xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
show current_config access_profile
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To display ACL part:
DES-3800:admin#show current_config access_profile
Command: show current_config access_profile
#----------------------------------------------------------------
# ACL
create access_profile ethernet vlan profile_id 1
config access_profile profile_id 1 add access_id 1 ethernet vlan default
port 1
permit
disable cpu_interface_filtering
#----------------------------------------------------------------
DES-3800:admin#
config flow_meter
Purpose
Syntax
Description
Parameters
Used to show the ACL CLI commands in current configuration.
show current_config access_profile
The ACL port will be displayed by this command.
None.
None.
To configure packet flow-based metering based on an access profile and
rule.
config flow_meter profile_id <value 1-255> access_id <value 1-65535> rate
<value 0-999936> rate_exceed [drop | set_drop_precedence]
This command is used to configure the flow-based metering function, users
may set the preferred bandwidth for this rule, in Kbps and once the
bandwidth has been exceeded, overflow packets will be either dropped or
be set for a drop precedence, depending on user configuration. The
set_drop_precedence function work with WRED.
Note: If the bandwidth is configured as zero, the meter will be destroyed.
Profile_id - Specifies the profile_ID
access_id - Specifies the access_ID
Rate - Specify the committed bandwidth in Kbps for the flow. The value of 0
means to delete this flow_meter setting.
rate_exceed - This specifies the action for packet which exceed the
committed rate.The action can be specified to be one of the following.
drop_packet: drop_packet.
set_drop_precedence: the packet will not be dropped right away. However,
when the traffic is busy, it has the higher probability to be dropped in the
