Introduction to Netlink Frame Relay Access Devices
Serial port cables are shown in the following table.
Table 1-1 WAN Port Cables for Netlink FRX4000
Port
Number
WAN 0, 1
WAN 2, 3
WAN 4–7
The Ethernet model of the Netlink FRX4000 contains an Ethernet interface, provided
in RJ-45 (for twisted pair) and 15-pin "D" (AUI, for Thicknet) configurations. The
Ethernet cable and, if AUI, the tranceiver, must be provided by the customer.
The Token Ring model of FRX4000 contains a Token Ring interface, provided in RJ-
45 (for unshielded twisted pair) and 9-pin "D" (for shielded twisted pair) configura-
tions. A Token Ring cable, part number FRX-TR-CAB, is available from Cabletron.
After it has been installed and configured, an FRX4000 can function with no keyboard
or video device. (Therefore, such devices are not standard equipment.) However, con-
figuration, file copy (backup, restore, transfer, etc.), and monitoring operations require
a keyboard and screen, in one of several forms.
Type of Interface
Connector with Cable
RS-232 RS-232 DTE
RS-232 DCE
Universal RS-232 DTE
(HD-44) RS-232 DCE
V.35 DTE
V.35 DCE
RS-449 DTE
RS-449 DCE
X.21 DTE
X.21 DCE
RS-232 RS-232 DTE
RS-232 DCE
V.35 V.35 DTE
V.35 DCE
RS-449 RS-449 DTE
RS-449 DCE
RS-449 X.21 DTE
X.21 DCE
1-7
