Product Overview

3.6 Local Control Panel (LCP)

The local control panel (LCP) is the combined display and keypad on the front of the drive.
The LCP is used to:
•
Control the drive and motor.
•
Access drive parameters and program the drive.
•
Display operational data, drive status, and warnings.
A numeric local control panel (NLCP) is available as an option. The NLCP operates in a manner similar to the LCP, but there
are differences. For details on how to use the NLCP, see the product-specific programming guide.
Illustration 3.4 Graphical Local Control Panel (LCP)
A. Display area
Each display readout has a parameter associated with it. See Table 3.2. The information shown on the LCP can be
customized for specific applications. Refer to chapter 6.3.1.2 Q1 My Personal Menu.
Callout
A1.1
A1.2
A1.3
A2
A3
Table 3.2 LCP Display Area
MG16P222
Operating Guide
A1.2
Status
A1.1
0.00 A
0.0 %
0.0 Hz
2605 kWh
Off Remote Stop
B1
Quick
Status
Menu
B2
C1
On
D1
Warn.
D2
Alarm
D3
E1 Hand
Off
On
E2
Parameter
Parameter 0-20 Display Line 1.1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Danfoss A/S © 04/2018 All rights reserved.
1(1)
A1.3
0.00 kW
A2
A3
B4
Main Alarm
Menu Log
B3
C2
C3
OK
C4
C5
Auto E3
Reset
On
E4
Default setting
Reference [%]
Motor current [A]
Power [Kw]
Frequency [Hz]
kWh counter
3 3
