binding button to configure the binding settings for the specified entry. Click the Delete button to delete the specified entry.
Page 465 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in Match MAC Access List are described below: Parameter Description Sequence No. Enter the sequence number of the associated match entry here. The range is from 1 to 65535.
Page 466: Security
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Security Port Security 802.1X RADIUS TACACS IMPB DHCP Server Screening ARP Spoofing Prevention BPDU Attack Protection NetBIOS Filtering MAC Authentication Web-based Access Control Network Access Authentication Safeguard Engine Trusted Host...
Page 467: Port Security Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Trap State Select to enable or disable port security traps on the Switch. Click the Apply button to accept the changes made. The fields that can be configured in Port Security Trap Rate Settings are described below:...
Page 468 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-2 Port Security Port Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 469: Port Security Address Entries
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description specified time period. Click the Apply button to accept the changes made. Port Security Address Entries This window is used to view, clear and configure the port security address entries.
Page 470 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-4 The EAPOL Packet Utilizing this method, unauthorized devices are restricted from connecting to a LAN through a port to which the user is connected. EAPOL packets are the only traffic that can be transmitted through the specific port until authorization is granted.
Page 471 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-6 The Authentication Server Authenticator The Authenticator (the Switch) is an intermediary between the Authentication Server and the Client. The Authenticator serves two purposes when utilizing the 802.1X function. The first purpose is to request certification information from the Client through EAPOL packets, which is the only information allowed to pass through the Authenticator before access is granted to the Client.
Page 472 Figure 9-9 The 802.1X Authentication Process The D-Link implementation of 802.1X allows network administrators to choose between two types of Access Control used on the Switch, which are: • Port-based Access Control - This method requires only one user to be authenticated per port by a remote RADIUS server to allow the remaining users on the same port access to the network.
Page 473 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The original intent behind the development of 802.1X was to leverage the characteristics of point-to-point in LANs. As any single LAN segment in such infrastructures has no more than two devices attached to it, one of which is a Bridge Port.
Page 474: 802.1X Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-11 Example of Typical Host-based Configuration 802.1X Global Settings This window is used to display and configure the global 802.1X settings. To view the following window, click Security > 802.1X > 802.1X Global Settings, as shown below: Figure 9-12 802.1X Global Settings Window...
Page 475: Authentication Sessions Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-13 802.1X Port Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 476: Authenticator Statistics
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-14 Authentication Sessions Information Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 477: Authenticator Session Statistics
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Authenticator Session Statistics This window is used to view and clear the authenticator session statistics. To view the following window, click Security > 802.1X > Authenticator Session Statistics, as shown below:...
Page 478: Aaa
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-17 Authenticator Diagnostics Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this query here.
Page 479: Application Authentication Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description AAA State Select to enable or disable the global Authentication, Authorization, and Accounting (AAA) state. Click the Apply button to accept the changes made. Application Authentication Settings This window is used to display and configure the application authentication settings.
Page 480 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-21 Application Accounting Settings Window Click the Edit button to re-configure the specific entry. Figure 9-22 Application Accounting Settings (Edit) Window The fields that can be configured in Application Accounting Exec Method list are described below:...
Page 481: Authentication Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. Authentication Settings This window is used to display and configure the AAA network and EXEC authentication settings.
Page 482 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • local - Specifies to use the local database for authentication. • group - Specifies to use the server groups defined by the AAA group server. Enter the AAA group server name in the space provided. This string can be up to 32 characters long.
Page 483: Accounting Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in AAA Authentication Enable are described below: Parameter Description Status Select to enable or disable the AAA authentication enable state here. Method 1 ~ Method 4 Select the method lists that will be used for this configuration here.
Page 484 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-25 Accounting Settings Window The fields that can be configured in AAA Accounting Network are described below: Parameter Description Default Select to enable or disable the use of the default method list here.
Page 485: Radius
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description List Name Enter the method list name that will be used with the AAA accounting EXEC option here. Method 1 ~ Method 4 Select the method lists that will be used for this configuration here. Options to choose from are none, group, radius, and tacacs+.
Page 486 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-29 RADIUS Global Settings Window The fields that can be configured in RADIUS Global Settings are described below: Parameter Description DeadTime Enter the dead time value here. This value must be between 1 and 1440 minutes.
Page 487: Radius Server Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide RADIUS Server Settings This window is used to display and configure the RADIUS server settings. To view the following window, click Security > RADIUS > RADIUS Server Settings, as shown below:...
Page 488 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-31 RADIUS Group Server Settings Window The fields that can be configured are described below: Parameter Description Enter the RADIUS group server name here. This name can be up to 32 Group Server Name characters long.
Page 489: Radius Statistic
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to return to the previous window. RADIUS Statistic This window is used to view and clear the RADIUS statistics information. To view the following window, click Security > RADIUS > RADIUS Statistic, as shown below:...
Page 490: Tacacs Server Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-34 TACACS Global Settings Window The fields that can be configured in TACACS Global IPv4 Source Interface are described below: Parameter Description IPv4 TACACS Source Enter the name of the IPv4 TACACS+ source interface here.
Page 491: Tacacs Group Server Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Enter the key, used to communicate with the TACACS+ server, here. This key can be up to 254 characters long. Click the Apply button to accept the changes made.
Page 492: Tacacs Statistic
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 493: Ipv4
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv4 DHCPv4 Snooping DHCP Snooping Global Settings This window is used to display and configure the global DHCP snooping settings. To view the following window, click Security > IMPB > IPv4 > DHCPv4 Snooping > DHCP Snooping Global...
Page 494 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-40 DHCP Snooping Port Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 495 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description State Select to enable or disable the DHCP snooping VLAN setting here. Click the Apply button to accept the changes made. DHCP Snooping Database This window is used to display and configure the DHCP snooping database settings.
Page 496: Dynamic Arp Inspection
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Select the location from the drop-down list and enter the URL where the DHCP snooping database will be loaded from here. Locations to choose from are TFTP, FTP, and Flash.
Page 497 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Security > IMPB > IPv4 > Dynamic ARP Inspection > ARP Access List, as shown below: Figure 9-44 ARP Access List Window The fields that can be configured are described below:...
