xStack DES-3800 Series Layer 3 Stackable Fast Ethernet Managed Switch CLI Manual
Virtual Interface Configuration
Transit
Area ID
--------
10.0.0.0
10.1.1.1
Total Entries : 2
OSPF Area Aggregation Settings
Area ID
---------------
Total Entries : 0
OSPF Host Route Settings
Host Address
-------------
Total Entries : 0
DES-3800:admin#
create ospf area
Purpose
Syntax
Description
Parameters
Restrictions
Usage example:
To create an OSPF area:
DES-3800:admin#create ospf area 10.48.74.122 type
normal
Command: create ospf area 10.48.74.122 type normal
Success.
DES-3800:admin#
Virtual Hello
Neighbor Router Interval Interval
--------------- -------- -------- --------------
20.0.0.0 10
20.1.1.1 10
Aggregated
Network Address
------------------
Metric Area ID
------ ---------------
Used to configure OSPF area settings.
create ospf area <area_id> type [normal | stub {stub_summary
[enable | disable] | metric <value 0-65535>}]
This command is used to create an OSPF area and configure its
settings.
<area_id> − The OSPF area ID. The user may enter a 32-bit number in
the form of an IP address (xxx.xxx.xxx.xxx) that uniquely identifies the
OSPF area in the OSPF domain.
type [normal | stub] − The OSPF area mode of operation − stub or
normal.
stub_summary [enable | disable] − Enables or disables the OSPF area
to import summary LSA advertisements.
metric <value 0-65535> − The OSPF area cost between 0 and 65535. 0
denotes that the value will be automatically assigned. The default setting
is 0.
Only Administrator or Operator-level users can issue this command.
Dead Authentication
60 None
60 None
LSDB Advertise
Type
-------- ---------
TOS
---
214
Link
Status
------
DOWN
DOWN
