Features
Direct Station Selector: MLX
NOTE:
Fast flashing is applicable only to individual extensions. Slow flashing is
applicable only to individual extension types and line/trunk numbers.
Calling Group or CMS Supervisory Operation
A supervisor with a DLC switches from normal call handling to supervisor
operation by pressing the Feature button, dialing
button. The effect of pressing a DSS button while in supervisor operation is the
same as that described for normal call-handling operation. See
on page 281
When the supervisory position is not in Message Status operation, the green LED
next to the Message Status button is off. The red LED next to each DSS button
for a calling group member's extension is used to monitor the availability of
members to take calls directed to the calling group. The meaning of the red LED
associated with each group member is shown in
Table 14. LED Meanings for Supervisor Operation without Message Status Active
Extension
LED Status Status
Off 0
On 2
Slow Flashing 1
NOTE:
The LEDs next to DSS buttons for all other types of extensions are always
off and have no meaning.
Extension Status Operation (Hotel
When Extension Status is in Hotel configuration, the Extension Status feature is
assigned to and removed from individual DLCs through system programming (see
''Extension Status'' on page 256
always active unless the operator presses the Message Status button to use the
Auto Dial or DSS buttons to see message-waiting status for each extension.
Pressing a DSS button while in Hotel Extension Status operation has the same
effect as for normal call-handling operations.
for additional information.
Meaning
The extension is signed out from the group, and the member
is unavailable to take calls.
The extension is signed into the group, and calls can be sent
to the member.
Used for CMS only: the extension is in the after-call work
state, and the group member is not available to take calls.
Configuration)1 4
for details). Hotel Extension Status operation is
1 3
, and pressing the Hold
32
''Group Calling''
Table 14.