Page 498 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to return to the previous page. Click the Apply button to accept the changes made. Click the Delete button to remove the specified entry. ARP Inspection Settings This window is used to display and configure the ARP inspection settings.
Page 499 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description ARP Access List Name Enter the ARP access list name used here. This name can be up to 32 characters long. VID List Enter the VLAN ID list used here.
Page 500 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Security > IMPB > IPv4 > Dynamic ARP Inspection > ARP Inspection VLAN, as shown below: Figure 9-48 ARP Inspection VLAN Window The fields that can be configured are described below:...
Page 501: Ip Source Guard
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-50 ARP Inspection Log Window The fields that can be configured are described below: Parameter Description Log Buffer Enter the log buffer value used here. This value must be between 1 and 1024. By default, this value is 32.
Page 502 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Security > IMPB > IPv4 > IP Source Guard > IP Source Guard Binding, as shown below: Figure 9-52 IP Source Guard Binding Window...
Page 503 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. IP Source Guard HW Entry This window is used to view the IP source guard hardware entries.
Page 504 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured in IP-MAC-Port Binding Trap Settings are described below: Parameter Description Trap State Select the enable or disable the IP-MAC-Port binding option’s trap state.
Page 505: Ipv6
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv6 IPv6 Snooping This window is used to display and configure the IPv6 snooping settings. To view the following window, click Security > IMPB > IPv6 > IPv6 Snooping, as shown below:...
Page 506 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description DHCP-PD snooping performs DHCPv6 snooping of Prefix Delegation (PD) to setup bindings between the Delegating Router (assigned with an IPv6 prefix) and the corresponding Requesting Router. The bindings can be used to validate the source prefix in the packets.
Page 507 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv6 RA Guard This window is used to display and configure the IPv6 Router Advertisement (RA) guard settings. To view the following window, click Security > IMPB > IPv6 > IPv6 RA Guard, as shown below:...
Page 508 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv6 DHCP Guard This window is used to display and configure the IPv6 DHCP guard settings. To view the following window, click Security > IMPB > IPv6 > IPv6 DHCP Guard, as shown below:...
Page 509 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide IPv6 Source Guard IPv6 Source Guard Settings This window is used to display and configure the IPv6 source guard settings. To view the following window, click Security > IMPB > IPv6 > IPv6 Source Guard > IPv6 Source Guard Settings,...
Page 510: Dhcp Server Screening
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-63 IPv6 Neighbor Binding Window The fields that can be configured in IPv6 Neighbor Binding Settings are described below: Parameter Description MAC Address Enter the MAC address used here.
Page 511: Dhcp Server Screening Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide When the DHCP Server Screening function is enabled on a port, all DHCP server packets received on this ports will be redirected to the CPU for a software-based check. Legal DHCP server packets will be forwarded out and illegal DHCP server packets will be dropped.
Page 512: Dhcp Server Screening Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Clear Log button to clear the log. DHCP Server Screening Port Settings This window is used to display and configure the DHCP server screening port settings.
Page 513: Bpdu Attack Protection
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-66 ARP Spoofing Prevention Window The fields that can be configured are described below: Parameter Description Select the Switch unit that will be used for this configuration here.
Page 514: Netbios Filtering
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-67 BPDU Attack Protection Window The fields that can be configured in BPDU Attack Protection Global Settings are described below: Parameter Description BPDU Attack Protection Select to enable or disable the global BPDU attack protection state here.
Page 515: Mac Authentication
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-68 NetBIOS Filtering Window The fields that can be configured are described below: Parameter Description Select the Switch unit that will be used for this configuration here. Unit From Port - To Port Select the range of ports that will be used for this configuration here.
Page 516 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-69 MAC Authentication Window The fields that can be configured in MAC Authentication Global Settings are described below: Parameter Description MAC Authentication State Select to enable or disable the global MAC authentication state.
Page 517: Web-Based Access Control
WAC by attempting to gain Web access. D-Link’s implementation of WAC uses a virtual IP that is exclusively used by the WAC function and is not known by any other modules of the Switch. In fact, to avoid affecting a Switch’s other features, WAC will only use a virtual IP address to communicate with hosts.
Page 518 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-70 RADIUS Authentication Server Conditions and Limitations • If the client is utilizing DHCP to attain an IP address, the authenticating VLAN must provide a DHCP server or a DHCP relay function so that client may obtain an IP address.
Page 519: Web Authentication
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Web Authentication This window is used to display and configure the Web authentication settings. To view the following window, click Security > Web-based Access Control > Web Authentication, as shown below:...
Page 520: Wac Customize Page
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-72 WAC Port Settings Window The fields that can be configured are described below: Parameter Description Select the Switch unit that will be used for this configuration here.
Page 521: Network Access Authentication
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Page Title Enter a custom page title message here. This message can be up to 128 characters long.
Page 522 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Security > Network Access Authentication > Network Access Authentication Global Settings, as shown below: Figure 9-75 Network Access Authentication Global Settings Window The fields that can be configured in Network Access Authentication MAC Format Settings are described below:...
Page 523: Network Access Authentication Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Authorization State Select to enable or disable the authorized state here. The option is used to enable or disable the acceptance of an authorized configuration. When authorization is enabled for authentication, the authorized attributes (for example VLAN, 802.1p...
Page 524: Network Access Authentication Sessions Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description From Port - To Port Select the appropriate port range used for the configuration here. Host Mode Select the host mode option that will be associated with the selected port(s) here.
Page 525: Safeguard Engine
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-77 Network Access Authentication Sessions Information Window The fields that can be configured are described below: Parameter Description Port Select the appropriate Switch unit and port used for the query here.
Page 526: Safeguard Engine Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Protocol Name Sub-interface Description (Group) 802.1X Protocol Port-based Network Access Control Protocol Address resolution Protocol Protocol Border Gateway Protocol DHCP Protocol Dynamic Host Configuration Protocol Protocol Domain Name System...
Page 527: Cpu Protect Counters
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-78 Safeguard Engine Settings Window The fields that can be configured in Safeguard Engine Settings are described below: Parameter Description Safeguard Engine State Select to enable or disable the safeguard engine feature here.
Page 528: Cpu Protect Sub-Interface
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Clear button to clear the information based on the selections made. Click the Clear All button to clear all the information in this table. CPU Protect Sub-Interface This window is used to display and configure the CPU protection sub-interface settings.
