Commands (Including Guest Vlans) - D-Link DES-3852 - xStack Switch - Stackable Cli Manual

xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
The DES-3800 implements the server-side of the IEEE 802.1x Port-based and MAC-based Network Access Control. This mechanism
is intended to allow only authorized users, or other network devices, access to network resources by establishing criteria for each port
on the Switch that a user or network device must meet before allowing that port to forward or receive frames.
Command
enable 802.1x
disable 802.1x
show 802.1x auth_state
show 802.1x auth_configuration
config 802.1x capability ports
config 802.1x auth_parameter ports
config 802.1x init
config 802.1x auth_mode
config 802.1x reauth
config radius add
config radius delete
config radius
show radius
create 802.1x guest_vlan
config 802.1x guest_vlan ports
delete 802.1x guest_vlan
show 802.1x guest_vlan
Each command is listed, in detail, in the following sections.
802.1X C
OMMANDS
Parameters
{ports <portlist>}
{ports <portlist>}
[<portlist> | all] [authenticator | none]
[<portlist> | all] [default | {direction [both | in] | port_control
[force_unauth | auto | force_auth] | quiet_period <sec 0-65535> |
tx_period <sec 1-65535> | supp_timeout <sec 1-65535> |
server_timeout <sec 1-65535> | max_req <value 1-10> |
reauth_period <sec 1-65535> | enable_reauth [enable | disable]}]
[port_based ports [<portlist> | all] | mac_based [ports] [<portlist> |all]
{mac_address <macaddr>}]
[port_based | mac_based]
{port_based ports [<portlist> | all] | mac_based [ports] [<portlist> |all]
{mac_address <macaddr>}]
<server_index 1-3> <server_ip> key <passwd 32> [default | {auth_port
<udp_port_number 1-65535> | acct_port <udp_port_number 1-
65535>}]
<server_index 1-3>
<server_index 1-3> {ipaddress <server_ip> | key <passwd 32>
[auth_port <udp_port_number 1-65535> acct_port <udp_port_number
1-65535>]}
<vlan_name 32>
[<portlist> | all] state [enable | disable]
{<vlan_name 32>}
131
(I G
NCLUDING
18
VLAN )
UEST S
