xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
CPU I
The xStack DES-3800 switch series implements Access Control Lists that enable the Switch to deny or permit network access to
specific devices or device groups based on IP settings, MAC address, and packet content.
Command
create cpu access_profile
delete cpu access_profile
config cpu access_profile profile_id
enable cpu interface_filtering
disable cpu_interface_filtering
show cpu_interface_filtering
show cpu access_profile
F
NTERFACE ILTERING
Parameters
[ethernet {vlan | source_mac <macmask> | destination_mac <macmask> |
ethernet_type} | ip {vlan | source_ip_mask <netmask> |
destination_ip_mask <netmask> | dscp | [icmp {type | code} | igmp {type} | tcp
{src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} | flag_mask
[all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port_mask <hex 0x0-0xffff> |
dst_port_mask <hex 0x0-0xffff>} | protocol_id {user_mask <hex 0x0-0xffffffff>}]}
| packet_content_mask {offset 0-15 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff>| offset 16-31 <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | {offset 32-47 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | {offset 48-
63 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> | {offset 64-79 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff>}] [profile_id <value 1-5>]
profile_id <value 1-5>
<value 1-5> [add access_id <value 1-65535> [ethernet {vlan <vlan_name 32>
| source_mac <macaddr> | destination_mac <macaddr> | ethernet_type <hex
0x0-0xffff>} [permit | deny] | ip {vlan <vlan_name 32> | source_ip <ipaddr> |
destination_ip <ipaddr> | dscp <value 0-63> | [icmp {type <value 0-255> code
<value 0-255>} | igmp {type <value 0-255>} | tcp {src_port <value 0-65535> |
dst_port <value 0-65535> | {urg | ack | psh | rst | syn | fin}]} | udp {src_port
<value 0-65535> | dst_port <value 0-65535>} | protocol_id <value 0 - 255>
{user_define <hex 0x0-0xffffffff>}]} [permit | deny] | packet_content {offset_0-15
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>|
offset_16-31 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> | offset_32-47 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> | offset_48-63 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_64-79 <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>} [permit |
deny] | delete access_id <value 1-65535>]
{profile_id <value 1-5> {access_id <value 1-65535>}}
(S
OFTWARE
336
48
ACL) C
OMMANDS