Page 529: Trusted Host
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-81 CPU Protect Type Window The fields that can be configured in CPU Protect Type are described below: Parameter Description Protocol Name Select the protocol name option here.
Page 530: Traffic Segmentation Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Traffic Segmentation Settings This window is used to display and configure the traffic segmentation settings. When the traffic segmentation forwarding domain is specified, packets received by the port will be restricted in Layer 2 packet forwarding to interfaces within the domain.
Page 531 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-84 Storm Control Window The fields that can be configured in Storm Control Trap Settings are described below: Parameter Description Trap State Select the storm control trap option here. Options to choose from are None, Storm Occur, Storm Clear, and Both.
Page 532 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description rise threshold is reached. Selecting Drop specifies to discards packets that exceed the risen threshold. Level Type Select the level type option here. Options to choose from are PPS, Kbps, and Level.
Page 533: Dos Attack Prevention Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. DoS Attack Prevention Settings This window is used to display and configure the Denial-of-Service (DoS) attack prevention settings. The following well-known DoS types which can be detected by most Switches: •...
Page 534: Ssh
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-87 DoS Attack Prevention Settings Window The fields that can be configured in SNMP Server Enable Traps DoS Settings are described below: Parameter Description Trap State Select to enable or disable the DoS attack prevention trap state here.
Page 535: Ssh Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide • Configure the User Account to use a specified authorization method to identify users that are allowed to establish SSH connections with the Switch using the SSH User Authentication Mode window. There are three choices as to the method SSH will use to authorize the user, which are Host Based, Password, and Public Key.
Page 536: Ssh Server Connection
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 9-89 Host Key Window The fields that can be configured in Host Key Management are described below: Parameter Description Select the crypto key type used here. Options to choose from are the Rivest...
Page 537: Ssh User Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Security > SSH > SSH Server Connection, as shown below: Figure 9-92 SSH Server Connection Window SSH User Settings This window is used to display and configure the SSH user settings.
Page 538: Ssl Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide • Key Exchange: The first part of the Cipher suite string specifies the public key algorithm to be used. This Switch utilizes the Rivest Shamir Adleman (RSA) public key algorithm and the Digital Signature Algorithm (DSA), specified here as the DHE DSS Diffie-Hellman (DHE) public key algorithm.
Page 539: Crypto Pki Trustpoint
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description SSL Status Select to enable or disable the global SSL status here. Service Policy Enter the service policy name here. This name can be up to 32 characters long.
Page 540: Ssl Service Policy
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Find button to locate a specific entry based on the information entered. Click the Delete button to remove the specified entry.
Page 541 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: Only IPv4 SFTP servers are supported. To view the following window, click Security > SFTP Server Settings, as shown below: Figure 9-97 SFTP Server Settings Window The fields that can be configured are described below:...
Page 542: 10. Oam
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide 10. OAM Cable Diagnostics Ethernet OAM CFM Settings This window is used to display and configure the Connectivity Fault Management (CFM) settings. To view the following window, click OAM > CFM > CFM Settings, as shown below:...
Page 543 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description easy identification of administrative responsibility for each maintenance domain. Domain Level Enter the Maintenance Domain (MD) level here. The range is from 0 to 7. A unique MD level is assigned to define the hierarchical relationship between domains.
Page 544 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Chassis - Specifies to transmit the sender ID TLV with the chassis ID information. • Manage - Specifies to transmit the sender ID TLV with the managed address information.
Page 545 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description MA Mode Select the MA mode here. Options to choose from are: • Software - Specifies that the MA works in the CFM software mode. • Hardware - Specifies that the MA works in the CFM hardware mode.
Page 546 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Add MEP button, the following page will appear. Figure 10-5 CFM Settings (Add MA, Add MEP) Window The fields that can be configured are described below:...
Page 547 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 10-6 CFM Settings (Add MA, Add MEP, MEPID Detail) Window Click the Edit button to modify the specified entry. Click the Back button to return to the previous window.
Page 548 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 10-7 CFM Settings (Add MA, Add MEP, MEPID Detail, Edit) Window The fields that can be configured are described below: Parameter Description MEP State Select to enable or disable the MEP state on the interface here.
Page 549 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description sent. Alarm Time Enter the time period used to define the time from when a defect is detected on the MEP to when a fault alarm will be sent. The range is from 250 to 1000 centiseconds.
Page 550 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Edit DM button, the following page will appear. Figure 10-10 CFM Settings (Add MA, Add MEP, Edit DM) Window The fields that can be configured in CFM DM Settings are described below:...
Page 551 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description default value is the PDU priority of the MEP. Click the Apply button to accept the changes made. The fields that can be configured in Clear CFM DM are described below:...
Page 552: Cfm Port Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description MAC Address Enter the MAC address for the LM test here. Period Select the time period here. This specifies the transmitting interval of the LM PDU. Options to choose from are 100ms, 1sec, and 10sec.
Page 553: Cfm Loopback Test
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Show Detail button, the following page will appear. Figure 10-13 CFM Port Settings (View Detail) Window Click the Back button to return to the previous window.
Page 554: Cfm Linktrace Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description PDU Priority Select the 802.1p priority to be set in the transmitted LBMs here. If not specified, it uses the same priority as the CCMs sent by the MA. The range is from 0 to 7.
Page 555: Cfm Packet Counter
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Clear All button to clear the information associated with all entries. Click the Show Detail button to view more detailed information about the link-trace entry. After clicking the Show Detail button, the following page will appear.
Page 556: Cfm Counter Ccm
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide CFM Counter CCM This window is used to view and clear the CFM CCM counter information. To view the following window, click OAM > CFM > CFM Counter CCM, as shown below: Figure 10-18 CFM Counter CCM Window Click the Clear button to clear the counter information associated with all entries.
Page 557 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 10-21 Cable Diagnostics Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 558: Ethernet Oam
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Ethernet OAM Ethernet OAM Settings This window is used to display and configure the Ethernet Operations, Administration, and Maintenance (OAM) settings. To view the following window, click OAM > Ethernet OAM > Ethernet OAM Settings, as shown below:...
