Goodrive3000 series medium voltage inverters
9.1.4 Communication extension card
Model Description
PROFIBUS+Ethernet
EC-TX103
communication card
CANopen+Ethernet
EC-TX105
communication card
Note: For PROFIBUS, Ethernet and CANopen protocols, refer to Operation Manual of INVT
Communication Cards.

9.2 Reactors

Our company provides reactors for selection, among which four-quadrant input reactors are standard.
Model
GD3000-01-055G-12
GD3000-11-055G-12
GD3000-01-075G-12
GD3000-11-075G-12
GD3000-01-090G-12
GD3000-11-090G-12
GD3000-01-110G-12
GD3000-11-110G-12
GD3000-01-132G-12
GD3000-11-132G-12
GD3000-01-160G-12
GD3000-11-160G-12
GD3000-01-200G-12
GD3000-11-200G-12
GD3000-01-250G-12
GD3000-11-250G-12
GD3000-01-315G-12
GD3000-11-315G-12
GD3000-01-400G-12
GD3000-11-400G-12
GD3000-01-500G-12
GD3000-11-500G-12
GD3000-01-630G-12
GD3000-11-630G-12
GD3000-01-800G-12
GD3000-11-800G-12
GD3000-01-1000G-12
GD3000-11-1000G-12
Protocol Baud rate
DP 9.6kbit/s-12Mbit/s
Ethernet 10Mbit/s/100Mbit/s
CANopen 50kbit/s-1Mbit/s
Ethernet 10Mbit/s/100Mbit/s
Input reactor
25006-00298
25006-00298
25006-00298
25006-00298
25006-00438
25006-00438
25006-00438
25006-00210
25006-00210
25006-00210
25006-00441
25006-00441
25006-00435
25006-00435
-224-
Peripheral options and parts
Transmission
distance (in theory)
Max. 1200m
Max. 100m
Max. 2500m
Max. 100m
Output reactor
25006-00395
25006-00395
25006-00395
25006-00395
25006-00072
25006-00072
25006-00072
25006-00431
25006-00431
25006-00431
25006-00440
25006-00440
25006-00434
25006-00434
