xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
create ospf aggregation
Purpose
Syntax
Description
Parameters
Restrictions
Usage example:
To create an OSPF area aggregation:
delete ospf aggregation
Purpose
Syntax
Description
Parameters
Restrictions
Usage example:
To configure the OSPF area aggregation settings:
Host Address Metric
------------ ------
Total Entries: 0
DES-3800:admin#
Used to configure OSPF area aggregation settings.
create ospf aggregation <area_id> <network_address> lsdb_type
summary {advertise [enable | disable]}
This command is used to create an OSPF area aggregation.
<area_id> − A 32-bit number in the form of an IP address
(xxx.xxx.xxx.xxx) that uniquely identifies the OSPF area in the OSPF
domain.
<network_address> − The 32-bit number in the form of an IP address
that uniquely identifies the network that corresponds to the OSPF Area.
lsdb_type summary − The type of address aggregation.
advertise [enable | disable] − Allows for the advertisement trigger to be
enabled or disabled.
Only Administrator or Operator-level users can issue this command.
DES-3800:admin#create ospf aggregation 10.1.1.1
10.48.76.122/16 lsdb_type summary advertise enable
Command: create ospf aggregation 10.1.1.1
10.48.76.122/16 lsdb_type summary advertise enable
Success.
DES-3800:admin#
Used to delete an OSPF area aggregation configuration.
delete ospf aggregation <area_id> <network_address> lsdb_type
summary
This command is used to delete an OSPF area aggregation
configuration.
<area_id> − A 32-bit number in the form of an IP address
(xxx.xxx.xxx.xxx) that uniquely identifies the OSPF area in the OSPF
domain.
<network_address> − The 32-bit number in the form of an IP address
that uniquely identifies the network that corresponds to the OSPF Area.
lsdb_type summary − Specifies the type of address aggregation.
Only Administrator or Operator-level users can issue this command.
Area ID TOS
----------- ---
218
