System configuration controller (SYSCFG)
Bit 2 PVDL: PVD lock
Bit 1 Reserved, must be kept at reset value.
Bit 0 CLL: core lockup lock
8.2.8
Compensation cell control register (SYSCFG_CMPCR)
Address offset: 0x20
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:9 Reserved, must be kept at reset value.
Bit 8 READY: Compensation cell ready flag
Bits 7:2 Reserved, must be kept at reset value.
Bit 0 CMP_PD: Compensation cell power-down
206/1284
This bit is set by software. It can be cleared only by a system reset. It enables and
locks the PVD connection to TIM1/8 Break input. It also locks (write protection) the
PVDE and PVDS[2:0] bits of PWR_CR register.
0: PVD interrupt not connected to TIM1/8 Break input. PVDE and PVDS[2:0] can be
read and modified
1: PVD interrupt connected to TIM1/8 Break input. PVDE and PVDS[2:0] are read-
only
This bit is set and cleared by software. It enables and locks the LOCKUP (Hardfault)
output of the Cortex
®
0: Cortex
-M4 with FPU LOCKUP output not connected to TIM1/8 Break input
®
1: Cortex
-M4 with FPU LOCKUP output connected to TIM1/8 Break input
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
0: I/O compensation cell not ready
1: O compensation cell ready
0: I/O compensation cell power-down mode
1: I/O compensation cell enabled
DocID029473 Rev 3
®
-M4 with FPU core with TIM1/8 Break input.
24
23
22
Res.
Res.
Res.
Res.
8
7
6
READY
Res.
Res.
Res.
r
21
20
19
18
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
RM0430
17
16
Res.
Res.
1
0
Res.
CMP_PD
rw