Page 559: Ethernet Oam Configuration Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Process - Specifies to react to remote loopback requirements from a peer. The feature is used to configure the client to process or to ignore the received Ethernet OAM remote loopback feature.
Page 560 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 10-23 Ethernet OAM Configuration Settings Window The fields that can be configured in Ethernet OAM Configuration Settings are described below: Parameter Description Unit Select the Switch unit ID that will be used here.
Page 561 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Error Frame Seconds - This feature is used to enable notifying the Ethernet OAM error frame second event and configure the monitor threshold and window on the specified port.
Page 562: Ethernet Oam Event Log Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit ID that will be used here. From Port - To Port Select the Switch port range that will be used here. Click the Find button to locate a specific entry based on the information entered.
Page 563: Ethernet Oam Duld Settings
Click the Show All button to display all the statistics information. Ethernet OAM DULD Settings This window is used to display and configure the Ethernet OAM D-Link Unidirectional Link Detection (DULD) settings. DULD is an extension of 802.3ah Ethernet OAM. It provides a mechanism to detect a unidirectional point-to-point Ethernet link without PHY support.
Page 564: Ddm
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 10-26 Ethernet OAM DULD Settings Window The fields that can be configured in Ethernet OAM DULD Settings are described below: Parameter Description Recovery Time Enter the time interval value used by DULD to decide how long to recover the disabled port here.
Page 565: Ddm Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Switch and to configure alarm settings, warning settings, temperature threshold settings, voltage threshold settings, bias current threshold settings, Tx power threshold settings, and Rx power threshold settings. DDM Settings The window is used to view and configure the action that will occur for specific ports when an exceeding alarm threshold or warning threshold event is encountered.
Page 566: Ddm Temperature Threshold Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Apply button to accept the changes made. DDM Temperature Threshold Settings This window is used to display and configure the DDM Temperature Threshold Settings for specific ports on the Switch.
Page 567: Ddm Bias Current Threshold Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here. Select the port used for the configuration here.
Page 568: Ddm Rx Power Threshold Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 10-31 DDM TX Power Threshold Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 569: Ddm Status Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. Port Select the port used for the configuration here. Action Select the action that will be taken here. Options to choose from are Add and Delete.
Page 570: 11. Mpls
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide 11. MPLS MPLS LDP Information Settings MPLS LSP Trigger Information MPLS Forwarding Settings MPLS LDP Neighbor Password Settings MPLS LDP Neighbor Targeted Settings MPLS LDP Neighbor Information MPLS Global Settings...
Page 571 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Max PDU Length In this field the LDP maximum PDU length value will be displayed. Initial Backoff Enter the initial back-off delay time here. The LDP back-off delay time is a mechanism to prevent an endless sequence of session setup failures that occur between two LSRs with incompatible settings.
Page 572: Mpls Lsp Trigger Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Select the Default option to use the default value, which is 254. Hop Count Limit Enter the hop count limit here. The range is from 1 to 255. This feature is used to configure the maximum number of hops permitted in the LSP setup.
Page 573: Mpls Forwarding Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-2 MPLS LSP Trigger Information Window The fields that can be configured are described below: Parameter Description Enter the sequence number of the LSP trigger filter rule here. When creating a new rule, if not specified, the SN begins from 10 and is incremented by 10.
Page 574 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-3 MPLS Forwarding Settings Window The fields that can be configured for Static FTN Settings are described below: Parameter Description Enter the FEC IPv4 address of the static FTN here.
Page 575: Mpls Ldp Neighbor Password Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Mask Enter the FEC subnet mask of the FTN here. Click the Find button to locate a specific entry based on the information entered. MPLS LDP Neighbor Password Settings This window is used to display and configure the MPLS LDP neighbor password settings.
Page 576: Mpls Ldp Neighbor Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-5 MPLS LDP Neighbor Targeted Settings Window The fields that can be configured are described below: Parameter Description Neighbor Targeted Enter the LSR ID of the targeted peer here. The targeted peer is used to establish the LDP session with the non-directly connected neighbor.
Page 577: Mpls Global Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Clear All button to clear all the MPLS LDP neighbor information. MPLS Global Settings This window is used to display and configure the global MPLS settings. To view the following window, click MPLS > MPLS Global Settings, as shown below:...
Page 578: Mpls Ldp Session Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-8 MPLS LDP Interface Settings Window The fields that can be configured are described below: Parameter Description Interface VID Enter the interface VLAN ID used here. The range is from 1 to 4094.
Page 579 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-9 MPLS LDP Session Information Window The fields that can be configured are described below: Parameter Description Peer Enter the IP address which is used as the peer LSR ID here.
Page 580: Mpls Ldp Statistic
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-11 MPLS LDP Session Information (Show Statistics) Window Click the Back button to return to the previous window. MPLS LDP Statistic This window is used to display MPLS LDP statistics.
Page 581: Mpls Ldp Discovery Information
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-13 MPLS LDP Binding Table Window MPLS LDP Discovery Information This window is used to display MPLS LDP discovery information. To view the following window, click MPLS > MPLS LDP Discovery Information, as shown below:...
Page 582: Mpls Qos Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. MPLS QoS Settings This window is used to display and configure the MPLS QoS settings.
Page 583 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-18 MPLS QoS Settings (Edit) Window Click the Add button to add a new entry. Click the Delete button to remove the specific entry. Click the Apply button to accept the changes made.
Page 584 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-20 MPLS QoS Settings (Edit, Outbound CoS to EXP Settings) Window Click the Add button to add a new entry. Click the Delete button to remove the specific entry.
Page 585: Ping Mpls
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 11-22 MPLS QoS Settings (Edit, Binding FECs Settings) Window The fields that can be configured are described below: Parameter Description Enter the FEC IP address here. Use this feature to apply an MPLS QoS policy to FECs.
Page 586: Traceroute Mpls Ipv4
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description IPv4 Address Select and enter the FEC IPv4 address here whose LSP connectivity will be checked. Mask Select and enter the FEC subnet mask here.
Page 587 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description IPv4 Address Enter the FEC IPv4 address here whose LSP connectivity will be checked. Enter the FEC subnet mask here.
