xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
Each command is listed, in detail, in the following sections.
config bandwidth_control
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To configure the port bandwidth:
show bandwidth_control
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To display the port bandwidth control table for ports 1 to 10:
DES-3800:admin#show bandwidth_control
Command: show bandwidth_control 1-10
Bandwidth Control Table
Port
Used to configure the port bandwidth control.
config bandwidth_control <portlist>{rx_rate [ no_limit | <value
64-1000000>] | tx_rate [ no_limit | <value 64-1000000>]}
The config bandwidth_control command configures the port
bandwidth control.
<portlist>- Specifes a range of ports to be configured.
rx_rate- Specifies the limitation of receive data rate.
no_limit indicates no limitation , a value from 64 to 1000000 indicates
the limitation in kbits/sec . The switch will choose the closest value
and NOT a greater value in order to work.
tx_rate- Specifies the limitation of transmit data rate.
no_limit indicates no limitation , a value from 64 to 1000000 indicates
the limitation in kbits/sec . The switch will choose the closest value,
but it must NOT be greater than the value in order to work .
Only Administrator or Operator-level users can issue this command.
DES-3800:admin#config bandwidth_control 1-10 tx_rate
640
Command: config bandwidth_control 1-10 tx_rate 640
Success.
DES-3800:admin#
Used to display the port bandwidth control table.
show bandwidth_control {<portlist>}
The show bandwidth_control command displays the port bandwidth
configurations.
<portlist>- Specifies a range of ports to be displayed.
If no parameter specified , system will display all the ports bandwidth
configurations
None.
RX Rate TX Rate
(kbit/sec) (kbit/sec)
1-10
Effective RX
(kbit/sec)
95
Effective TX
(kbit/sec)
