Canon iR C6800 Series Service Manual page 674

Chapter 9
Memo:
If you changed the setting in service mode(*), the particulars of the down sequence table may not be as shown
below: for instance, if '1' (priority on fixing) is selected, the down sequence start temperature tends to be slightly
higher; on the other hand, if '2' is selected (priority on productivity), the temperature tends to be slightly lower.
* The following applies:
Plan paper: COPIER>OPTION>BODY>FIX TEMP
Heavy paper 1: COPIER>OPTION>BODY>T1 TEMP
Heavy paper 2: COPIER>OPTION>BODY>T2 TEMP
Heavy paper 3, transparency: COPIER>OPTION>BODY>OHP TEMP
a. 100V Model, A4 Paper, Room Temperature of 20 deg C or Higher
Plain paper
LV deg C
PPM
Initial
1 174
2 173
3 172
4 170
185
Recovery
b. 100 V Model, A4 Paper, Room Temperature of Lower Than 20 deg C
Plain paper
LV deg C
PPM
Initial
1 174
2 173
3 172
4 170
185
Recovery
9-10
Heavy paper 1
LV deg C
68
Initial
60 1 184
50 2 180
35 3 176
4 173
Stop
68 200
Recovery
Heavy paper 1
LV deg C
68
Initial
60 1
50 2 188
35 3 184
4 182
Stop
68 200
Recovery
T-9-5
Heavy paper 2
LV deg C
PPM
68
Initial
40 1 184
30 2 180
20 3 176
4 173
Stop
68 200
Recovery
T-9-6
Heavy paper 2
LV deg C
PPM
Initial
30
1
20 2 188
15 3 184
4 182
Stop
30 200
Recovery
Heavy paper 3/
transparency
LV deg C
PPM
68
Initial
40 1 184
30 2 180
20 3 176
4 173
Stop
68 200
Recovery
Heavy paper 3/
transparency
LV deg C
PPM
Initial
30
1
20 2 188
15 3 184
4 182
Stop
30 200
Recovery
PPM
40
40
30
20
Stop
40
PPM
30
20
15
Stop
30