Page 588: 12. Mpls L2Vpn
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide 12. MPLS L2VPN VPWS Settings L2VC Interface Description VPLS Settings VPLS MAC Address Table VPWS Settings This window is used to display and configure the Virtual Private Wire Service (VPWS) settings.
Page 589 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description VC ID Enter the Pseudo-Wire (PW) service instance ID here. The range is from 1 to 4294967295. Click the Apply button to accept the changes made. Click the Find button to locate a specific entry based on the information entered.
Page 590 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description specified delay time after the primary PW comes back. The range is from 0 to 180 seconds. Selecting the Never option specifies not to switch back to the primary PW even if it comes back.
Page 591: L2Vc Interface Description
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 12-3 VPWS Settings (Show Detail) Window Click the Back button to return to the previous window. L2VC Interface Description This window is used to display and configure the Layer 2 Virtual Circuit (L2VC) interface description.
Page 592: Vpls Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Description Enter the L2VC interface description here. This name can be up to 64 characters long. Click the Apply button to accept the changes made. The fields that can be configured for Find L2VC Interface Description are described below:...
Page 593 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. From Port - To Port Select the range of ports that will be used for this configuration here.
Page 594 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description to remote peers in this VPLS here. The MTU value must be same at both the local and remote sites to establish the PW. If the MTU is specified as 0, then local the MTU will not be advertised to remote peers in the VPLS.
Page 595 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured for Egress VLAN Mode Settings are described below: Parameter Description Egress VLAN Mode Select the egress VLAN mode of the VPLS here. The egress VLAN mode will affect the outer VLAN tag handling before the decapsulated packet egress on ACs belonging to this VPLS.
Page 596: Vpls Mac Address Table
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Back button to return to the previous window. VPLS MAC Address Table This window is used to clear and display VPLS MAC address information. To view the following window, click MPLS L2VPN > VPLS MAC Address Table, as shown below:...
Page 597: 13. Monitoring
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide 13. Monitoring VLAN Counter Utilization Statistics Mirror Settings sFlow Device Environment External Alarm Settings VLAN Counter This window is used to display and configure the VLAN counter settings. This is used to create a control entry for traffic statistics on specified Layer 2 VLAN interface(s).
Page 598: Utilization
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Both - Specifies to count ingress and egress traffic. Click the Apply button to accept the changes made. Click the Delete button to delete the specified entry based on the information entered/selected.
Page 599: History Utilization
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide History Utilization This window is used to view the memory, CPU and port history utilization. To view the following window, click Monitoring > Utilization > History Utilization, as shown below:...
Page 600: Statistics
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • CPU - Specifies to display the historical CPU utilization information. • Port - Specifies to display the historical port utilization information. Unit Select the Switch unit that will be used here.
Page 601: Cpu Port
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide After clicking the Show Detail button, the following window will appear: Figure 13-7 Port (Show Detail) Window Click the Back button to return to the previous window. Click the Refresh button to refresh the information displayed in the table.
Page 602: Interface Counters
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 13-8 CPU Port Window The fields that can be configured are described below: Parameter Description Type Select the type of information to display here. Options to choose from are All, Layer 2 (L2), Layer 3 (L3), and Protocol.
Page 603 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 13-9 Interface Counters (Port) Window The fields that can be configured are described below: Parameter Description Type Select the type of information to display here. Options to choose from are Port and VLAN.
Page 604 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 13-10 Interface Counters (Show Errors) Window Click the Back button to return to the previous window. Click the Refresh button to refresh the information displayed in the table.
Page 605: Interface History Counters
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Interface History Counters This window is used to view the history counter information per interface. To view the following window, click Monitoring > Statistics > Interface History Counters, as shown below:...
Page 606: Counters
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Click the Find button to display entries in the table based on the information selected/entered. Counters This window is used to view and clear counter information. To view the following window, click Monitoring > Statistics > Counters, as shown below:...
Page 607 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 13-14 Counters (Show Detail) Window Click the Back button to return to the previous window. Click the Refresh button to refresh the information displayed in the table. After selecting VLAN as the Type, the following window will appear:...
Page 608: Mirror Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Type Select the type of information to display here. Options to choose from are Port and VLAN. Interface VLAN Enter the VLAN ID that will be used in this display here.
Page 609 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured for Mirror Settings are described below: Parameter Description Session Number Select the mirror session number for this entry here. This number is between 1 and 4.
Page 610: Sflow
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 13-17 Mirror Settings (Show Detail) Window Click the Back button to return to the previous page. sFlow sFlow Agent Information This window is used to view the sFlow agent information.
Page 611: Sflow Sampler Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Receiver Index Enter the index number of the receiver here. This number must be between 1 and Owner Name Enter the owner name of the receiver here.
Page 612: Sflow Poller Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • Selecting Outbound specifies to sample egress packets. Sampling Rate Enter packet sampling rate here. This value must be between 0 and 65536. Entering 0 will disable this function. If not specified, the default value is 0.
Page 613: External Alarm Settings
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 13-22 Device Environment Window External Alarm Settings This window is used to display and configure the external alarm settings. This is used to enable monitoring the external alarm source status or to configure external alarm message for a channel. The source of alarm is located outside of the Switch and is monitored via pre-defined connecting channels.
Page 614 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Message Enter the alarm message associated with the channel here. This string can be up to 128 characters long. Click the Apply button to accept the changes made.
Page 615: 14. Green
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide 14. Green Power Saving Power Saving This window is used to display and configure the power saving settings of the Switch. To view the following window, click Green > Power Saving, as shown below:...
Page 616: Eee
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: The hibernation feature can only be configured when physical stacking is disabled on this Switch. After clicking the Power Saving Shutdown Settings tab, the following page will appear.
Page 617 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here. Select the appropriate port range used for the configuration here.
Page 618: 15. Save And Tools
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide 15. Save and Tools Save Configuration Firmware Upgrade & Backup Configuration Restore & Backup Log Backup Ping Trace Route Reset Reboot System DLMS Settings Save Configuration This window is used to save the running configuration to the start-up configuration. This is to prevent the loss of configuration in the event of a power failure.
Page 619: Firmware Upgrade From Tftp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. Source File In this field the source firmware file’s filename and path will be displayed after selection.
