xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
Example usage:
To display the 802.1x authentication states:
DES-3800:admin#show 802.1x auth_configuration ports 1
Command: show 802.1x auth_configuration ports 1
802.1X
Authentication Mode
Authentication Protocol : Radius_Eap
Port number
Capability
AdminCrlDir
OpenCrlDir
Port Control
QuietPeriod
TxPeriod
SuppTimeout
ServerTimeout
MaxReq
ReAuthPeriod
ReAuthenticate : Disabled
CTRL+C ESC q
show 802.1x auth_state
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To display the 802.1x auth state for Port-based 802.1x:
DES-3800:admin#show 802.1x auth_state
Command: show 802.1x auth_state
Port
----
1
2
3
: Enabled
: Port_based
: 1
: None
: Both
: Both
: Auto
: 60 sec
: 30 sec
: 30 sec
: 30 sec
: 2 times
: 3600 sec
Quit SPACE n Next Page
Used to display the current authentication state of the 802.1x server on the
Switch.
show 802.1x auth_state {ports <portlist>}
The show 802.1x auth_state command is used to display the current
authentication state of the 802.1x Port-based or MAC-based Network
Access Control server application on the Switch.
ports <portlist> − Specifies a port or range of ports to be viewed.
The following details what is displayed:
Port number − Shows the physical port number on the Switch.
Auth PAE State: Initialize / Disconnected / Connecting / Authenticating /
Authenticated / Held / ForceAuth / ForceUnauth − Shows the current state
of the Authenticator PAE.
Backend State: Request / Response / Fail / Idle / Initialize / Success /
Timeout − Shows the current state of the Backend Authenticator.
Port Status: Authorized / Unauthorized − Shows the result of the
authentication process. Authorized means that the user was
authenticated, and can access the network. Unauthorized means that the
user was not authenticated, and cannot access the network.
None.
Auth PAE State
----------------
ForceAuth
ForceAuth
ForceAuth
Enter Next Entry
Backend State Port Status
------------- -----------
Success Authorized
Success Authorized
Success Authorized
134
