I Applications
MERLIN MAIL and MERLIN LEGEND MAIL
System Programming
Complete the following procedures so that MERLIN MAIL or MERLIN LEGEND
MAIL VMS can work on your system. Refer to System Programming for complete
procedures.
Assign all VMS ports to a calling group, set the group type to VMI
Integrated, and set the hunt type to Linear.
Program loop-start lines for reliable disconnect.
Specify the touch-tone duration and interval between digits in codes sent
between the MERLIN MAIL or MERLIN LEGEND MAIL VMS and the
system.
Specify the VMS transfer return interval. This is the number of rings before
a call transferred by the MERLIN MAIL or MERLIN LEGEND MAIL VMS is
sent to the system operator.
Set inside (intercom) dial tone to Outside.
Assign Disallowed Lists to each VMI port not used for Outcalling.
Assign Facility Restriction Levels to each VMI port.
When you use an Automated Attendant only for Night Service:
— If the lines/trunks set for answering by Automated Attendant service
— Specify Immediate Answer (one ring) for the VMI ports.
— Specify the VMS calling group as the Night Service operator.
Platform Requirements
MERLIN MAIL Voice Messaging System
To connect the MERLIN MAIL VMS to the system, you need the following
equipment:
MERLIN MAIL VMS unit
Remote maintenance device (a modem and power supply)
Modem cable with a 9-pin connector at one end and a 25-pin connector at
the other, to connect the remote maintenance device to the serial port on
the MERLIN MAIL VMS unit
D4BU modular cords (two for a two-port system, four for a four-port
system, or six for a six-port system, plus one for the remote maintenance
device)
appear at other extensions, set the No Ring option for the other
extensions.
9
9
9