Page 620: Firmware Upgrade From Rcp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 15-4 Firmware Upgrade from FTP Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 621: Firmware Backup To Http
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here. Enter the RCP server IP address here.
Page 622: Firmware Backup To Ftp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 15-7 Firmware Backup to TFTP Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit that will be used for this configuration here.
Page 623: Firmware Backup To Rcp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description selected, enter the IPv6 address of the FTP server in the space provided. TCP Port Enter the TCP port number used for the FTP connection here. The range is from 1 to 65535.
Page 624: Configuration Restore & Backup
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Configuration Restore & Backup Configuration Restore from HTTP This window is used to initiate a configuration restore from a local PC using HTTP. To view the following window, click Tools > Configuration Restore & Backup > Configuration Restore from HTTP,...
Page 625: Configuration Restore From Ftp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Unit Select the Switch unit that will be used for this configuration here. TFTP Server IP Enter the TFTP server IP address here. When select the IPv4 option, enter the IPv4 address of the TFTP server in the space provided.
Page 626: Configuration Restore From Rcp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description long. Source File Enter the source filename and path of the configuration file located on the FTP server here. This field can be up to 64 characters long.
Page 627: Configuration Backup To Http
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Configuration Backup to HTTP This window is used to initiate a configuration file backup to a local PC using HTTP. To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup to HTTP, as...
Page 628: Configuration Backup To Ftp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Destination File Enter the destination path and location where the configuration file should be stored on the TFTP server. This field can be up to 64 characters long.
Page 629: Configuration Backup To Rcp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Configuration Backup to RCP This window is used to initiate a configuration file backup to an RCP server. To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup to RCP, as...
Page 630: Log Backup To Tftp
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description • When the System Log option is selected, the system log will be backed up. • When the Attack Log is selected, the attack log will be backed up.
Page 631: Ping
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description RCP Server IP Enter the RCP server IP address here. User Name Enter the user name used for the RCP connection here. This name can be up to 32 characters long.
Page 632 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 15-21 Ping Window The fields that can be configured in Ping Access Class are described below: Parameter Description ACL Name Enter the name of the ACL that will be used here. This name can be up to 32 characters long.
Page 633 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description Timeout Select a timeout period between 1 and 99 seconds for this Ping message to reach its destination. If the packet fails to find the IP address in this specified time, the Ping packet will be dropped.
Page 634: Trace Route
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 15-22 Ping (Please Select) Window Select the radio button next to the entry to use that ACL in the configuration. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 635 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Figure 15-24 Trace Route Window The fields that can be configured in IPv4 Trace Route are described below: Parameter Description VRF Name Enter the name of the VRF instance here. This name can be up to 12 characters long.
Page 636: Reset
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Parameter Description default value is 1. Click the Start button to initiate the route trace for each individual section. The fields that can be configured in IPv6 Trace Route are described below:...
Page 637: Reboot System
Figure 15-28 Reboot System (Rebooting) Window DLMS Settings This window is used to display and configure the D-Link License Management System (DLMS) settings. The license specifies the feature options that are enabled on the Switch. License keys are sold in the market. It may be printed on a physical package or be displayed in an e-mail or a portal.
Page 638 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To view the following window, click Tools > DLMS Settings, as shown below: Figure 15-29 DLMS Settings Window The fields that can be configured are described below: Parameter Description Unit Select the Switch unit ID that will be used here.
Page 639: Appendix A - Password Recovery Procedure
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Appendix A - Password Recovery Procedure This section describes the procedure for resetting passwords on the D-Link DGS-3630 Series Switch. Authenticating any user who tries to access networks is necessary and important. The basic authentication method used to accept qualified users is through a local login, utilizing a Username and Password.
Page 640: Appendix B - System Log Entries
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Appendix B - System Log Entries The following table lists all possible entries and their corresponding meanings that will appear in the System Log of this Switch. 802.1X Log Description Severity Event description: 802.1X Authentication failure.
Page 641 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: Login failed due to AAA server timeout or improper configuration. Warning Log Message: Login failed through <exec-type> from <client-ip> due to AAA server <server-ip> timeout (Username: <username>).
Page 642 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity username: It indicates the username for authentication. Event description: RADIUS assigned a valid priority attributes. Informational Log Message: RADIUS server <server-ip> assigned 802.1p default priority: <priority> to port <interface -id>...
Page 643 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Auto-save Log Description Severity Event description: Record the event when the configure information of DDP is saved Informational automatically. Log Message:CONFIG-6-DDPSAVECONFIG: [Unit <unitID>, ]Configuration automatically saved to flash due to configuring from DDP(Username: <username>, IP: <ipaddr>)
Page 644 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity ipaddr: IP address of BGP peer. Event description: BGP connection is closed due to receive notify packet. (Error Code and Warning Error Subcode refer to RFC) Log Message: BGP-4-NOTIFYCLOSE: BGP connection is closed due to Notify: Code <num>...
Page 645 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide BPDU Protection Log Description Severity Event description: Record the event when the BPDU attack happened. Informational Log Message: <interface-id> enter STP BPDU under protection state (mode: <mode>) Parameters description: interface-id: Interface on which detected STP BPDU attack.
Page 646 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity mepid: Represents the MEPID of the MEP. macaddr: Represents the MAC address of the MEP. Event description: Remote MEP's MAC reports an error status Warning Log Message: CFM remote MAC error. MD Level:<mdlevel>, VLAN:<vlanid>, Local(Interface:<interface-id>, Direction:<mepdirection>)
Page 647 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity mdlevel: Represents the MD level of the MEP. interface-id: Represents the interface number of the MEP. mepdirection: Represents the direction of the MEP. This can be "inward" or "outward".
Page 648 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity macaddr : Represent client MAC address. serverIP: Server IP address. pathFile: Path and file name on server. Event description: Firmware uploaded unsuccessfully. Warning Log Message: [Unit <unitID>, ]Firmware uploaded by <session> unsuccessfully (Username: <username>[, IP: <ipaddr>, MAC: <macaddr>], Server IP: <serverIP>, File...
Page 649 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: Configuration uploaded unsuccessfully. Warning Log Message: [Unit <unitID>] Configuration uploaded by <session> unsuccessfully. (Username: <username>[, IP: <ipaddr>, MAC: <macaddr>], Server IP: <serverIP>, File Name: <pathFile>) Parameters description: unitID: The unit ID.
