PU Subscriber Parameters
PU Name
Local Subscriber ID
Remote Subscriber ID
Maxdata
Autocall
Autocall Retry Time
Autocall Retry Count
LPDA Resource ID
Istatus
LLC2 Connection
Configuring SNA
identifies the PU to an SNMP or NetView host.
is the subscriber address of the local end of an SNA connection. (A Subscriber ID—
see page 8-13—must also be configured.)
is the subscriber address of the remote end of an SNA connection. (A Subscriber ID—
see page 8-13—must also be configured.)
must correspond to the PIU size configured on the host (parameter MAXDATA of
macro PU in VTAM). For a link between a PU type 4 and a PU type 2, the frame size
configured for the TPAD port must be set at the value of MAXDATA in VTAM plus
6 bytes (corresponding to the length of the link header and the link trailer).
causes automatic calling between SNA ports when the controller (identified by Link
Address) becomes active. If set to
the local port to the remote subscriber port.
If both ends of a connection are configured for autocall, their retry timers (see next
entry) should be different, to avoid collisions.
is the time between autocall retries.
is the maximum number of times an autocall will be sent. Note that a value of
indefinite retries.
identifies a logical unit (LU) on the PU. LPDA requires both a PU name and an LU
ID. The Resource ID value must match the NetView LOCADDR.
affects the line and PU the same way
as , the PU will be disabled until either an on-line enable is performed (see
Inactive
page 16-16) or a VARY ACT (see page E-4) is sent from a NetView manager device.
specifies whether SDLC-LLC2 conversion will be done on the PU connection, either
locally or at a remote node via an X.25 logical or physical port.
If SDLC-LLC2 conversion will be done, LLC2 Connection must
be configured as
properly after the session unless an on-line update (
formed in the logical port record.
on an SNA port, an X.25 call will be made from
Y
Blocked Port Flag
Y ; otherwise, the PU will not re-activate
0
affects the port. If configured
) is per-
[F7]
allows
8-9