Page 650 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters description: interface-id: port interface ID. component: DDM threshold type. It can be one of the following types: temperature supply voltage bias current TX power RX power high-low: High or low threshold.
Page 651 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity ipv6address: IPv6 address obtained from a DHCPv6 server. ipif-name: Name of the DHCPv6 client interface. Event description: The IPv6 address obtained from a DHCPv6 server renews success.
Page 652 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters description: ipv6address: IPv6 prefix obtained from a delegation router. intf-name: Name of the DHCPv6 client PD interface. Event description: The IPv6 prefix obtained from a delegation router rebinds success.
Page 653 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity <string25>: Activation Code Event Description: License successfully installed. Informational Log Message: License successfully installed (license:<license-model>, AC: <string25>). Parameters Description: <license-model>: License Model Name. <string25>: Activation Code Event Description: The Activation Code is unbound.
Page 654 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Dynamic ARP Inspection Log Description Severity Event description: Detect illegal ARP packet Warning Log Message: Illegal ARP <type> packets (IP: <ip-address>, MAC: <mac-address>, VLAN <vlan-id>, on <interface-id>). Parameters description: type: The type of ARP packet, it indicates that ARP packet is request or ARP response.
Page 655 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters description: macaddr: MAC address InstanceID: Instance ID Event description: "RPL owner conflicted. Warning Log Message: "RPL owner conflicted on the node (MAC: <macaddr>, instance <InstanceID>)"...
Page 656 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters description: interface-id: The interface name. Event description: Remote loopback stop Warning Log Message: OAM Remote loopback stopped (Port <interface-id>) Parameters description: interface-id: The interface name.
Page 657 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: Link Aggregation Group link up. Informational Log Message: Link Aggregation Group <group_id> link up. Parameters description: group_id: The group id of the link up aggregation group.
Page 658 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters Description: None LLDP-MED Log Description Severity Event description: LLDP-MED topology change detected Notice Log Message: LLDP-MED topology change detected (on port <portNum>. chassis id: <chassisType>, <chassisID>, port id: <portType>, <portID>, device class: <deviceClass>) Parameters description: portNum: The port number.
Page 659 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity 1. interfaceAlias(1) 2. portComponent(2) 3. macAddress(3) 4. networkAddress(4) 5. interfaceName(5) 6. agentCircuitId(6) 7. local(7) portID: port ID. deviceClass: LLDP-MED device type. Notice Event description: Incompatible LLDP-MED TLV set detected Log Message: Incompatible LLDP-MED TLV set detected ( on port <portNum>, chassis id:...
Page 660 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity username: Represent current login user. Event description: Console session timed out. Informational Log Message: [Unit <unitID>, ] Console session timed out (Username: <username>) Parameters description: unitID: The unit ID.
Page 661 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters description: username: Represent current login user. ipaddr: Represent client IP address. Log Description Severity Event description: the host has passed MAC authentication Informational Log Message: MAC-based Access Control host login success (MAC: <mac-address>, <interface-id>, VID: <vlan-id>)
Page 662 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: LSP is up Informational Log Message: LSP <lsp_id> is up Parameters description: lsp_id: The established LSP ID Event description: LSP is down Informational Log Message: LSP <lsp_id> is down...
Page 663 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity portNum: Port ID/ old_role: Old role new_status: New role Event description: Spanning Tree instance created. Informational Log Message: Spanning Tree instance created. (Instance:<InstanceID>) Parameters description: InstanceID: Instance ID.
Page 664 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: OSPF interface link state changed. Informational Log Message: OSPF interface <intf-name> changed state to [Up | Down] Parameters description: intf-name: Name of OSPF interface.
Page 665 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Peripheral Log Description Severity Event description: Fan Recovered. Critical Log Message: Unit <unit-id>, <fan-descr> back to normal Parameters description: Unit <id>: The unit ID. <fan-descr>: For example, right fan, left fan etc.
Page 666 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity port: Represents the logical port number. nway: Represents the speed and duplex of link. Event description: port linkdown Informational Log Message: Port <port> link down Parameters description: port: Represents the logical port number.
Page 667 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Parameters description: entry-name: The name for this schedule execute configuration entry filename: The filename of the configuration. time-range: The name of the time range. Event description: schedule backup configuration or log failure Warning Log Message: Entry <entry-name>...
Page 668 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: SSH server is enabled. Informational Log Message: SSH server is enabled Event description: SSH server is disabled. Informational Log Message: SSH server is disabled...
Page 669 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Stack_TP_TYPE: The stacking topology type is one of the following: 1. Ring, 2. Chain. unitID: Box ID. Macaddr: MAC address. Event description: Backup master changed to master.
Page 670 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity packets interface-id: The interface ID on which a storm is occurring. Event description: Storm cleared. Informational Log Message: <Broadcast | Multicast | Unicast> storm is cleared on <interface-id>.
Page 671 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Log Message: <interface-id> Broadcast storm is occurring. Parameters description: interface-id: The interface name. Event description: Broadcast storm cleared. Informational Log Message: <interface-id> Broadcast storm has cleared.
Page 672 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity vc_id: The link down pseudowire ID ipaddr: The peer ip address of the link down pseudowire Event description: Pseudowire link up Informational Log Message: Pseudowire id <vc_id> peer ip <ipaddr> link up...
Page 673 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity intf-name: Interface name on which virtual router is based. Auth-type: VRRP interface authentication type. Event description: Checksum error of one received VRRP advertisement message. Warning Log Message: Received an ADV msg with incorrect checksum on VR <vr-id> at interface <intf-name>...
Page 674 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity vrrp-mac-addr: VRRP virtual MAC address vrrp-errcode: Errcode of VRRP protocol behavior. Event description: Failed when adding a virtual MAC into Switch L3 table. The L3 table is Error full.
Page 675 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity Event description: When a client host fails to authenticate. Warning Log Message: WAC unauthenticated user (User Name: <string>, IP: <ipaddr | ipv6address>, MAC: <macaddr>, Port: <[unitID:]portNum>)
Page 676 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Log Description Severity username: The use name that used to login HTTP server. ipaddr: The IP address of HTTP client.
Page 677: Appendix C - Trap Entries
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Appendix C - Trap Entries The following table lists all possible trap log entries and their corresponding meanings that will appear in the Switch. 802.1X Trap Name Description dDot1xExtLoggedSuccess The trap is sent when a host has successfully logged in 1.3.6.1.4.1.171...
Page 678 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Authentication Fail Trap Name Description authenticationFailure An authenticationFailure trap signifies that the SNMPv2 1.3.6.1.6.3.1.1. entity, acting in an agent role, has received a protocol message that is not properly authenticated. While all...
Page 679 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide CFM Extension Trap Name Description dCfmAisOccurred This trap is initiated when local MEP enters AIS status. 1.3.6.1.4.1.171 .14.86.0.1 Binding objects: (1) dCfmEventMdIndex (2) dCfmEventMaIndex (3) dCfmEventMepIdentifier dCfmAisCleared This trap is initiated when local MEP exits AIS status.
Page 680 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description dDhcpFilterAttackDetected When DHCP Server Screen is enabled, if the Switch 1.3.6.1.4.1.171 received the forge DHCP Server packet, the Switch will .14.133.0.1 trap the event if any attacking packet is received.
Page 681 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description dExternalAlarmStatusChg The commander Switch will send this notification when 1.3.6.1.4.1.171 External alarm state is changed. .14.32.0.1 Binding objects: (1) dExternalAlarmUnitID (2) dExternalAlarmChannel (3) dExternalAlarmStatus Gratuitous ARP...
Page 682 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description (1) ifIndex, (2) if AdminStatus (3) ifOperStatu Trap Name Description swPortLoopOccurred The trap is sent when a port loop occurs. 1.3.6.1.4.1.171 .14.46.0.1 Binding objects: (1) swLoopDetectPortIndex...
Page 683 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description (1) lldpStatsRemTablesInserts (2) lldpStatsRemTablesDeletes (3) lldpStatsRemTablesDrops (4) lldpStatsRemTablesAgeouts lldpXMedTopologyChangeDetected A notification generated by the local device sensing a 1.0.8808.1.1.2. change in the topology that indicates that a new remote 1.5.4795.0.1...
Page 684 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description mplsXCUp This notification is generated when the 1.3.6.1.2.1.10. mplsXCOperStatus object for one or more contiguous 166.2.0.1 entries in the mplsXCTable is about to enter the up state from another state.
Page 685 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description pimNeighborLoss A pimNeighborLoss notification signifies the loss of an 1.3.6.1.2.1.157 adjacency with a neighbor. This notification should be .0.1 generated when the neighbor timer expires, and the router has no other neighbor on the same interface with the same IP version and a lower IP address than itself.
Page 686 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Port Security Trap Name Description dPortSecMacAddrViolation When the port security trap is enabled, new MAC 1.3.6.1.4.1.171 addresses that violate the pre-defined port security .14.8.0.1 configuration will trigger trap messages to be sent out.
Page 687 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description is configured for sending SNMP traps. Binding objects: (1) alarmIndex (2) alarmVariable (3) alarmSampleType (4) alarmValue (5) alarmFallingThreshold Safeguard Trap Name Description dSafeguardChgToExhausted This trap indicates System change operation mode from 1.3.6.1.4.1.171...
Page 688 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description (1) swSingleIPMSID (2) swSingleIPMSMacAddr swSingleIPMSnewRoot The commander Switch will send this notification when its 1.3.6.1.4.1.171 member generates a new root notification. .12.8.6.0.16 Binding objects: (1) swSingleIPMSID...
Page 689 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Storm Control Trap Name Description dStormCtrlOccurred This trap is sent when dStormCtrlNotifyEnable is 1.3.6.1.4.1.171 'stormOccurred' or 'both' and a storm is detected. .14.25.0.1 Binding objects: (1) ifIndex, (2) dStormCtrlNotifyTrafficType...
Page 690 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Trap Name Description the notPresent (5) state. pwUp This notification is generated when the pwOperStatus object for one or more contiguous entries in the pwTable 1.3.6.1.2.1.10. which are about to enter the up (1) state from some other 246.0.2...
Page 691: Appendix D - Radius Attributes Assignment
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide Appendix D - RADIUS Attributes Assignment The RADIUS Attributes Assignment on the Switch is used in the following modules: Console, Telnet, SSH, Web, 802.1X, MAC-based Access Control, and WAC.
Page 692 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide To assign the 802.1p Default Priority by the RADIUS server, the proper parameters should be configured on the RADIUS server. The table below shows the parameters for 802.1p default priority.
Page 693 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide NOTE: A tag field of greater than 0x1F is interpreted as the first octet of the following field. If the user has configured the VLAN attribute of the RADIUS server (for example, VID 3) and the 802.1X, or MAC based Access Control, or WAC authentication is successful, the port will be assigned to VLAN 3.
Page 694: Appendix E - Ietf Radius Attributes Support
Switch. RADIUS attributes are supported by the IETF standard and Vendor-Specific Attribute (VSA). VSA allows the vendor to create an additionally owned RADIUS attribute. For more information about D-Link VSA, refer to the RADIUS Attributes Assignment Appendix.
Page 695 DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide RADIUS Accounting Attributes: Number IETF Attribute User-Name NAS-IP-Address NAS-Port Service-Type Framed-IP-Address Calling-Station-ID NAS-Identifier Acct-Status-Type Acct-Delay-Time Acct-Input-Octets Acct-Output-Octets Acct-Session-ID Acct-Authentic Acct-Session-Time Acct-Input-Packets Acct-Output-Packets Acct-Terminate-Cause Acct-Input-Gigawords Acct-Output-Gigawords NAS-Port-Type NAS-IPv6-Address...

D-Link DGS-3630 Series Reference Manual

1 Introduction

2 Web-Based Switch Configuration

3 System

4 Management

5 Layer 2 Features

6 Layer 3 Features

7 Quality of Service (Qos)

Quick Links

Related Manuals for D-Link DGS-3630 Series

Summary of Contents for D-Link DGS-3630 Series
